Trouble
Defectives
Code
P2311 CAN: Faulty ECU communication
P2312 CAN: Faulty ECU communication
P2313 CAN: Faulty selector lever control
communication
P2315 CAN: Faulty instrument panel commu-
nication
P2317 CAN: Faulty communication between
TCCU/TOD and CAN
(For 4WD only)
P2330 CAN: Faulty brake system signal
CAN: Faulty ECU message
P2331
P2332 CAN: Faulty ECU message
P2333 CAN: Faulty selector lever signal
P2335 CAN: Faulty instrument cluster signal
P2337 CAN: Faulty TCCU/TOD
(For 4WD only)
P2400 CAN: Faulty rear RH wheel speed
sensor signal
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
Action
- Check CAN communication line H and L.
- Check engine ECU.
- Check the related harness for open, short and contact.
- Check CAN communication line H and L.
- Check engine ECU.
- Check the related harness for open, short and contact.
- Check CAN communication line H and L.
- Check selector lever.
- Check the related harness for open, short and contact.
- Check CAN communication line H and L.
- Check instrument cluster.
- Check the related harness for open, short and contact.
- Check CAN communication line H and L.
- Check TCCU/TOD unit.
- Check the related harness for open, short and contact.
- Check CAN communication line H and L.
- Check ABS/ESP unit.
- Check the related harness for open, short and contact.
- Check CAN communication line H and L.
- Check engine ECU.
- Check the related harness for open, short and contact.
- Check CAN communication line H and L.
- Check engine ECU.
- Check the related harness for open, short and contact.
- Check CAN communication line H and L.
- Check selector lever. Check selector lever.
- Check the related harness for open, short and contact.
- Check CAN communication line H and L.
- Check instrument cluster.
- Check the related harness for open, short and contact.
- Check CAN communication line H and L.
- Check TCCU/TOD unit.
- Check the related harness for open, short and contact.
- Check CAN communication line H and L.
- Check ABS/ESP unit.
• Check wheel speed sensor connector.
• Check the air gap between tooth wheel and wheel
speed sensor. (Air gap: 0.309 ~ 0.958 mm)
• Check the numbers of tooth wheel: 48
- Check the related harness for open, short and contact.
