Shock Absorber Assembly

Preceding Work: Remove the tire.

1. Compress the coil spring with special tool and unscrew the shock absorber upper nut on body (frame)

(17 mm - 1EA).

2. Unscrew the shock absorber lower bolt/nut (bolt: 14 mm / nut: 17 mm) on coil spring link.

3. Remove the shock absorber from the rear suspension.

KYRON SM - 2005.09

Tightening torque: 30 ~ 45 Nm

Tightening torque: 60 ~ 80 Nm

EFFECTIVE DATE

AFFECTED VIN
