IP Switch Relay

Proceed as follows:

Using the Configuration Manager (page Périphériques > Relais

(actionneurs) > Configurer)

Configuration du relais

Select the relay.

Le système est maître

The available relays on an IP switch relay can also be toggled without

affecting the PBX. In some situations, e.g. if the PBX is switched off at the

switching point, the PBX cannot identify the state of the relay.

The PBX restores the relay to the last state it was able to identify after it is

Commande d'arrêt

Requirements:

the relay must have been set up

The PBX will switch off relays with the operating modes Light, Door

opener, Alarm and PC relay after the specified switching duration.

Note: When switched off, the hold time of the relay is used. The PBX

does not actively switch off the relay.

COMpact 5200/5200R/5500R - Firmware V7.4A - Advanced Information V08 06/2019
