Second Row Seat
1. Slide the front seats forward and remove the four front
mounting nuts (14 mm) of the second row seat.
Installation Notice
Tightening torque
2. Lay down the seatback of the second row seat and remove the eight rear mounting nuts (14 mm). Insert a wrench
between seatback and cushion to remove the mounting bolts with arrow mark.
3. Remove the second row seat from the vehicle.
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
35 ~ 55 Nm
13
7410
Tightening torque:
35 ~ 55 Nm
SEAT & SEAT BELT
KYRON SM - 2005.09
