Quick Links

ADTRAN OPERATING SYSTEM (AOS)
Command Reference Guide
AOS Version 11.1
NetVanta 1000R Series Products
November 2005
61200510L1-35E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1000R Series and is the answer not in the manual?

Questions and answers

Related Manuals for ADTRAN 1000R Series

Summary of Contents for ADTRAN 1000R Series

  • Page 1 ADTRAN OPERATING SYSTEM (AOS) Command Reference Guide AOS Version 11.1 NetVanta 1000R Series Products November 2005 61200510L1-35E...

  • Page 2: Software Licensing Agreement

    To the Holder of this Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.

  • Page 3: Warranty And Customer Service

    Command Reference Guide Warranty and Customer Service ADTRAN will repair and return this product within the warranty period if it does not meet its published specifications or fails while in service. Warranty information can be found at www.adtran.com. (Click on Warranty and Repair Information under Support.)
  • Page 4 Your reseller should serve as the first point of contact for support. If additional pre-sales support is needed, the ADTRAN Support website provides a variety of support services such as a searchable knowledge base, latest product documentation, application briefs, case studies, and a link to submit a question to an Applications Engineer.
  • Page 5 Territory Manager or the Enterprise Training Coordinator. Export Statement An Export License is required if an ADTRAN product is sold to a Government Entity outside of the EU+8 (Austria, Australia, Belgium, Czech Republic, Denmark, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Japan, Luxembourg, Netherlands, New Zealand, Norway, Poland, Portugal, Spain, Sweden, Switzerland and the United Kingdom).

  • Page 6: Table Of Contents

    AS Path List Command Set ........... . 1273 61200510L1-35E Table of Contents Copyright © 2005 ADTRAN Table of Contents...
  • Page 7 Index ................1365 61200510L1-35E Copyright © 2005 ADTRAN Table of Contents...

  • Page 8: Accessing The Cli From Your Pc

    For a list of all of the commands available through the CLI, see 61950860L1-35L (All Products). If you are new to the ADTRAN Operating System’s (AOS) Command Line Interface (CLI), take a few moments to review the information provided in the section which follows (CLI Introduction).

  • Page 9: Understanding Command Security Levels

    Understanding Configuration Modes The ADTRAN CLI has four configuration modes to organize the configuration commands – Global, Line, Router, and Interface. Each configuration mode supports a set of commands specific to the configurable parameters for the mode.

  • Page 10: Using Cli Shortcuts

    For example: >enable #config term (config)#int eth 0/1 Using CLI Shortcuts The ADTRAN CLI provides several shortcuts which help you configure your AOS product more easily. See the following table for descriptions. Shortcut Description Up arrow key To re-display a previously entered command, use the up arrow key. Continuing to press the up arrow key cycles through all commands entered starting with the most recent command.
  • Page 11 Obtain syntax help for a specific command by entering the command, a space, and then a question mark (?). The ADTRAN CLI displays the range of values and a brief description of the next parameter expected for that particular command. For...

  • Page 12: Performing Common Cli Functions

    For information on specific debug commands, refer to the section on page 36 To turn off any active debug commands, enter this command. Copyright © 2005 ADTRAN Enable Mode Command...

  • Page 13: Understanding Cli Error Messages

    The error in command entry is located where the caret (^) mark appears. Enter a question mark at the prompt. The system will display a list of applicable commands or will give syntax information for the entry. Copyright © 2005 ADTRAN Understanding CLI Error Messages Using...

  • Page 14: Command Descriptions

    Command Reference Guide COMMAND DESCRIPTIONS This portion of the guide provides a detailed listing of all available commands for the ADTRAN OS CLI (organized by command set). Each command listing contains pertinent information including the default value, a description of all sub-command parameters, functional notes for using the command, and a brief technology review.
  • Page 15 1226 on page 1230 on page 1239 on page 1254 on page 1276 on page 1282 on page 1298 on page 1301 on page 1316 on page 1345 on page 1351 on page 1363 Copyright © 2005 ADTRAN Command Descriptions...

  • Page 16: Basic Mode Command Set

    18 ping <address> on page 19 show clock on page 21 show snmp on page 22 show version on page 23 telnet <address> on page 24 traceroute <address> on page 25 61200510L1-35E Copyright © 2005 ADTRAN Basic Mode Command Set...
  • Page 17 Usage Examples The following example enters the Enable Command mode and defines an Enable Command mode password: >enable #configure terminal (config)#enable password ADTRAN At the next login, the following sequence must occur: >enable Password: ****** 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 18 Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example shows the logout command being executed in the Basic mode: >logout Session now available Press RETURN to get started. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 19 The following is a list of output messages from the ping command: Success Destination Host Unreachable Invalid Host Address TTL Expired in Transit Unknown Host Request Timed Out 61200510L1-35E Copyright © 2005 ADTRAN Basic Mode Command Set...
  • Page 20 '*' = Request timed out '-' = Destination host unreachable 'x' = TTL expired in transit Pinging 192.168.0.30 with 100 bytes of data: !!!!! Success rate is 100 percent (5/5) round-trip min/avg/max = 19/20.8/25 ms 61200510L1-35E Copyright © 2005 ADTRAN Basic Mode Command Set...

  • Page 21: Show Clock

    Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example displays the current time and data from the system clock: >show clock 23:35:07 UTC Tue Aug 20 2002 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 22: Show Snmp

    Chassis: Chassis ID Contact: Customer Service 0 Rx SNMP packets 0 Bad community names 0 Bad community uses 0 Bad versions 0 Silent drops 0 Proxy drops 0 ASN parse errors 61200510L1-35E Copyright © 2005 ADTRAN Basic Mode Command Set...

  • Page 23: Show Version

    Upgrade key: de76efcfeb4c8eeb6901188475dd0917 Boot ROM version 03.00.18 Checksum: 7A3D built on: Fri Nov 08 13:12:25 2002 Copyright (c) 1999-2002 ADTRAN Inc. Serial number C14C6308 UNIT_2 uptime is 0 days 4 hours 59 minutes 43 seconds System returned to ROM by Warm Start Current system image file is "030018adv.biz"...
  • Page 24 Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example opens a Telnet session with a remote system (10.200.4.15): >telnet 10.200.4.15 User Access Login Password: 61200510L1-35E Copyright © 2005 ADTRAN Basic Mode Command Set...
  • Page 25 The following example performs a traceroute on the IP address 192.168.0.1: #traceroute 192.168.0.1 Type CTRL+C to abort. Tracing route to 192.168.0.1 over a maximum of 30 hops 22ms 20ms 20ms 192.168.0.65 23ms 20ms 20ms 192.168.0.1 61200510L1-35E Copyright © 2005 ADTRAN Basic Mode Command Set...

  • Page 26: Common Commands

    27 cross-connect <#> <from interface> <slot/port> <tdm-group#> <to interface> <slot/port> on page 28 description <text> on page 31 on page 32 on page 33 exit on page 34 shutdown on page 35 61200510L1-35E Copyright © 2005 ADTRAN Common Commands...
  • Page 27 The following example defines a unique character string for the T1 interface: (config)#interface t1 1/1 (config-t1 1/1)#alias “CIRCUIT_ID_23-908-8887-401” Technology Review Please refer to RFC2863 for more detailed information on the ifAlias display string. 61200510L1-35E Copyright © 2005 ADTRAN Common Commands...
  • Page 28 Command was expanded to include the E1 interface. Functional Notes Cross-connects provide the mechanism for connecting a configured virtual (layer 2) endpoint with a physical (layer 1) interface. Supported layer 2 protocols include Frame Relay and point-to-point protocol (PPP). 61200510L1-35E Copyright © 2005 ADTRAN Common Commands...
  • Page 29 For example, the following creates a Frame Relay interface labeled 7 and sets the signaling method to ansi. (config)# interface frame-relay 7 (config-fr 7)# frame-relay lmi-type ansi 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 30 (labeled 5) to make an association between the Frame Relay virtual interface (fr 7) and the TDM group configured on interface t1 1/1 (tdm-group 9). (config)# cross-connect 5 t1 1/1 9 fr 7 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 31 Applies to all AOS products. Command History Release 1.1 Command was introduced. Usage Examples The following example enters comment information using the description command: (config)#interface t1 1/1 (config-t1 1/1)#description This is the Dallas office T1 61200510L1-35E Copyright © 2005 ADTRAN Common Commands...
  • Page 32 Polling interval is 10 seconds full inquiry interval is 6 polling intervals Output queue: 0/0 (highest/drops) 0 packets input 0 bytes 0 pkts discarded 0 error pkts 0 unknown protocol pkts 0 packets output 0 bytes 0 tx pkts discarded 0 tx error pkts 61200510L1-35E Copyright © 2005 ADTRAN Common Commands...
  • Page 33 Applies to all AOS products. Command History Release 1.1 Command was introduced. Usage Examples The following example shows the end command being executed in the T1 Interface Configuration mode: (config-t1 1/1)#end #- Enable Security mode command prompt 61200510L1-35E Copyright © 2005 ADTRAN Common Commands...
  • Page 34 Applies to all AOS products. Command History Release 1.1 Command was introduced. Usage Examples The following example shows the exit command being executed in the Global Configuration mode: (config)#exit #- Enable Security mode command prompt 61200510L1-35E Copyright © 2005 ADTRAN Common Commands...
  • Page 35 Applies to all interface mode command sets. Applicable Platforms Applies to all AOS products. Command History Release 1.1 Command was introduced. Usage Examples The following example administratively disables the modem interface: (config)#interface modem 1/2 (config-modem 1/2)#shutdown 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 36: Enable Mode Command Set

