Parking Brake Warning
1. The parking brake warning light comes on for approx. 4 seconds when turning the ignition key from the "OFF" to
the "ON" position regardless of the vehicle speed and the parking brake switch position. After this 4 seconds, the
warning lamp comes on, goes off or blinks according to the vehicle speed and the parking brake switch position.
2. The warning light comes on when the parking brake switch is turned on while the vehicle speed is below 10 km/h.
3. The warning light goes off when turning off the parking brake switch under step 2.
4. The warning light blinks and the chime buzzer in the ICM box sounds for 2.85 seconds and stops for 1.5 seconds
when the vehicle speed is over 10 km/h for more than 2 seconds while the parking brake switch is turned on.
5. The warning light goes off and the chime buzzer stops when turning off the parking brake switch under step 4.
6. The warning light comes on and the chime buzzer stops when the vehicle speed goes down below 10 km/h under step 4.
7. This function is not available when the ignition key is turned to the "OFF" position.
IGN1 SW
P/BRAKE
Over V1
VEHICLE SPEED
Below V1
P/BREAK WARN
LAMP
C/BUZZER
T1: 2.0 sec ± 0.5 sec T2: 0.6 sec T3: 0.3 sec T4: 4.0 sec V1: 10 Km/h T5: 2.5 sec ± 0.1 sec T6: 1.5s ± 0.1 sec
Parking Brake: Hand operated type (manual transmission equipped vehicle), Foot operated type (automatic trans-
mission equipped vehicle)
Hand Operated Type
(Manual Transmission Equipped Vehicle)
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
ON
OFF
ON
OFF
T4
T2
ON
OFF
T3
ON
OFF
T5
T6
T1
Foot Operated Type
(Automatic Transmission Equipped Vehicle)
RKSTICS (REKES + STICS) / STICS
27
8710
T4
