Overview
1.5 Technical data
Auxiliary hoist
Main boom
Counterweight
parts
1 - 12
Name
Complete auxiliary hoist
Rigging frame
Name
Complete main boom
Name
7 t base plate
each 9.5 t plate
9.5 t section with cutouts
each 9 t block
each 10 t block
1) There may be deviations of up to ± 3% due to the manufacturing
procedure.
The stability of the crane rigged with the counterweight sections delivered
has been tested.
Length x width x height
in m (ft)
1.15 x 1.90 x 0.80
(3.77 x 6.23 x 2.62)
1.43 x 2.17 x 0.55
(4.69 x 7.12 x 1.80)
Length x width x
height in m (ft)
16.0 x 2.0 x 2.0
(52.5 x 6.6 x 6.6)
Length x width x
height in m (ft)
2.99 x 2.42 x 1.25
(9.81 x 7.94 x 4.10)
2.99 x 2.40 x 0.29
(9.81 x 7.87 x 0.95)
2.99 x 2.40 x 0.24
(9.81 x 7.87 x 0.79)
1.39 x 1.44 x 1.24
(4.56 x 4.72 x 4.07
0.97 x 1.97 x 1.30
(3.18 x 6.46 x 4.27
3 112 xxx en
Weight
in kg (lbs)
2,000
(4,410)
352
(776)
Weight in kg (lbs)
27,500
(60,630)
Weight
1)
in kg (lbs)
7,000
(15,440)
9,500
(20,950)
9,500
(20,950)
9,000
(19,850)
10,000
(22,050)