    156 reload [cancel | in <delay>] 61200510L1-35E on page 82 on page 87 on page 90 on page 92 on page 147 on page 150 on page 157 Copyright © 2005 ADTRAN Enable Mode Command Set on page 86...
  • Page 37 320 vlan database on page 321 wall <message> on page 322 write [dynvoice-config | erase | memory | network | terminal] 61200510L1-35E on page 317 on page 319 on page 323 Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 38 This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example clears all counters for the access list labeled MatchAll: >enable #clear access-list MatchAll 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 39: Clear Arp-Cache

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example removes all dynamic entries from the ARP cache: >enable #clear arp-cache 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 40 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example removes the entry for 10.200.4.56 from the ARP cache: >enable #clear arp-entry 10.200.4.56 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 41: Clear Bridge

    This command applies to the NetVanta 300, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example clears all counters for bridge group 17: >enable #clear bridge 17 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 42 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example clears the maximum-used buffer statics: >enable #clear buffers max-used 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 43 Command was introduced. Release 9.1 Command was expanded to include HDLC and tunnel interfaces. Usage Examples The following example clears all counters associated with the Ethernet 0/1 interface: >enable #clear counters ethernet 0/1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 44 Specifies a valid interface ID to clear (e.g., 1 for port channel 1). Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced.
  • Page 45 This command applies to the NetVanta 300, 1000, 1000R, and 2000 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example resets the counters on VLAN interface 7: >enable #clear counters vlan 7 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 46 Release 4.1 Command was introduced. Usage Examples The following example clears the entire database of IKE SAs (including the active associations): >enable #clear crypto ike sa 61200510L1-35E on page 367 for more information. Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 47: Clear Crypto Ipsec Sa

    No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 4.1 Command was introduced. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 48 > enable #clear crypto ipsec sa The following example clears the IPSec SA used for ESP traffic with the SPI of 300 to IP address 63.97.45.57: > enable #clear crypto ipsec sa entry 63.97.45.57 esp 300 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 49 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 6.1 Command was introduced. Usage Examples The following example clears the entire database of IKE SAs (including the active associations): >enable #clear dump-core 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 50: Clear Event-History

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example clears all local event-history messages: >enable #clear event-history 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 51 ? for a complete list of applicable interfaces. Default Values There are no default settings for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced.
  • Page 52 This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 10.1 Command was introduced. Usage Examples The following example clears all dynamic hostnames: >enable #clear host * 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 53 Currently, all of the peer's routes are stored permanently, even if they are filtered by a prefix list. The command causes the peer's routes to be reprocessed with any new parameters. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 54 Command Reference Guide Enable Mode Command Set Usage Examples The following example causes a hard reset with peers with an AS number of 101: >enable #clear ip bgp 101 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 55 This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example removes all entries from the cache table: >enable #clear ip cache 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 56 DHCP client (i.e., most often a PC). Clearing a binding allows the unit to offer that IP address again, should a request be made for one. Usage Examples The following example clears a DHCP server binding for the IP address 125.25.47.4: >enable #clear ip dchp-server binding 125.25.47.4 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 57 Interfaces that are statically joined are not cleared: #show ip igmp groups IGMP Connected Group Membership Group Address Interface Uptime Expires Last Reporter 172.0.1.50 Loopback100 01:22:59 00:02:46 172.23.23.1 172.1.1.1 Ethernet0/1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 58 This version of the command clears all dynamic groups that have the specified output interface (Ethernet 0/1): #clear ip igmp group ethernet 0/1 This version of the command clears the specified group on all interfaces where it is dynamically registered: #clear ip igmp group 172.1.1.1 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 59 This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example resets the OSPF process: >enable #clear ip ospf process 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 60 GRE; decimal for all other protocols). Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 61 Usage Examples The following example clears the Telnet association (TCP port 23) for policy class pclass1 with source IP address 192.22.71.50 and destination 192.22.71.130: >enable #clear ip policy-sessions pclass1 tcp 192.22.71.50 23 192.22.71.130 23 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 62 Usage Examples The following example clears statistical counters for all policy classes: >enable #clear ip policy-stats The following example clears statistical counters for the policy class MatchALL: >enable #clear ip policy-stats MatchALL 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 63: Clear Ip Prefix-List

    Command History Release 8.1 Command was introduced. Usage Examples The following example clears the hit count statistics for prefix list test: >enable #clear ip prefix-list test 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set on page 237 for more...
  • Page 64 This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example removes all learned routes from the route table: >enable #clear ip route ** 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 65 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example resets all LLDP counters: >enable #clear lldp counters 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 66 Total Access 900 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example resets the counters on PPP interface 1: >enable #clear lldp counters interface ppp 1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 67: Clear Lldp Neighbors

    Usage Examples The following example clears LLDP neighbor Switch_1 from the Ethernet interface 0/7: >enable #clear lldp neighbors LLDP: Deleted neighbor “Switch_1” on interface eth 0/7 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 68 ? for a complete list of applicable interfaces. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced.

  • Page 69: Clear Port-Security

    ? or clear port-security dynamic interface ? for a complete list of applicable interfaces. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples...
  • Page 70 ? for a complete list of applicable interfaces. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples The following command clears the violation count associated with the Ethernet interface 0/1: >enable...
  • Page 71 This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example ends the current PPPoE client session for ppp 1: >enable #clear pppoe 1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 72: Clear Processes Cpu Max

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example resets the CPU maximum usage statistics: >enable #clear process cpu max 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 73: Clear Qos Map

    No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 6.1 Command was introduced. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 74 #clear qos map priority 10 The following example clears QoS statistics for a specified interface: #clear qos map interface frame-relay 1 The clear counters command clears ALL interface statistics (including QoS map interface statistics). 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 75 This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example clears all route map counters: >enable #clear route-map counters 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 76 This command applies to the NetVanta 300, 1000, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 6.1 Command was introduced. Usage Examples The following example clears the spanning tree counters for Ethernet 0/10: >enable #clear spanning-tree counters interface eth 0/10 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 77 Usage Examples The following example re-initiates the protocol migration process on Ethernet interface 0/3: >enable #clear spanning-tree detected-protocols interface ethernet 0/3 The following example re-initiates the protocol migration process on all interfaces: >enable #clear spanning-tree detected-protocols 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 78: Clear Tacacs+ Statistics

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example clears all TACACS+ protocol statistics: >enable #clear tacacs+ statistics 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 79 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example detaches the console 1 user: >enable #clear user console 1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 80: Clock Auto-Correct-Dst

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 6.1 Command was introduced. Usage Examples The following example allows for automatic DST correction: >enable #clock auto-correct-dst 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 81: Clock No-Auto-Correct-Dst

    Many time zones include an automatic one-hour correction for daylight saving time at the appropriate time. You may override it at your location using this command. Usage Examples The following example overrides the one-hour offset for DST: >enable #clock no-auto-correct-dst 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 82: Clock Set

    Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example sets the system software clock for 3:42 pm, August 22 2004: >enable #clock set 15:42:00 22 Au 2004 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 83: Clock Timezone

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 6.1 Command was introduced. Release 11.1 Command was expanded to include clock timezone 0. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 84 -6-Central-America clock timezone -6-Central-Time clock timezone -6-Mexico-City clock timezone -6-Saskatchewan clock timezone -7-Arizona clock timezone -7-Mountain-Time clock timezone -8 clock timezone -9 clock timezone 0 clock timezone GMT-Casablanca clock timezone GMT-Dublin Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 85 Command Reference Guide Enable Mode Command Set Usage Examples The following example sets the timezone for Santiago, Chile. >enable #clock timezone -4-Santiago 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 86 Command History Release 1.1 Command was introduced. Usage Examples The following example enters the Global Configuration mode from the Enable mode: >enable #configure terminal (config)# 61200510L1-35E on page 324 Copyright © 2005 ADTRAN Enable Mode Command Set for more information.
  • Page 87 The following example creates a backup copy of the startup configuration file (and places in FLASH memory): >enable #copy startup-config backup.bak The following example copies the current running-configuration file to the startup configuration file located in NVRAM: >enable #copy running-config startup-config 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 88 Use the dir command to see a list of files in the root directory. Usage Examples The following example copies the console input into the file config (located in the AOS root directory): >enable #copy console config 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 89 Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example copies the contents of the unit’s flash memory to a TFTP server: >enable #copy flash tftp 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 90: Copy Interface

    This command applies to the NetVanta 300, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example upgrades the ADSL interface with the firmware file configfile: >enable #copy configfile interface adsl 0/1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 91 The following example copies myfile.biz from the TFTP server (10.200.2.4) to flash memory and labels it newfile.biz: >enable #copy tftp flash Address of remote host?10.200.2.4 Source filename myfile.biz Destination filename newfile.biz Initiating TFTP transfer... Received 45647 bytes. Transfer Complete! 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 92 HyperTerminal, you will now select Transfer > Send File and browse to the file you wish to copy. Once the transfer is complete, information similar to the following is displayed: Received 231424 bytes. Transfer complete. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 93: Debug Aaa

    AAA: New Session on portal 'TELNET 0 (172.22.12.60:4867)'. AAA: No list mapped to 'TELNET 0'. Using 'default'. AAA: Attempting authentication (username/password). AAA: RADIUS authentication failed. AAA: Authentication failed. AAA: Closing Session on portal 'TELNET 0 (172.22.12.60:4867)'. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 94 The debug access-list command provides debug messages to aid in troubleshooting access list issues. Usage Examples The following example activates debug messages for the access list labeled MatchAll: >enable #debug access-list MatchAll 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 95: Debug Atm Events

    Applicable Platforms This command applies to the NetVanta 300, 1000R, 3000, and 4000 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example activates ATM event messages: >enable #debug atm events 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 96 This command applies to the NetVanta 300, 1000R, 3000, and 4000 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example activates ATM OAM debug messages for VCD 1: >enable #debug atm oam 1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 97: Debug Atm Packet

    This command applies to the NetVanta 300, 1000R, 3000, and 4000 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example activates debug ATM packet debug messages on ATM port 1: >enable #debug atm packet interface atm 1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 98: Debug Auto-Config

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The example activates debug messages associated with auto-config events: >enable #debug auto-config 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 99: Debug Bridge

    This command applies to the NetVanta 300, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example activates bridge debug messages: >enable #debug bridge 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 100 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example activates debug messages for the chat interface 0/1: >enable #debug chat-interfaces 0/1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 101 This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 4.1 Command was introduced. Release 6.1 Debug pki command introduced. Usage Examples The following example activates the IPSec debug messages: >enable #debug crypto ipsec 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 102: Debug Data-Call

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example activates debug messages associated with data call errors and events: >enable #debug data-call 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 103: Debug Demand-Routing

    This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example activates demand routing error and event messages: >enable #debug demand-routing 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 104: Debug Dial-Backup

    Release 1.1 Command was introduced. Release 2.1 Additional debug messages were implemented for dial-backup operation to ADTRAN’s IQ and Express Series products. Functional Notes The debug dial-backup command activates debug messages to aid in the troubleshooting of dial-backup links. Usage Examples The following example activates debug messages for dial-backup operation: >enable...

  • Page 105: Debug Dialup-Interfaces

    These messages also give information on why certain calls are dropped or rejected. It is beneficial to use this command when troubleshooting dial backup (in addition to the debug dial-backup command). Usage Examples The following example activates the debug messages for dialup interfaces: >enable #debug dialup-interfaces 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 106 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example activates dynamic DNS debug messages: >enable #debug dynamic-dns verbose 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 107: Debug Firewall

    The debug firewall command activates debug messages to provide real-time information about the AOS stateful inspection firewall operation. Usage Examples The following example activates the debug messages for the AOS stateful inspection firewall: >enable #debug firewall 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 108 The debug frame-relay command activates debug messages to aid in the troubleshooting of Frame Relay links. Usage Examples The following example activates all possible debug messages associated with Frame Relay operation: >enable #debug frame-relay events #debug frame-relay llc2 #debug frame-relay lmi 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 109 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 9.1 Command was introduced. Usage Examples The following example activates debug messages associated with multilink operation for all Frame Relay interfaces: >enable #debug frame-relay multilink 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 110: Debug Gvrp Bpdus

    Syntax Description No subcommands. Default Values By default, all debug messages in the AOS are disabled. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Functional Notes With GVRP enabled on many ports, this command can produce a lot of output. To see these messages debug gvrp interface <interface>...
  • Page 111 Displays debug messages showing all GVRP-related VLAN changes occurring on the interface. Default Values By default, all debug messages in the AOS are disabled. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples...
  • Page 112 VLAN only. Range is 1 to 4094. Default Values By default, all debug messages in the AOS are disabled. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced.
  • Page 113 This command applies to the 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 9.1 Command was introduced. Usage Examples The following example activates detailed debug messages associated with the HDLC interface: >enable #debug hdlc verbose 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 114: Debug Interface

    The debug interface command activates debug messages to aid in the troubleshooting of physical interfaces. Usage Examples The following example activates all possible debug messages associated with the Ethernet port: >enable #debug interface ethernet 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 115: Debug Interface Adsl Events

    This command applies to the NetVanta 300, 1000R, 3000, 4000, and 5000 Series units. Command History Release 9.1 Command was introduced. Usage Examples The following example activates debug messages for ADSL events: >enable #debug interface adsl events 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 116 Usage Examples The following example enables debug messages on general outbound BGP messages and events: >enable #debug ip bgp out #07:42:39: BGP OUT 10.15.240.1[2]: Transmitting msg, type=UPDATE (2), len=142 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 117: Debug Ip Dhcp-Client

    AOS. The AOS DHCP client capability allows interfaces to dynamically obtain an IP address from a network DHCP server. Usage Examples The following example activates debug messages associated with DHCP client activity: >enable #debug ip dhcp-client 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 118: Debug Ip Dhcp-Server

    AOS. The AOS DHCP server capability allows the AOS to dynamically assign IP addresses to hosts on the network. Usage Examples The following example activates debug messages associated with DHCP server activity: >enable #debug ip dhcp-server 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 119: Debug Ip Dns-Client

    The debug ip dns-client command activates debug messages to provide information on DNS client activity in the AOS. The IP DNS capability allows for DNS-based host translation (name-to-address). Usage Examples The following example activates debug messages associated with DNS client activity: >enable #debug ip dns-client 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 120: Debug Ip Dns-Proxy

    The debug ip dns-proxy command activates debug messages to provide information on DNS proxy activity in the AOS. The IP DNS capability allows for DNS-based host translation (name-to-address). Usage Examples The following example activates debug messages associated with DNS proxy activity: >enable #debug ip dns-proxy 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 121 This command applies to the NetVanta 300, 1000, 1000R, and 2000 and Total Access 900 Series units. Command History Release 6.1 Command was introduced. Usage Examples The following example activates debug messages associated with HTTP activity: >enable #debug ip http 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 122 ICMP RECV: From (172.22.255.200) to (10.100.23.19) Type=11 Code=0 Length=36 Details:TTL equals 0 during transit ICMP RECV: From (172.22.14.229) to (10.100.23.19) Type=3 Code=3 Length=36 Details:port unreachable ICMP RECV: From (172.22.14.229) to (10.100.23.19) Type=3 Code=3 Length=36 Details:port unreachable 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 123: Debug Ip Igmp

