Field Service Ver. 2.1 Feb. 2012
3.2

Periodical replacement parts list

• To ensure that the machine produces good copies and to extend its service life, it is rec-
ommended that the maintenance jobs described in this schedule be carried out as
instructed.
• Replace with reference to the numeric values displayed on the total counter, the life
counter or the messages displayed on the control panel.
• Maintenance conditions are based on the case of A4 or 8
low power mode OFF.
*Standard mode bizhub C360
bizhub C280
bizhub C220
3.2.1

Main body

Classification Parts name
Paper feed Tray 1 pick-up roller
section
Tray 1 feed roller
Tray 1 separation roller
2
assy
Tray 2 pick-up roller
Tray 2 feed roller
Tray 2 separation roller
2
assy
Manual bypass tray feed
roller
Manual bypass tray
separation roller assy
Processing Toner cartridge/Y,M,C
section *1
Toner cartridge/K *1
Drum unit/Y,M,C *1
Drum unit/K *1
Developing unit/Y,M,C
Developing unit/K
Ozone filter
Waste toner box *1
3. PERIODICAL MAINTENANCE ITEMS
Color
4 pages per job 4 pages per job
3 pages per job 3 pages per job
2 pages per job 2 pages per job
Parts No. Qt.
A00J 5636 XX 1
A00J 5636 XX 1
A00J 5636 XX 1
A00J 5636 XX 1
A00J 5636 XX 1
A00J 5636 XX 1
A02E 5947 XX 1
4034 0151 XX 1
⎯
1
⎯
1
⎯
1
⎯
1
⎯
1
⎯
1
A02E R727 XX 1 C360/C280:300,000
A162 WY1 1
1 / x 11, standard mode and
2
B/W
Descrip
Replacing cycle
tions
300,000 *2 *4
300,000 *2
300,000 *2
300,000 *2 *4
300,000 *2
300,000 *2
200,000 *2 *4
200,000 *2
26,000
29,000
C360:90,000 *3
C280:75,000 *3
C220:55,000 *3
C360:120,000 *3
C280:100,000 *3
C220:70,000 *3
114,000 *3
570,000 *3
*5
*3
C220:260,000 *3
(45,000) *6
Ref.
page
P.39
P.41
P.39
P.43
P.43
P.43
P.43
P.45
P.31
P.26
P.30
P.25
P.37
19
