Trouble
Defections
Code
1380 Driver's curtain air bag is
short to ground
1381 Driver's curtain air bag is
short to battery voltage
1382 Passenger's curtain air bag
circuit resistance is too high
1383 Passenger's curtain air bag
circuit resistance is too low
1384 Passenger's curtain air bag
is short to ground
1385 Passenger's curtain air bag
is short to battery voltage
1395 Air bag connector problem
1400
Driver's curtain air bag sensor
problem
1401
Driver's curtain air bag sensor
circuit is short to ground
1402 Driver's curtain air bag sensor
circuit is short to battery volt-
age
1409
Communication error in
driver's curtain air bag
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
• Check driver curtain air bag connector.
• Check driver curtain air bag wiring.
• Check air bag unit terminals for damage.
• Resistance: below 2 kΩ
• Check driver curtain air bag connector.
• Check driver curtain air bag wiring.
• Check air bag unit terminals for damage.
• Resistance: below 2 kΩ
• Check passenger curtain air bag connector.
• Check passenger curtain air bag wiring.
• Check air bag unit terminals for damage.
• Resistance of squib: over 4.3 Ω
• Check passenger curtain air bag connector.
• Check passenger curtain air bag wiring.
• Check air bag unit terminals for damage.
• Resistance of squib: below 0.6 Ω
• Check passenger curtain air bag connector.
• Check passenger curtain air bag wiring.
• Check air bag unit terminals for damage.
• Resistance: below 2 kΩ
• Check passenger curtain air bag connector.
• Check passenger curtain air bag wiring.
• Check air bag unit terminals for damage.
• Resistance: below 2 kΩ
• Check passenger curtain air bag connector.
• Check passenger curtain air bag wiring.
• Check air bag unit terminals for damage.
• Check driver curtain air bag connector.
• Check driver curtain air bag wiring.
• Check air bag unit terminals for damage.
• Check driver curtain air bag connector.
• Check driver curtain air bag wiring.
• Check the air bag unit terminals for damage.
• Resistance: below 250 Ω
• Check driver curtain air bag connector.
• Check driver curtain air bag wiring.
• Check air bag unit terminals for damage.
• Resistance: below 25 Ω
• Check driver curtain air bag connector.
• Check driver curtain air bag wiring.
• Check air bag unit terminals for damage.
• If the voltage drops below 10.6 V during normal system
operation, the trouble code is generated. This trouble code is
linked with B1 400, B1 401, B1 402, B1 414.
8810
Action
AIR BAG SYSTEM
