1 Air vents
2 High speed monitoring for the hoists
3 Windscreen wiper on/off
4 Roof window wiper on/off
5 Windscreen washing system
6 High-speed monitoring for derricking gear / tele-
scoping mechanism
7 Spotlight sockets on/off
8 Slewable spotlight on/off
9 Air traffic control light/camera on/off/Camera
10 Swing the spotlight
11 Flame start system monitoring
12 Voltage monitoring warning
13 Carrier ignition monitoring
14 Rotating beacons on/off
15 Houselock on/off
16 Set idling speed
17 Carrier ignition on/off
18 Air-conditioning system
19 Ignition lock
20 Cigarette lighter (24 volts)
1)
Additional equipment
2)
Symbol according to execution
1)
1)
1)
1)
1)
1)