    This command applies to the NetVanta 300, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 7.1 Command was introduced. Usage Examples The following example enables IGMP debug messages for the specified multicast group: >enable #debug ip igmp 224.1.1.1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 124: Debug Ip Mrouting

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 10.1 Command was introduced. Usage Examples The following sample activates ip mrouting debug messages: >enable #debug ip mrouting 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 125: Debug Ip Ospf

    By default, all debug messages in the AOS are disabled. Applicable Platforms This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 126 OSPF: Rx ACK lasid=00000000 lsartid=192.168.2.13 nbr=11.0.50.2 OSPF: Received LSA ACK LSA_ID=0.0.0.0 LSA_RT_ID=-64.-88.2.13 OSPF: Sending delayed ACK OSPF: Update LSA: id=c0a8020d rtid=192.168.2.13 area=11.0.0.0 type=1 OSPF: Flooding out last interface OSPF: Update LSA: id=0b003202 rtid=11.0.50.2 area=11.0.0.0 type=1 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 127 The debug ip rip command activates debug messages to provide information on RIP activity in the AOS. RIP allows hosts and routers on a network to exchange information about routes. Usage Examples The following example activates debug messages associated with RIP activity: >enable #debug ip rip 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 128 In the debug ip tcp events information, TCB stands for TCP task control block. The numbers which sometimes appear next to TCB (e.g., TCB5 in the following example) represent the TCP session number. This allows you to differentiate debug messages for multiple TCP sessions. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 129 2003.02.17 07:40:56 IP.TCP EVENTS TCB5: new connection from 172.22.75.246:3473 to 10.200.2.201:23 2003.02.17 07:40:56 IP.TCP EVENTS TCB5: state change: SYNRCVD->ESTABLISHED [172.22.75.246:3473] 2003.02.17 07:41:06 IP.TCP EVENTS TCB5: Connection aborted -- error = RESET 2003.02.17 07:41:06 IP.TCP EVENTS TCB5: De-allocating tcb 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 130: Debug Ip Tcp Md

    Functional Notes Debug messages will only be generated for TCP ports that have MD5 authentication enabled. Usage Examples The following example activates debug messages associated with incoming TCP packet’s MD5 authentication: >enable #debug ip tcp md5 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 131: Debug Ip Udp

    Command was introduced. Functional Notes In the debug ip udp information, the message no listener means that there is no service listening on this UDP port (i.e., the data is discarded). 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 132 The following is sample output for this command: >enable #debug ip udp 2003.02.17 07:38:48 IP.UDP RX: src=10.200.3.236:138, dst=10.200.255.255:138, 229 bytes, no listener 2003.02.17 07:38:48 IP.UDP RX: src=10.200.2.7:138, dst=10.200.255.255:138, 227 bytes, no listener 2003.02.17 07:38:48 IP.UDP RX: src=10.200.201.240:138, dst=10.200.255.255:138, 215 bytes, no listener 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 133 Command History Release 8.1 Command was introduced. Usage Examples The following example activates all possible debug messages associated with LLDP operation: >enable #debug lldp rx #debug lldp tx #debug lldp verbose 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 134 New options were introduced. Usage Examples The following example activates port authentication debug information on received packets: >enable #debug port-auth packet rx Rcvd EAPOL Start for sess 1 on int eth 0/2 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 135: Debug Port Security

    Syntax Description No subcommands. Default Values By default, all debug messages in the AOS are disabled. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example activates port security debug messages: >enable...
  • Page 136 The debug ppp command activates debug messages to provide information on PPP activity in the system. PPP debug messages can be used to aid in troubleshooting PPP links. Usage Examples The following example activates debug messages associated with PPP authentication activity: >enable #debug ppp authentication 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 137: Debug Pppoe Client

    This command applies to the NetVanta 300, 1000R, 2000, 3000, and 4000 and Total Access 900 Series units. Command History Release 6.1 Command was introduced. Usage Examples The following example activates debug messages associated with PPPoE activity: >enable #debug pppoe client 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 138: Debug Radius

    The debug radius messages show the communication process with the remote RADIUS servers. Usage Examples The following is an example output for the debug radius command: >enable #debug radius RADIUS AUTHENTICATION: Sending packet to 172.22.48.1 (1645). RADIUS AUTHENTICATION: Received response from 172.22.48.1. NetVanta 2000, 5000, and 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 139: Debug Sntp

    2002.12.11 15:06:37 SNTP.CLIENT sent Version 1 SNTP time request to 63.97.45.57 2002.12.11 15:06:37 SNTP.CLIENT received SNTP reply packet from 63.97.45.57 2002.12.11 15:06:37 SNTP.CLIENT setting time to 12-11-2002 15:06:02 UTC 2002.12.11 15:06:37 SNTP.CLIENT waiting for 86400 seconds for the next poll interval 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 140 Command History Release 5.1 Command was introduced. Usage Examples The following example displays debug messages for BPDU packets that are transmitted and received by the unit: >enable #debug spanning-tree bpdu all 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 141 This command applies to the NetVanta 300, 1000, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example enables the display of general spanning-tree debug messages: >enable #debug spanning-tree general 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 142 Enables messages specific to the stack protocol. Default Values By default, all debug messages in the AOS are disabled. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example activates the possible debug stack messages: >enable...

  • Page 143: Debug System

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example activates debug messages associated with system information: >enable #debug system 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 144 This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example activates debug messages associated with the TACACS+ protocol: >enable #debug tacacs+ packets 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 145 This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example activates debug messages associated TFTP server packets: >enable #debug tftp server packets 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 146 The following is sample output from the dir command: >enable #dir Files: 988161 NV3200A-02-00-11.biz 1152 startup-config 1113 startup-config.bak 1739729 030018adv.biz 231424 boot030015.biz 1352150 NV3200A-E03-00-17.biz 232894 boot030018.biz 1812281 NV3200A-E03-00-20-adv.biz 6366976 bytes used, 335104 available, 6702080 total 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 147 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 10.1 Command was introduced. Usage Examples The following is example lists all files stored in flash: >enable #dir flash 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 148 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example exits the Enable mode and enters the Basic Command mode: #disable > 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 149 [md5] <password> on page 380 password is entered. Refer to for more information. Usage Examples The following example enters the Enable Command mode and defines an Enable Command mode password: >enable Password: ***** 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 150 The following example erases the startup configuration file stored in NVRAM: >enable #erase startup-config If a new startup-configuration file is not specified before power-cycling the unit, the AOS will initialize using a default configuration. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 151 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example enables event reporting: >enable #events 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 152: Exception Report Generate

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 10.1 Command was introduced. Usage Examples The following example immediately generates an exception report: >enable #exception report generate 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 153 Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example shows the logout command being executed in Enable mode: >enable #logout Session now available Press RETURN to get started. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 154 The following is a list of output messages from the ping command: Success Destination Host Unreachable Invalid Host Address TTL Expired in Transit Unknown Host Request Timed Out 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 155 '*' = Request timed out '-' = Destination host unreachable 'x' = TTL expired in transit Pinging 192.168.0.30 with 100 bytes of data: !!!!! Success rate is 100 percent (5/5) round-trip min/avg/max = 19/20.8/25 ms 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 156 Syntax Description No subcommands. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 8.1 Command was introduced. Functional Notes This command is available only in stack-master mode.
  • Page 157 The following example reloads the AOS software in 3 hours and 27 minutes: >enable #reload in 03:27 The following example reloads the AOS software in 15 minutes: >enable #reload in 15 The following example terminates a pending reload command: >enable #reload cancel 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 158: Show Access-Lists

    10.3.50.6 (0 matches) permit 10.200.5.0 wildcard bits 0.0.0.255 (0 matches) extended access list UnTrusted deny icmp 10.5.60.0 wildcard bits 0.0.0.255 any source-quench (0 matches) deny tcp any (0 matches) 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 159 #show arp ADDRESS TTL (min) 192.168.30.36 192.168.30.253 224.0.0.9 71578541 61200510L1-35E MAC ADDRESS LAST UPDATED (min) 00:E0:7D:88:1A:B9 4260 02:60:8C:DD:0A:CE 4264 01:00:5E:00:00:09 Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text> on page INTERFACE eth 0/1 eth 0/1 eth 0/2...
  • Page 160 Usage Examples The following is sample output from this command: >enable #show atm pvc interface atm 1.1 Encap Name Type atm 1.1 SNAP 61200510L1-35E Peak Avg/Min Burst Kbps Kbps Cells Copyright © 2005 ADTRAN Enable Mode Command Set Status Active...

