Relay Operating Modes
Light
The relay is assigned to a door terminal.
The PBX switches on the relay as soon as an internal subscriber triggers
light switching for the assigned door terminal.
Alternatively, switching can be triggered manually by phone.
The PBX switches off the relay after the defined switching duration.
Possible use:
• Switching a staircase light
Alarm
The relay is assigned to an alarm.
The PBX switches on the relay as soon as the assigned alarm is triggered.
Alternatively, switching can be triggered manually by phone.
The PBX switches off the relay after the defined switching duration.
Alternatively, switching off can be triggered by phone after the alarm has
been acknowledged.
Possible use:
• Switching a siren or an indicator light
Music on hold
The relay is assigned to music on hold.
The PBX switches on the relay when a call is to be transferred or in
the case of a query call, when a communication partner waiting in the
background is to hear music on hold.
The PBX switches off the relay after the defined switching duration.
