Floor Air Duct
Preceding Work: 1. Disconnect the negative battery cable and remove the center fascia panel and center lower
panel.
2. Remove the center console assembly.
Floor Air Duct
1. Unscrew two center mounting screws in floor air duct.
2. Unscrew the mounting bolts and remove the air duct.
Vehicle with Foot Parking Brake
Mounting Screws
Lower Air Duct Assembly
Vehicle with Hand Parking Brake
