30
4610
Lower Shaft
1. Remove the upper lock bolt inside the vehicle and the lower lock bolt in underbody.
Tightening torque: 18 ~ 25 Nm
2. Remove the lower shaft mounting nuts on floor.
Installation Notice
Tightening torque
3. Remove the lower shaft.
NOTICE
• Install the lower shaft so that the lock bolt can be in-
serted into the point without spline.
• Be cautious of the alignment marks.
Lower Shaft Assembly
POWER STEERING SYSTEM
KYRON SM - 2005.09
Tightening torque: 18 ~ 25 Nm
7 ~ 11 Nm
