SSANGYONG Kyron Repair Manual page 889

11
8790
PAS Unit
Preceding Work:
1. Disconnection of negative battery cable
2. Removal of rear lower quarter panel and seat belt.
(For removal and installation, refer to the BODY section.)
1. Disconnect the connector and mounting bolts (10 mm - 2EA) and then remove the PAS unit.
Connector
Disconnection Removal of
of connector mounting bolt
Connector
PARKING AID SYSTEM
CHANGED BY
EFFECTIVE DATE KYRON SM - 2005.09
AFFECTED VIN
