4. INPUT/OUTPUT OF SPWM UNIT

Seat memory power
Seat sliding, rear lift power
Seat reclining, front lift power
Instrument panel:
gear shift lever at "P" position
In the vehicle equipped with automatic
transmission, the position memory recall
is not available if the gear shift lever is not
in "P" position.
Parking brake operation
In the vehicle equipped with manual
transmission, the position memory recall
is not available if the parking brake is
released.
Vehicle speed signal
If vehicle speed is over 3 km/h, the position
memory recall is not available.
Outside rearview
mirror folding switch
Outside rearview mirror
adjusting switch
Power seat control switch
Seat memory
switch
SEAT POSITION WITH MEMORY
KYRON SM - 2005.09
Sliding motor
Cushion front motor
Cushion rear motor
RH outside rearview
mirror folding/unfolding
motor
LH outside rearview
mirror folding/unfolding
motor
RH outside mirror Up/
Down adjustment motor
RH outside mirror Left/
Right adjustment motor
LH outside mirror Up/
Down adjustment motor
LH outside mirror Left/
Right adjustment motor
The changes of each motor are always
monitored by the sensor in the motor.
