Rear gear set and center
output shaft
Rear freewheel and rear
hollow shaft
Rear gear set and center output shaft
1. Output shaft in center gear set
2. Needle bearing
3. Teflon ring
4. Thrust washer
5. Thrust needle bearing
6. Shim
7. Circlip
8. Rear gear set
9. Thrust washer
10. Clutch C3
11. Rear hollow shaft
C. Oil outlet port in clutch C3
D. Oil inlet port in clutch C3
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
Rear freewheel and rear hollow shaft
12. Hollow shaft
13. O-ring
14. Snap ring
15. Freewheel
16. Inner disc carrier and rear sun gear/clutch C3
17. Thrust needle bearing
18. Shim
19. Circlip
63
3650
AUTO TRANSMISSION
KYRON SM - 2005.09