  • Page 161: Show Auto-Config

    The following is a sample output of the show auto-config command: >enable #show auto-config Auto-Config is enabled, current status: Done. TFTP Server is 10.20.20.1 Config filename is 1524STfile Maximum retry count is 0 (repeat indefinitely), total retries is 0 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 162: Show Bridge

    00:10:A4:B3:A2:72 00:A0:C8:00:8F:98 00:E0:81:10:FF:CE 61200510L1-35E Action Interface forward eth 0/1 forward eth 0/1 forward eth 0/1 forward eth 0/1 forward fr 1.17 Copyright © 2005 ADTRAN Enable Mode Command Set Rx Count Tx Count 7133392 7042770 402365 311642 412367 1502106 1486963...
  • Page 163 The following is a sample output from the show buffers command: >enable #show buffers Buffer handles: 119 of 2000 used. Pool Size Total Used 1800 1894 2048 4096 8192 16384 32768 61200510L1-35E Available Max. Used 1775 Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text> on page...
  • Page 164 Command Reference Guide show buffers users [realtime] Use the show buffers users command to display a list of the top users of packet buffers. Typically, this command will only be used as a debug tool by ADTRAN personnel. Syntax Description realtime Displays full-screen output in real time.
  • Page 165 Command Reference Guide 0x001d8298 0x0010d970 0x00000000 0x00000000 0x00000000 0x00000000 0x00000000 0x00000000 0x00000000 0x00000000 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 166: Show Channel-Group

    Specifies the channel group using the channel group ID (16). Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced.
  • Page 167 Command was introduced. Usage Examples The following example displays the current time and data from the system clock: >show clock 23:35:07 UTC Tue Aug 20 2002 61200510L1-35E on page 82 Copyright © 2005 ADTRAN Enable Mode Command Set for more information.

  • Page 168: Show Configuration

    600 ip policy-timeout udp all-ports 60 ip policy-timeout icmp 60 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 169 0 no login line telnet 0 login line telnet 1 login line telnet 2 login line telnet 3 login line telnet 4 login 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 170: Show Connections

    Command History Release 7.1 Command was introduced. Usage Examples The following is sample output from the show connections command: >enable #show connections Displaying all connections... Conn ID From ppp 1 e1 1/1, tdm-group 1 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 171 CRL Dist. Pt: /C=FI/O=SSH Communications Security/OU=Web test/CN=Test CA 1 Start date is Jan 9 16:25:15 2003 GMT End date is Dec 31 23:59:59 2003 GMT Key Usage: Non-Repudiation Key Encipherment Data Encipherment CRL Signature Encipherment Only 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 172: Show Crypto Ike

    This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 4.1 Command was introduced. 61200510L1-35E for more information. on page 371 Copyright © 2005 ADTRAN Enable Mode Command Set crypto ike on page...
  • Page 173 #show crypto ike policy Crypto IKE Policy 100 Main mode Using System Local ID Address Peers: 63.105.15.129 initiate main respond anymode Attributes: Encryption: 3DES Hash: SHA Authentication: Pre-share Group: 1 Lifetime: 900 seconds 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 174: Show Crypto Ipsec

    No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 4.1 Command was introduced. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 175: Show Crypto Map

    Crypto Map "testMap" 10 ipsec-ike Extended IP access list NewList Peers: 63.97.45.57 Transform sets: esp-des Security-association lifetimes: 0 kilobytes 86400 seconds No PFS group configured Interfaces using crypto map testMap: eth 0/1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 176: Show Debugging

    Command was introduced. Usage Examples The following is a sample output from the show debugging command: >enable #show debugging debug access-list MatchAll debug firewall debug ip rip debug frame-relay events debug frame-relay llc2 debug frame-relay lmi 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 177: Show Demand

    Displays information for a specific demand routing interface. Valid range: 1 to 1024. Type show demand interface ? for a list of valid interfaces. Displays all resource pool information. name. Displays active demand sessions. Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 178 Connected to 2565552222 Number of active calls = 1 Interesting Traffic = list junk Connect Sequence: Successes = 0, Failures = 0 DialString Technology Successes Busys NoAnswers NoAuths InUse 5552222 ISDN 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 179 Remote IP address = 10.100.0.1 Remote Username = Dial reason: ip (s=, d=) Link 1 Dialed number = 5552222 Resource interface = bri 1/3, Multilink not negotiated Connect time: 0:0:13 Idle Timer: 119 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 180: Show Dial-Backup Interfaces

    10 seconds Restore delay: 10 seconds Connect timeout: 60 seconds Redial retries: unlimited Redial delay: 10 seconds Backup enabled all day on the following days: Sunday Monday Tuesday Wednesday Thursday Friday Saturday 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 181 Command Reference Guide Backup phone number list: Number Call Type min/max DS0s Backup I/F 5551212 analog 61200510L1-35E ppp 2 Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 182: Show Dialin Interfaces

    Command was introduced. Usage Examples The following is sample output from the show dialin interfaces command: >enable #show dialin interfaces Dialin interfaces... modem 1/3 dialin interface: Connection Status: Connected Caller ID info: name-John Smith number-5551212 time-14:23:10 2/17/2003 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 183: Show Dynamic-Dns

    The following is sample output from this command: >enable #show dynamic-dns eth 0/1: Hostname: host Is Updated: no Last Registered IP: 10.15.221.33 Last Update Time: 00:00:00 UTC Thu Jan 01 1970 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 184: Show Event-History

    2002.07.12 15:34:02 T1.t1 1/1 No Alarms 2002.07.12 15:34:02 INTERFACE_STATUS.t1 1/1 changed state to up. 2002.07.12 15:34:03 INTERFACE_STATUS.eth 0/1 changed state to up. 2002.07.12 15:34:10 OPERATING_SYSTEM Warm Start 2002.07.12 15:34:12 PPP.NEGOTIATION LCP up 2002.07.12 15:34:12 PPP.NEGOTIATION IPCP up 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 185: Show Flash

    The following is a sample show flash output: >enable #show flash Files: 245669 010100boot.biz 1141553 new.biz 821 startup-config 1638 startup-config.old 1175679 020016.biz 821 startup-config.bak 2572304 bytes used 4129776 available 6702080 total 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 186 61200510L1-35E rx_frag tx_frag tx frag. bytes 4724 tx non-frag. pkts tx non-frag. bytes 1960 tx pre-fragment pkts tx pre-fragment bytes 6324 dropped fragmenting pkts Copyright © 2005 ADTRAN Enable Mode Command Set dropped_frag...

  • Page 187: Show Frame-Relay

    In order to maximize the amount of data displayed, increase the terminal length (using the terminal length command; refer to 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text>...
  • Page 188 23013 in FECN pkts: 0 out DE pkts: 0 last time pvc status changed: 00:00:13:18 in bytes: 0 in FECN pkts: 0 out DE pkts: 0 last time pvc status changed: 00:00:13:18 Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 189 Command was introduced. Usage Examples The following is a sample output from this command: >enable #show frame-relay multilink Bundle: frame-relay 1 is DOWN; class A bundle Near-end BID: MFR1; Far-end BID: unknown 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 190: Show Garp Timer

    Syntax Description No subcommands. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example displays the current configured GARP application timer values: >enable...

