Switch Input+Relay - Auerswald COMpact 5200 Advanced Information

Switch Input+Relay

Switch Input+Relay
Proceed as follows:
• Separately for switch inputs
• Using the Configuration Manager (page Périphériques > Alarmes >
Entrée >
Requirements:
• Created switch input
Configuration de l'entrée
Select the switch input to be configured.
Séquence DTMF
Requirements:
• Created switch input for an analogue device
Specifies which DTMF sequence the PBX detects, for example,as the
actuation of a door bell button to then trigger an alarm or a door call. For
information about which DTMF sequences the connected device sends,
see the manual of the device in question.
Note: The DTMF sequence usually is the phone number assigned to
the door bell button within the door terminal.
Invite SIP
Requirements:
• Created switch input for a VoIP device
COMpact 5200/5200R/5500R - Firmware V7.4A - Advanced Information V08 06/2019
)
- 923 -
