1. Unscrew two bolts (12 mm) and remove the change
lever from shift lever.
Installation Notice
Tightening torque
2. Unscrew two bolts (12 mm) from semi-remote
controller.
Installation Notice
Tightening torque
3. If the oil should be changed, remove the oil drain
plug (A) in transmission housing and fully drain the
oil. And, retighten the plug (A).
Installation Notice
Tightening torque
4. Unscrew four bolts (17 mm) and separate the rear and front propeller shafts connected to transfer case output
shaft. Compress the propeller shaft and bind to torsion bar not to disturb the operation.
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
12 ~ 23 Nm
12 ~ 23 Nm
40 ~ 50 Nm
Tightening torque:
81 ~ 89 Nm
3170
Change lever
1
2
Tightening torque:
81 ~ 89 Nm
MANUAL TRANSMISSION
KYRON SM - 2005.09
31
