Condenser Assembly

Preceding Work:
1. Collect the A/C refrigerant.
2. Remove the front bumper assembly.
3. Drain the coolant
(Store the collected A/C refrigerant and coolant
into the designated container.)
Removal and Installation
1. Remove the air cleaner duct. (Unscrew two mount-
ing screws, release the cleaner hose clamp and
remove the duct.)
2. Remove the pipes from the radiator oil cooler for automatic transmission.
Installation Notice
Tightening torque
AIR CONDITIONING SYSTEM
KYRON SM - 2005.09
25 ~ 35 Nm
