Switch input+Relay

Switch input+Relay
Relais
Requirements:
• Relay/actuator (optional, see Technical Data in the Instructions)
• Created device (e. g. door terminal, IP switch relay) whose part the
relay is
A relay with the operating mode Alarme, which is used to enable e. g. a
siren when the alarm has been triggered, is assigned to the alarm.
In the list field, select one of the existing relays and click
If you do not want to use any of the existing relays, select Nouveau relais
in the list field (
for the relay and select the device as whose part the relay is to be created
in the Ajouter à list field. Click Ok.
Note: The relay remains part of this other device (e. g. door terminal,
IP switch relay) in the configuration of the PBX, but takes over the
selected alarm function for the alarm.
Note: For a detailed description of the operating modes, refer to
Operating Modes.
COMpact 5200/5200R/5500R - Firmware V7.4A - Advanced Information V08 06/2019
cancels the operation). Enter a freely selectable name
