Clutch C1
1. Outer multiple-disc carrier/clutch C1
1b. Sealing ring
2. Piston
3. Sealing ring in piston
4. Disc spring
5. Spring plate
5a. Sealing ring
6. Snap ring
7. Multiple-disc pack
8. Snap ring
9. Snap ring
10. Front freewheel
A. Oil pressure bore
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
Clutch C2
11. Inner multiple-disc carrier/clutch C1 with
integrated foot gear set
12. Hollow gear
13. Snap ring
14. Axial needle bearing
15. Clutch C2 and input shaft
16. Piston
17. Inner sealing ring in piston
18. Outer sealing in piston
19. Disc spring
20. Spring retainer
21. Snap ring
22. Multiple-disc set
23. Snap ring
Clutch C3
24. Outer multiple-disc carrier
25. Sealing ring
26. Piston
27. Spring plate
28. Disc spring
29. Snap rig
30. Multiple-disc pack
61
3650
AUTO TRANSMISSION
KYRON SM - 2005.09
