Management Announcement Output
Freely selectable name. This name is used to identify the announcement
output within the PBX and the connected system phones. The name can
also be transferred to the VoIP end devices via LDAP server.
Module Port
Module and port to which the device that can be used as announcement
output (e. g. an a/b-Audiobox at a loudspeaker system) is connected.
Configurer
Opens the configuration of the announcement output.
Relais
Requirements:
• Relay/actuator (optional, see Technical Data in the Instructions)
A relay with the operating mode Parler, which is enabled during the
loudspeaker announcement, is assigned to the alarm. This relay can be
used to switch over the loudspeaker area of the loudspeaker system, for
example, or to switch on an additional lamp which draws attention to the
announcement.
If suitable relays have already been configured on the page
Périphériques > Relais (actionneurs), a list field will appear now. Select
one of the existing relays and click .
If you do not want to use any of the existing relays, select New relays in
the list field ( cancels the operation). Enter a freely selectable name for
the relay and click Ok.