  • Page 191: Show Gvrp Configuration

    Syntax Description No subcommands. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example displays a GVRP configuration summary for the switch: >enable...
  • Page 192 ? for a complete list of applicable interfaces. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example displays statistics related to GVRP for Ethernet interface 0/24: >enable...
  • Page 193 Name/address lookup uses domain name service DNS Proxy is disabled Default domain is not set Name servers are 1.1.1.1 2.2.2.2 Host Flags Example1 (P OK) Example2 (P OK) 61200510L1-35E Type Address 1.1.1.1 2.2.2.2 Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 194: Show Interfaces

    Ethernet interfaces only. Displays detailed configuration information on the terminal screen (versus only the non-default values). Optional. Displays current version information (e.g., model and list number, software version, etc.) for the T1 interface. Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 195 0 Severely Errored Seconds 0 Severely Errored Frame Seconds 0 Unavailable Seconds 0 Path Code Violations 0 Line Code Violations 0 Controlled Slip Seconds 0 Line Errored Seconds 0 Degraded Minutes 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text> on page...
  • Page 196 0 input errors 0 CRC 0 frame 0 abort 0 ignored 0 overruns 81 packets output 11496 bytes 0 underruns 0 input clock glitches 0 output clock glitches 0 carrier lost 0 cts lost 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 197 (Bc + Be). If not, the value for BW is the speed of the interface. The Average utilization displayed is the average utilization of the displayed bandwidth. If the bandwidth number is the Bc + Be value, the (limited) text appears (as shown above). 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 198 4144544E Serial Number: EngBetaREVC01D Firmware Version: ADSL Capabilities G.DMT, G.LITE, ADSL2, ADSL2+ adsl 0/1 Remote Line Information Vendor Id: 54535443 Serial Number: 00000000 Firmware Version: ADSL Capabilities G.DMT, G.LITE, ADSL2, ADSL2+ 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 199 (or range of intervals) to display rather than displaying all 96. Optional. Displays current version information (e.g., model and list number, software version, etc.) for the SHDSL interface. Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 200 Remote transparent network loopback • Remote non-transparent network loopback • No remote loopbacks Shows the current, minimum, and maximum signal-to-noise ratio of the line. These may be cleared using the clear counters shdsl <slot/port> command. Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 201 Shows current interval line statistics. These statistics may be cleared through the use of the clear counters shdsl <slot/port> command, but the number of elapsed seconds will continue running and accumulating time. Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 202 The reason for this is that sending test patterns into the IP stack could cause unpredictable behavior. However, it is still possible for the network to send a transparent loopback request. Such requests will be accepted. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 203 Negotiation of Trunking: access Access mode VLAN: 1 Trunking Native mode VLAN: 1 Trunking VLAN Enabled: 1-4094 Name: eth 0/2 Switchport: enabled Administrative mode: access Negotiation of Trunking: access Access mode VLAN: 12... 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 204: Show Ip Access-Lists

    10.3.50.6 (0 matches) permit 10.200.5.0 wildcard bits 0.0.0.255 (0 matches) Extended IP access list UnTrusted deny icmp 10.5.60.0 wildcard bits 0.0.0.255 any source-quench (0 matches) deny tcp any any (0 matches) 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 205 The following is a sample output of the show ip arp command: >enable #show ip arp ADDRESS TTL (min) 192.168.30.36 192.168.30.253 224.0.0.9 71578541 61200510L1-35E MAC ADDRESS LAST UPDATED (min) 00:E0:7D:88:1A:B9 4260 02:60:8C:DD:0A:CE 4264 01:00:5E:00:00:09 Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text> on page...
  • Page 206 400 permit 500 In the following example, only the AS Path List with the name AsPathList2 is displayed. >enable #show ip as-path-list AsPathList2 ip as-path-list AsPathList2: permit 400 permit 500 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 207 By default, this command displays all BGP routes. Applicable Platforms This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 10.1 Command was introduced. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 208 Total RIB entries = 4 61200510L1-35E Metric LocPrf Metric LocPrf Copyright © 2005 ADTRAN Enable Mode Command Set Path 302 300 1 3 4 i 302 300 1 3 4 5 i 302 300 1 3 4 i 302 300 1 3 4 i...
  • Page 209 Network address of the route learned, the Next Hop address to that network, the Metric, the Local Preference value (set using the "set local-preference *" command), and the Autonomous System Path to the destination network. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 210 21.0.0.0/30 10.22.131.10 Total RIB entries = 10 61200510L1-35E Metric LocPrf Copyright © 2005 ADTRAN Enable Mode Command Set Path 302 300 1 3 4 i 302 300 1 3 4 5 i 302 300 1 3 4 i 302 300 1 3 4 i...
  • Page 211 10.22.130.8/29 10.22.132.9 *> 10.22.130.240/28 10.22.131.1 *> 10.22.130.240/28 10.22.131.9 * i10.22.130.240/28 10.22.132.1 61200510L1-35E Metric LocPrf Path 302 i 302 i 303 304 302 i 302 300 i 302 300 i 303 300 i Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 212 302 300 i 302 300 i 303 i 303 i 302 304 i 303 304 i 302 304 i 303 304 i 302 304 i 303 304 i 302 304 i 303 304 i Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 213 302 304 305 i 303 304 305 i 305 i 302 304 305 i 303 304 305 i 305 i 305 i MsgRcvd MsgSent OutQ Copyright © 2005 ADTRAN Enable Mode Command Set Up/Down State/PfxRcd 01:30:06 01:30:07 02:43:09 02:43:15 02:43:24...
  • Page 214 303 304 i 303 304 i 303 304 i 303 304 i 303 304 i 303 304 i 303 304 i 303 304 i 303 304 305 i 303 304 305 i Copyright © 2005 ADTRAN Enable Mode Command Set 02:41:43 02:41:40...
  • Page 215 #show ip bgp 10.15.240.0/28 BGP routing table entry for 10.15.240.0/28 Paths: (1 available, best #1) Advertised to peers: 1.1.5.10 100 1 10.15.43.17 from 10.15.43.17 (8.1.1.1) Origin IGP, metric 2, valid, external, best 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 216: Show Ip Bgp Neighbors

    Entries that are not filtered by prefix lists are marked with an asterisk (*) to show they are valid. Entries that are deemed the best path to advertised route are marked with a caret (>). 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 217 Status codes: * valid, > best, i - internal Origin codes: i - IGP, e - EGP, ? - incomplete Network NextHop Metric Path *> 1.0.0.0/8 10.15.43.17 *> 2.0.0.0/9 10.15.43.17 61200510L1-35E Rcvd 1 100 i 1 100 i Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 218 Origin codes: i - IGP, e - EGP, ? - incomplete Network NextHop Metric Path *> 1.0.0.0/8 10.15.43.17 *> 2.0.0.0/9 10.15.43.17 61200510L1-35E 1 100 i 1 100 i 1 100 i 1 100 Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 219 10:67, and another which permits routes containing community number 10:68 and the internet community number, but denies routes containing community number 10:45. NetVanta4305#show ip community-list ip community-list CommList1: permit 10:67 ip community-list CommList2: permit 10:68 internet deny 10:45 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 220 The following is a sample output from the show dhcp-client lease command: >enable #show dhcp-client lease Interface: ethernet 0/1 Temp IP address: 10.100.23.64 Mask: 0.0.0.0 DHCP Lease server: 10.100.23.207 State: Bound (3) Lease: 120 seconds Temp default gateway address: 0.0.0.0 Client-ID: N/A 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 221 The following is a sample output from the show ip dhcp-server binding command: >enable #show ip dhcp-server binding IP Address Client Id 10.100.23.64 01:00:a0:c8:00:8f:b3 Aug 15 2002 11:02 AM 61200510L1-35E Lease Expiration Client Name Router Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 222: Show Ip Igmp Groups

    >enable #show ip igmp groups IGMP Connected Group Membership Group Address Interface 172.0.1.50 Loopback100 172.1.1.1 Ethernet0/1 172.1.1.1 Loopback100 61200510L1-35E Uptime Expires Last Reporter 00:42:57 00:02:50 172.23.23.1 00:05:26 00:02:51 1.1.1.2 00:42:57 00:02:51 172.23.23.1 Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 223: Show Ip Igmp Interface

    IGMP max query response time is 10 seconds Last member query count is 2 Last member query response interval is 1000 ms IGMP activity: 548 joins, 0 leaves IGMP querying router is 0.0.0.0 IGMP helper address is disabled 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 224 0/1 is UP, line protocol is UP Ip address is 10.10.10.1 Netmask is 255.255.255.0 MTU is 1500 Fastcaching is Enabled RIP Authentication is Disabled RIP Tx uses global version value RIP Rx uses global version value 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 225 Flags: S - Sparse, C - Connected, P - Pruned, J - Join SPT, T - SPT-bit Set, F - Register, R - RP-bit Set Timers: Uptime/Expires (*, 225.1.0.1), 01:16:21/00:02:45, RP 192.168.0.254, Flags: SC Incoming interface: tunnel 2, RPF nbr 172.16.2.10 Outgoing interface list: eth 0/1, Forward, 01:16:21/00:02:45 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 226 F - Register, R - RP-bit Set Timers: Uptime/Expires (*, 225.1.0.1), 01:17:34/00:03:25, RP 192.168.0.254, Flags: SC Forwarding Entry: Yes Incoming interface: tunnel 2, RPF nbr 172.16.2.10 Outgoing interface list: eth 0/1, Forward, 01:17:34/00:03:25 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 227: Show Ip Ospf

