Auerswald COMpact 5200 Advanced Information page 37

2nd Network Interface
• At the connections LAN 1 and LAN 2 an IAD is connected in each
case
• The internal and external VoIP telephony are realised via LAN 2.
• The data transmission is realised via LAN 1.
Proceed as follows for configuration:
• Configuring an IAD.
- Using the Configuration Manager (page Administration >
Passerelle Internet VoIP)
• Selecting the used Internet access for the VoIP provider.
Using the Configuration Manager (page Réseaux publics > VoIP
-
> Fournisseur > Configurer)
• Selecting the network interface of the VoIP registrar.
- Using the Configuration Manager (page Administration >
Configuration VoIP)
•
Configuring DHCP settings for the 2
- Using the Configuration Manager (page Administration >
Configuration IP)
COMpact 5200/5200R/5500R - Firmware V7.4A - Advanced Information V08 06/2019
nd
network interface.
- 37 -
