2. SYSTEM LAYOUT

Power steering
pump assembly
Feed pipe nut
Tightening torque:
40 ~ 50 Nm
Power steering return pipe
With SSPS
Power steering
gear box
POWER STEERING SYSTEM
KYRON SM - 2005.09
Power steering high
pressure hose and pipe
Gear box pipe
Return hose and pipe
Power steering high pressure
hose and pipe
SSPS Solenoid Valve
* cannot be replaced
Steering gear box
mounting bracket bolts
(14 mm - 2EA): 30 ~ 40 Nm
Power steering gear
box assembly
Power steering gear
box pipe
Tie rod end