    SPF delay timer: 5 seconds, Hold time between SPFs: 10 seconds LSA interval: 240 seconds Number of external LSAs: 0, Checksum Sum: 0x0 Number of areas: 0, normal: 0, stub: 0, NSSA: 0 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 228: Show Ip Ospf Database

    This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. 61200510L1-35E network <ip address> <wildcard> area <area id> for more information. Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 229 IP address. If describing a router, this ID is always the router’s OSPF router ID. Usage Examples >enable #show ip ospf database 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 230: Show Ip Ospf Interface

    Release 9.1 Command was expanded to include HDLC and tunnel interfaces. Usage Examples The following example shows OSPF information for the PPP 1 interface. >enable #show ip ospf interface ppp 1 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 231 Command was introduced. Release 9.1 Command was expanded to include HDLC and tunnel interfaces. Usage Examples The following example shows detailed information on the OSPF neighbors: >enable #show ip ospf neighbor 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 232: Show Ip Ospf Summary-Address

    This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example displays all summary address redistribution information for the system: >enable #show ip ospf summary-address 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 233 The following is a sample output from the show ip policy-class command: >enable #show ip policy-class ip policy-class max-sessions 0 Policy-class "Trusted": 0 current sessions (6000 max) Entry 1 - allow list MatchAll 61200510L1-35E on page 437 for information on configuring access Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 234 This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. Release 11.1 The All option was added. 61200510L1-35E on page 437 for information on configuring access Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 235 Dest IP Address Dst Port NAT IP Address 192.168.19.2 3135 10.10.10.1 192.168.19.2 3138 10.10.10.1 192.168.19.2 3139 10.10.10.1 192.168.19.2 3146 10.10.10.1 Copyright © 2005 ADTRAN Enable Mode Command Set NAT Port 3000 3001 3002 3003 NAT Port 3605 3606 3607 3608...
  • Page 236 Command History Release 3.1 Command was introduced. Usage Examples The following example displays a list of current policy class statistics: >enable #show ip policy-stats 61200510L1-35E on page 437 for information on configuring access Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 237 4 entries seq 5 permit 0.0.0.0/0 ge 8 le 8 seq 10 deny 0.0.0.0/0 ge 9 le 9 seq 15 permit 0.0.0.0/0 ge 10 le 10 seq 20 deny 0.0.0.0/0 ge 11 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 238: Show Ip Protocols

    Invalid after 180 seconds, hold down time is 120 seconds Redistributing: rip Default version control: send version 2, receive version 2 Interface Send Ver. Rec Ver. eth 0/1 ppp 1 Routing for networks: 1.1.1.0/24 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 239 In order to maximize the amount of data displayed, increase the terminal length (using the terminal length command; refer to 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text>...
  • Page 240 2.0.0.0/9 [30/0] via 10.15.43.17, fr 1.17 2.128.0.0/10 [30/0] via 10.15.43.17, fr 1.17 2.192.0.0/11 [30/0] via 10.15.43.17, fr 1.17 2.224.0.0/12 [30/0] via 10.15.43.17, fr 1.17 2.240.0.0/13 [30/0] via 10.15.43.17, fr 1.17 2.248.0.0/14 [30/0] via 10.15.43.17, fr 1.17 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 241 In order to maximize the amount of data displayed, increase the terminal length (using the terminal length command; refer to Usage Examples >enable #show ip traffic 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text> on page...

  • Page 242: Show Lldp

    Command History Release 8.1 Command was introduced. Usage Examples The following example shows a sample LLDP timer configuration: >enable #show lldp Global LLDP information: Sending LLDP packets every 30 seconds Sending TTL of 120 seconds 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 243 Software: Version: 08.00.22.sw1.D, Date: Mon Nov 01 10:28:55 2004 Capabilities: Bridge, Router Enabled Capabilities: Router Local Port: eth 0/3 Management Addresses: Address Type: IP version 4, Address: 10.23.10.10 Interface Type: Interface Index, Interface Id: 2 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 244: Show Lldp Interface

    The following example shows LLDP configuration and statistics for the Ethernet 0/1 interface: >enable #show lldp interface ethernet 0/1 eth 0/1 (TX/RX) 0 packets input 0 input errors 0 TLV errors, 0 TLVs Discarded 0 packets discarded 8799 packets output 0 neighbor ageouts 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 245 In order to maximize the amount of data displayed, increase the terminal length (using the terminal length command; refer to 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text>...
  • Page 246 Software: Version: 08.00.22.sw1.D, Date: Mon Nov 01 10:28:55 2004 Capabilities: Bridge, Router Enabled Capabilities: Router Local Port: eth 0/3 Management Addresses: Address Type: IP version 4, Address: 10.23.10.10 Interface Type: Interface Index, Interface Id: 2 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 247: Show Lldp Neighbors Statistics

    Age outs - Shows how many times neighbors have been removed from the table because no new updates were received from that neighbor before its time-to-live timer expired. 61200510L1-35E Inserts Deletes Copyright © 2005 ADTRAN Enable Mode Command Set Drops Age outs...

  • Page 248: Show Mac Address-Table

    STATIC DYNAMIC DYNAMIC DYNAMIC DYNAMIC DYNAMIC DYNAMIC DYNAMIC DYNAMIC DYNAMIC DYNAMIC DYNAMIC Copyright © 2005 ADTRAN Enable Mode Command Set Ports eth 0/18 eth 0/1 eth 0/1 eth 0/1 eth 0/1 eth 0/1 eth 0/1 eth 0/1 eth 0/1 eth 0/1...
  • Page 249 Command Reference Guide Usage Examples 00:a0:c8:05:00:ac 00:a0:c8:05:00:ad 00:a0:c8:05:00:c2 61200510L1-35E DYNAMIC DYNAMIC DYNAMIC Copyright © 2005 ADTRAN Enable Mode Command Set eth 0/1 eth 0/1 eth 0/1...

  • Page 250: Show Mac Address-Table Address

    MAC address from the MAC address table: >enable #show mac address-table address 00:a0:c8:7d:30:00 Mac Address Table ------------------------------------------ Vlan Mac Address -------- -------------------- 00:a0:c8:7d:30:00 61200510L1-35E Type Ports --------- ----------- DYNAMIC eth 0/1 Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 251 #show mac address-table address 00:a0:c8:7d:30:00 ethernet 0/1 Mac Address Table ------------------------------------------ Vlan Mac Address -------- -------------------- 00:a0:c8:7d:30:00 Total Mac Addresses for this criterion: 1 61200510L1-35E Type Ports --------- ----------- DYNAMIC eth 0/1 Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 252: Show Mac Address-Table Aging-Time

    Release 5.1 Command was introduced. Usage Examples The following is a sample from the show mac address-table aging-time command for a switch configured with an address-table aging-time: >enable #show mac address-table aging-time Aging Time ---------------- Seconds 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 253: Show Mac Address-Table Count

    The following is a sample from the show mac address-table count command: >enable #show mac address-table count Mac Table Entries: -------------------------- Dynamic Address Count: 19 Static Address Count: 3 Total Mac Addresses: 23 Total Mac Address Space Available: 8169 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 254: Show Mac Address-Table Dynamic

    Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, 1000R, and 2000 Series units. Command History Release 5.1 Command was introduced. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 255 0/7 DYNAMIC eth 0/12 DYNAMIC eth 0/24 DYNAMIC eth 0/23 DYNAMIC eth 0/20 DYNAMIC eth 0/7 DYNAMIC eth 0/2 DYNAMIC eth 0/3 DYNAMIC eth 0/4 DYNAMIC giga-eth 0/2 DYNAMIC giga-eth 0/1 Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 256 00:a0:c8:0a:2d:7c Total Mac Addresses for this criterion: 10 61200510L1-35E Type Ports DYNAMIC eth 0/1 DYNAMIC eth 0/1 DYNAMIC eth 0/1 DYNAMIC eth 0/1 DYNAMIC eth 0/1 DYNAMIC eth 0/1 DYNAMIC eth 0/1 Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 257: Show Mac Address-Table Static

