Center/Luggage Room Lamp
Preceding Work: Disconnect the negative battery cable.
1. Remove the lamp cover.
NOTICE
• Use the slot around the cover when replacing the
lamp (bulb).
Slot Slot
2. Unscrew the lamp mounting screws (luggage room lamp) and nuts (center room lamp).
Center room lamp Luggage room lamp
3. Disconnect the connector and remove the lamp assembly.
