INTERIOR LAMPS
Front Room Lamp
12V/10W -Two at each lamps
The driver's room lamp and the passenger's
room lamp are separately turned on when press-
ing the switch (1, 2). However, the front lamps
are turned on when opening a door and turned
off when closing it. The front room lamps and
center are turned on when pressing the room
lamp main switch (3).
Glove Box
12V/5W - One at glove box
LAMP
KYRON SM - 2005.09
Center and Luggage Room Lamp
Toward tailgate
Center room lamp
(coupled operation
with door)
Luggage room lamp
(Lamp: OFF)
Center Room Lamp
When this switch is pushed to-
wards the rear of the vehicle,
the lamp comes on. If the
switch is pushed to the oppo-
site direction, the lamp will go
off. But, when any door is open,
the lamp comes on and stays
for 30 seconds. When the door
is closed, the lamp will go off.
Door Courtesy Lamp
Toward dirver side
Center room
lamp
(Lamp: ON)
Luggage room
lamp (coupled
operation with
tailgate)
12V/10W - One at each lamp
Luggage Room Lamp
When this switch is pushed to-
wards the tailgate, the lamp
comes on when the tailgate is
open. If the switch is pushed
to the opposite direction, the
lamp will go off and will not
come on even if the tailgate is
open.
12V/5W - one at each door
