5. TROUBLE DIAGNOSIS

Symptom
Noise
(during driving straight
ahead)
Oil leakage
Noise (during turning)
Heating
AXLE
KYRON SM - 2005.09
Cause
Lack of oil
Low viscosity of oil
Inferior oil
Excessive backlash of ring gears
Worn or damaged tooth of ring and pinion gear
Worn or damaged drive pinion bearing
Wear of side bearing and side gear spline
Bending of axle housing
Distortion of differential case
Wear of pinion shaft
Incorrect drive pinion preload
Incorrect contact of ring gear and pinion
Excessive oil
Fault seal of carrier contact surface
Axle housing crack
Worn or damaged oil seal
Worn or damaged tooth of pinion or side gear
Wear of pinion shaft
Excessive backlash of pinion gear and side gear
Excessive end-play of axle shaft
Incorrect contact of side gear and differential case
Axle housing crack
Distortion or poor installation of drive pinion oil seal
Damaged or torn drive pinion oil seal
Loosened bearing collar
Worn or damaged universal joint
Worn or damaged axle shaft bearing
Lack of oil
Insufficient backlash of gears
Excessive preload of bearing
Action
Replenish
Replace
Replace
Adjust
Replace
Replace
Replace
Replace
Replace
Replace
Adjust
Reassembly
Adjust
Correct
Replace
Replace
Replace
Replace
Replace
Adjust
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replenish
Adjust
Adjust
