3. REMOVAL AND INSTALLATION OF HEADLAMPS

Headlamp Assembly

Preceding Work: Disconnect the negative battery

1. Open the engine hood and unscrew two headlamp up-

per mounting bolts (10 mm).

2. Remove the headlamp lower cover from the upper front bumper and unscrew the headlamp lower mounting nut

• Be careful not to damage the headlamp cover when removing it in order of the above number.

3. Disconnect two headlamp connectors (Turn signal lamp/Position lamp, Low beam/High beam).

EFFECTIVE DATE

AFFECTED VIN

KYRON SM - 2005.09
