Rear Wheel Speed Sensor
1. Disconnect the speed sensor connector. Set aside the wheel speed sensor cable.
2. Remove one of self-locking bolt (10 mm). Remove rear wheel speed sensor.
When Installing
Keep the specified tightening torque and air gap.
Tightening torque
Wheel speed sensor
Airgap (mm)
NOTICE
• Tighten the bolts with the specified tightening
torque.
• Otherwise, the air gap between the wheel speed
sensor and wheel rotor may be out of specified
value, and this may cause an incorrect input
value to HECU.
ABS/ESP SYSTEM
KYRON SM - 2005.09
6 ~ 8 Nm
0.037 ~ 1.175 (5-link)
0.489 ~ 1.039 (IRS)
