19
7810
5. Open the tailgate, unscrew the connector and mounting bolts (10 mm - 2EA) and then remove the wiper motor.
Rear Wiper Assembly
Passenger seat wiper blade assembly
Splasher ring-tailgate wiper
Mounting nut
Spacer ring-tailgate wiper
Front
Rear wiper motor and linkage assembly
Inside Rear
WIPER & WASHER SYSTEM
CHANGED BY
EFFECTIVE DATE KYRON SM - 2005.09
AFFECTED VIN
