Function Defective Components
Wheel speed sensor
1. C1031 (5031)
Cause
- Defective rear RH wheel speed sensor
- Short or poor contact wire to sensor
Action
- Check the wheel speed sensor connector
- Check the HECU connector
- Check the harness connection
2. C1032 (5032)
Cause
- Defective rear RH wheel speed sensor
- No signals from wheel speed sensor and tooth wheel
- Too large air gap between wheel speed sensor and tooth wheel
- Different number of teeth in tooth wheel
Sensor
Action
- Check the wheel speed sensor connector
Monitoring
- Check the HECU connector
- Check air gap and tooth wheel mounting (Specified air gap: 0.309 ~ 0.958 mm)
- Check the number of teeth (48) in tooth wheel
Wheel speed sensor
1. C1041 (5041)
Cause
- Defective rear LH wheel speed sensor
- Short or poor contact wire to sensor
Action
- Check the wheel speed sensor connector
- Check the HECU connector
- Check the harness connection
2. C1042 (5042)
Cause
- Defective rear LH wheel speed sensor
- No signals from wheel speed sensor and tooth wheel
- Too large air gap between wheel speed sensor and tooth wheel
- Different number of teeth in tooth wheel
Action
- Check the wheel speed sensor connector and HECU connector
- Check air gap and tooth wheel mounting (Specified air gap: 0.309 ~ 0.958 mm)
- Check the number of teeth (48) in tooth wheel
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
Trouble Code
C1031 (5031)
Rear RH
C1032 (5032)
Rear LH
C1041 (5041)
C1042 (5042)
Descriptions
Wheel speed sensor
rear left-electrical
Wheel speed sensor
rear left-other
Wheel speed sensor
rear left-electrical
Wheel speed sensor
rear left-other
49
4890
System
ABS ESP
O O
O O
ABS/ESP SYSTEM
