5. The modes available AQS function:
1) AUTO mode
2) Fan speed control dial operation mode
3) A/C switch operation. At this mode, the AQS system operates according to the AQS switch operation.
NOTICE
• If the ignition switch is turned off with AQS ON, the AQS
is turned on when turning the ignition switch on again.
AUTO A/C ON (TEMP switch ON)
Adjusting fan speed control dial
Mode change (MODE switch)
6. The AQS is turned off,
1) When pressing the defroster switch
2) When pressing the recirculation mode switch
AIR CONDITIONING SYSTEM
KYRON SM - 2005.09
Pressing AQS
AUTO A/C ON (TEMP switch ON)
switch
AQS ON
Adjusting fan speed control dial
Pressing AQS
switch
Mode change (MODE switch)
AQS OFF
Memory return
(when system OFF)
