Wiper Operation When the Wiper Parking Terminal Is Grounded

1. The wiper system continuously outputs the parking signal of current sensitivity when the parking terminal is

grounded (while the ignition key is in "ON" position and the wiper switch is in "ON" position).

* The wiper motor runs only when the rain sensor requires.

IGN (Operation)

2. When the parking terminal is fixed to IGN (HIGH), the wiper system outputs the operating signal of current

sensitivity for 2 seconds, then continuously outputs the parking signal of current sensitivity.

* The wiper motor runs only when the rain sensor requires.

IGN (Operation)

RKSTICS (REKES + STICS) / STICS

KYRON SM - 2005.09

EFFECTIVE DATE

AFFECTED VIN
