Compressor Assembly

Preceding Work: Disconnect the negative battery cable and collect the air conditioner refrigerant.
1. Remove the cooling fan belt from the engine.
2. Disconnect the connector from the compressor.
3. Unscrew the flange nuts
of pressure pipes and
compressor mounting
bolts and remove the com-
pressor assembly.
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
Tightening
torque:
16 ~ 23 Nm
6810
Tightening
torque:
16 ~ 23 Nm
Tightening
torque:
18 ~ 27 Nm
Tightening torque: 18 ~ 27 Nm
