16
5110
ROOF FASHION RAIL
1. CONSTRUCTION
CAUTION
• To prevent water leaks, apply the liquid
sealant to the bolt thread when install-
ing the roof fashion rail.
2. REMOVAL AND INSTALLATION
Preceding Work: Remove the headlining assembly.
Unscrew the front and rear mounting nuts (10 mm) and remove the roof fashion rail. The front mounting nut is
located behind the hand grip bracket.
BODY EXTERIOR
KYRON SM - 2005.09
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
