Surface Sensor
1. The surface sensor and cable harness make up one
component.
1) Surface sensor
2) Mounting spring
Check Surface Sensor
Check the surface sensor with a digital multimeter. If the
resistance of flame sensor is out of specified values, the
flame sensor is defective.
Specified value
Temperature [°C] 0
Resistance [W] 30.00
Controller
The surface heater and cable harness make up one
component.
1) Controller
2) Jacket
3) Combustion chamber housing
4) Mounting screw
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
20 30 40
10
13.03 8.90 6.20
19.53
Temperature [°C]
60 80
50 70
3.19 1.75
4.41 2.34
71
6910
100 120
90
1.02 0.62
1.32
