4. AIR CONDITIONER CONTROLLER (UNIT)

Functions of Full Automatic Air Conditioner Controller ( )
1
1. TEMP switch
2. AUTO switch
3. OFF switch
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
11
2
3 10 5
4. AMB switch
5. Mode switch
6. Blower switch
8 7 9
7. AQS switch
8. FRE switch
9. Defroster switch
AIR CONDITIONING SYSTEM
9
6810
6 4
10. A/C switch
11. VFD (Display)
