3. REMOVAL AND INSTALLATION OF SEAT

Driver's Seat (Power Seat)
1. Move the seat rearward as far as possible and unscrew
the two front mounting bolts (14 mm) at both sides.
Installation Notice
Tightening torque
2. Move the seat forward as far as possible and unscrew
the two rear mounting bolts (14 mm) at both sides.
Installation Notice
Tightening torque
3. Lay down the seatback and disconnect the connector under the seat and then remove the seat assembly.
Disconnect the connector
Connector
(seat side)
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
35 ~ 55 Nm
35 ~ 55 Nm
Main connector
11
7410
SEAT & SEAT BELT
KYRON SM - 2005.09
