Removal and Installation
1. Remove the left center fascia panel and unscrew three
mounting screws on the hazard switch bezel
assembly.
2. Remove four instrument panel mounting screws.
3. Disconnect the outside mirror switch bezel connector and remove the meter cluster panel assembly.
NOTICE
• Be careful not to damage the another components during removal procedures.
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
NOTE
• Remove the bottom of the center fascia panel first.
• For details, refer to "Removal and Installation of
Instrument Panel".
