Drain Channel
Preceding Work: Removal of glass panel
1. Remove the two mounting bolts (TORX bolt) at both sides on the drain channel with the glass panel removed.
2. Unhook the locks (A) and remove the drain channel.
3. When installing
Hook the locks (B) of the drain channel.
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
Tightening torque:
1.2 Nm
13
7340
With Sunroof Tilted-up
SUNROOF SYSTEM
KYRON SM - 2005.09
