MULTIFUNCTION SWITCH

1. OVERVIEW

The multifunction switch in this vehicle contains basic multifunction switch functions, Auto washer & wiper, fog lamp
switch and Auto hazard lamp switch. When serving the multifunction switch, pay particular attention not to damage
the air bag spring clock installed on the multifunction switch.
Mounted View
Front fog lamp switch
SWITCHES / ELECTRIC DEVICES
KYRON SM - 2005.09
Front auto washer and wiper switch
When the front wiper switch is off and this
switch is pressed, washer fluid will be
sprayed and the wiper will automatically
operate 4 times. Then, the fluid will be
sprayed again and the wiper will automati-
cally operate 3 times.
<For detailed operation logics, refer to "STICS">
