Air Mix Door Actuator
The air mix door actuator controls the discharging air temperature properly by closing/opening the damper according
to the control signals from FATC.
Air mix door actuator component
Air mix door actuator location
Removal and Installation
Preceding Work: Disconnect the battery negative cable and remove the instrument panel assembly.
With the instrument panel assembly removed as shown in the above figure, disconnect the air mix door actuator and
unscrew two mounting screws to remove the air mix door actuator.
