36
4890
Removal and Installation
1. Disconnect the battery negative terminal.
2. Remove the connector of the pressure sensor.
3. Remove the fuel filter bracket to remove the pressure
sensor.
4. Place an empty container under the pressure sensors
to collect the oil.
5. Remove the primary and secondary pressure sensors.
When installing
Tightening torque
6. Install in the reverse order of removal.
7. Bleed the brake system after installation.
ABS/ESP SYSTEM
KYRON SM - 2005.09
33 ~ 37 Nm
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
