AUTOMATIC TRANSMISSION

TABLE OF CONTENTS

GENERAL INFORMATION ...................... 2
1. Overview .............................................................. 2
AUTOMATIC TRANSMISSION
(DC 5-SPEED) .......................................... 4
1. Appearance ......................................................... 4
2. Structure and specifications ............................... 5
3. Power flow ......................................................... 11
FUNCTION AND DESCRIPTION........... 19
1. Selector lever .................................................... 19
2. Torque converter ................................................ 24
3. Planetary gear set ............................................ 27
4. Multiple-disc clutch .......................................... 28
5. Freewheel ......................................................... 29
6. Others ............................................................... 30
REMOVAL AND INSTALLATION ........... 33
1. Selector lever and link ...................................... 33
2. Front and rear propeller shaft ........................... 36
3. Transmission assembly .................................... 38
4. Replacing the o-ring on parking pawl guide
sleeve ................................................................ 42
5. Disassembly and reassembly
(DC 5-SPEED A/T) ............................................ 46
6. Valve body ......................................................... 65
(DC 5-SPEED)
3650 / 3660 / 3110
SPECIAL TOOLS AND EQUIPMENT .... 68
VALVE BODY .......................................... 72
HYDRAULIC CIRCUIT ........................... 80
1. Hydraulic circuit diagram .................................. 80
2. Hydraulic circuit ................................................ 85
3. Adapter plug ..................................................... 91
4. Valve body ......................................................... 93
TCU (Transmission Control Unit) ........ 99
TROUBLE CODE AND DIAGNOSIS ... 104
1. Trouble diagnosis with SCAN-100 .................. 104
2. DTC (Diagnosis Trouble Code) of DC5AT ....... 105
3. Removal and installation of TCU .................... 112
