4. Disconnect the power steering pipes and remove the steering gearbox mounting bolts.
Supply and Return Pipes
Tightening torque: 20 ~ 26 Nm
Gear Box Mounting/Gear box Cross Member
Tightening torque:
70 ~ 90 Nm
NOTICE
• Tighten the center bolt/nut first, and then tighten the left mounting bolt with the specified tightening torque.
POWER STEERING SYSTEM
KYRON SM - 2005.09
NOTICE
• Plug the pipe openings with caps.
• Be careful not to spill the oil on the floor and
vehicle body.
Tightening torque:
70 ~ 90 Nm
Gear box Mounting
Clamping Bolt
Tightening torque:
30 ~ 40 Nm
