Glow Plug
1) Glow plug
2) Combustion chamber with flame pipe
Combustion Chamber Housing
1) Jacket
2) Combustion chamber housing
3) Insulation washer
4) Seal - combustion chamber / combustion air fan
5) Seal - combustion chamber / heat exchanger
Flame Sensor
1) Flame sensor
2) Graphite bush
3) Bush
