3. Remove the right and left hoses from the inter cooler.
LH
4. Remove the inlet/outlet hoses and return hose from the radiator.
5. Remove the air conditioner hose and pipe at condenser side.
High-pressure Pipe: Compressor Side
Tightening
torque:
16 ~ 23 Nm
Plug the pipe openings with a seal caps after disconnecting the high/ low pressure pipes.
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
Radiator Inlet Hose
RH
Return Hose
Low-pressure Pipe: Receiver Dryer Side
AIR CONDITIONING SYSTEM
53
