Door Ajar Warning
1. The warning light in indicator display comes on when opening any of the driver's door, the passenger's door, the
rear doors or the tailgate while the vehicle speed is below 10 km/h.
2. The warning light goes off when closing the door under step 1.
3. The warning light blinks when the vehicle speed is over 10 km/h while the warning light is turned on.
4. The warning light blinks when a door is open while the vehicle speed is over 10 km/h.
5. The warning light goes off when closing the door under step 3.
6. The warning light comes on when the vehicle speed is below 10 km/h under step 3.
IGN1
DOOR SW (*1)
OVER V1
VEHICLE SPEED
BELOW V1
DOOR AJAR
WARN LAMP
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
ON
OFF
OPEN
CLOSE
T2
ON
OFF
T3
T2: 0.6 sec
(*1) DOOR OPEN: Dr or Ps or Rr or T/GATE = OPEN
CLOSE: Dr & Ps &r Rr & T/GATE = CLOSE
T3: 0.3 sec V1 = 10 Km/h