    Specifies a valid VLAN interface ID (1 to 4094). Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. 61200510L1-35E Copyright ©...
  • Page 258 The following is a sample from the show mac address-table static command: >enable #show mac address-table static Mac Address Table ----------------------------- Vlan Mac Address ------ ------------------- 00:a0:c8:00:88:40 Total Mac Addresses for this criterion: 1 61200510L1-35E Type Ports -------- -------- STATIC Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 259 Shows how much memory has been set aside to be used without memory caching, how much memory is being used and how much memory is free. (Valid only on NetVanta 300, 1000, and 1000R Series Units.) realtime Displays full-screen output in real time. See the Functional Notes below for more information.
  • Page 260 The following is a sample output from the show memory heap command: >enable #show memory heap Memory Heap: HeapFree: 2935792 HeapSize: 8522736 Block Managers: Size Used Free 1263 1225 1008 2032 4080 8176 16368 32752 65520 131056 0 61200510L1-35E Max-Used 1273 1227 Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 261 *********** T3 Module *********** Empty ----------- Empty ----------- Empty ----------- Empty ----------- Empty ----------- Empty ----------- Copyright © 2005 ADTRAN Enable Mode Command Set Part # H/W Rev 1200990L1 1200832L1 ----------- ---------- ----------- ---------- ----------- ---------- ----------- ---------- ----------- ----------...
  • Page 262 Displays information for a single specific monitor session. Shows all sessions. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples The following is a sample from the show monitor session command: >enable...

  • Page 263: Show Output-Startup

    The following is a sample output from the show output-startup command: >enable #show output-startup #hostname "UNIT_2" UNIT_2#no enable password UNIT_2#! UNIT_2#ip subnet-zero UNIT_2#ip classless UNIT_2#ip routing UNIT_2#! UNIT_2#event-history on UNIT_2#no logging forwarding UNIT_2#logging forwarding priority-level info UNIT_2#no logging email etc... 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 264 ID number. Type show port-auth interface ? for a list of valid interfaces. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 10.1 Command was introduced. Usage Examples The following example displays the port authentication information: >enable...
  • Page 265 0/23 disabled port-based n/a eth 0/24 disabled port-based n/a Port Authentication Port Details: Port-Authentication is disabled on eth 0/1 Port-Authentication is disabled on eth 0/2 61200510L1-35E Mode Authorized Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 266 Displays information for all interfaces, even if not configured for port expiration. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced.
  • Page 267 Displays full-screen output in real time. See the Functional Notes below for more information. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 1000 and 1000R series units. Command History Release 9.1 Command was introduced. Release 11.1 The real time display option was added.
  • Page 268 Command Reference Guide eth 0/2 auto eth 0/3 auto eth 0/4 auto eth 0/5 auto eth 0/6 eth 0/7 eth 0/8 eth 0/9 auto … 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set Class 0 Class 1...

  • Page 269: Show Pppoe

    10 seconds Backup enabled all day on the following days: Sunday Monday Tuesday Wednesday Thursday Friday Saturday Backup phone number list: Number Call Type min/max DS0s Backup I/F 5551212 analog 61200510L1-35E ppp 2 Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 270 The following is a sample output from the show processes cpu command: >enable #show processes cpu processes cpu System load: 7.07% Min: 0.00% Context switch load: 0.21% 61200510L1-35E Max 85.89% Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text> on page...
  • Page 271 RouteTableTick 50 W ...etc. 61200510L1-35E Exec Time Runtime (count) (usec) (usec) 129689 1971 927923 9658 3202 1443 31656 3871 Copyright © 2005 ADTRAN Enable Mode Command Set Load % (1sec) 92.79 0.32 0.03 0.00 0.00 0.01 0.39 0.00 0.00 0.09...
  • Page 272 Default Values No defaults necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 6.1 Command was introduced.
  • Page 273 The following is sample output from the show qos queuing command with WRR queuing enabled: >enable #show qos queuing Queue-type: wrr Expedite queue: disabled wrr weights: qid - weight 1 - 12 2 - 45 3 - 55 4 - 65 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 274: Show Qos Map

    This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 6.1 Command was introduced. Release 9.1 Command was expanded to include HDLC interface. Release 11.1 Demand interface was added. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 275 5 packets matched by map: 0 map entry 20 match IP packets with a precedence value of 3 priority bandwidth: 50 (kilobits/sec) burst: default packets matched by map: 0 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 276 #show qos map priority 10 qos map priority map entry 10 match IP packets with a precedence value of 6 priority bandwidth: 400 (kilobits/sec) burst: default packets matched by map: 125520 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 277 70 match NetBEUI frames being bridged by the router budget 3750/3750 bytes (current/max) priority bandwidth: 150 (kilobits/sec) packets matched on interface: 0 packets dropped: 0 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 278 TOS: 0 prot: 17 (udp), source port 99, destination port 99 (depth/weight/highest/discards) 6/256/25/0 Conversation 23, linktype: ip, length: 258 source: 10.100.23.11, destination: 10.200.2.125, id: 0x0000, ttl: 47, TOS: 0 prot: 6 (tcp), source port 16, destination port 16 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 279 Release 5.1 Command was introduced. Usage Examples The following is a sample output from the show queuing command: >enable #show queuing Interface Discard threshold fr 1 fr 2 ppp 1 61200510L1-35E Conversation subqueues Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 280: Show Radius Statistics

    The following is an example output using the show radius statistics command: >enable #show radius statistics Number of packets sent: Number of invalid responses: Number of timeouts: Average delay: Maximum delay: 61200510L1-35E Auth. Acct. 2 ms 0 ms 3 ms 0 ms Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 281 RouteMap1, permit, sequence 20 Match clauses: community (community-list filter): CommList2 Set clauses: local-preference 350 BGP Filtering matches: 87 routes Policy routing matches: 0 packets 0 bytes route-map RouteMap2, permit, sequence 10 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 282 (access-lists): Acl1 Set clauses: metric 100 BGP Filtering matches: 10 routes Policy routing matches: 0 packets 0 bytes route-map RouteMap2, permit, sequence 20 Match clauses: ip address (access-lists): Acl2 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 283 Policy routing matches: 0 packets 0 bytes route-map RouteMap3, permit, sequence 20 Match clauses: ip address (access-lists): Acl3 Set clauses: ip next-hop: 10.10.11.14 BGP Filtering matches: 0 routes Policy routing matches: 144 packets 15190 bytes 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 284: Show Running-Config

    Optional: Displays the current global PIM-SM configuration. verbose Optional. Displays the entire running configuration to the terminal screen (versus only the non-default values). Default Values No default value necessary for this command. 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 285 600 ip policy-timeout udp all-ports 60 ip policy-timeout icmp 60 interface eth 0/1... 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 286 Chassis: Chassis ID Contact: Customer Service 0 Rx SNMP packets 0 Bad community names 0 Bad community uses 0 Bad versions 0 Silent drops 0 Proxy drops 0 ASN parse errors 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 287: Show Sntp

    No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. Usage Examples >enable #show sntp 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 288: Show Spanning-Tree

    Interface Role ------------------- ------------------- eth 0/2 Desg eth 0/3 Desg eth 0/4 Desg giga-eth 0/1 Desg giga-eth 0/2 Desg 61200510L1-35E Cost ------------------- ----------- Copyright © 2005 ADTRAN Enable Mode Command Set Prio.Nbr Type ------------- --------------- 128.2 128.3 128.4 128.25 128.26...
  • Page 289 Optional. Displays the spanning-tree protocol status in detail. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples The following is an example output using the show spanning-tree active command: >enable...

  • Page 290: Show Spanning-Tree Blockedports

    Syntax Description No subcommands. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples The following is an example output using the show spanning-tree blockedports command: >enable...
  • Page 291 Optional. Displays spanning-tree protocol information for only active interfaces. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples The following is an example output using the show spanning-tree detail command: >...
  • Page 292 Optional. Displays only spanning-tree protocol state information. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples The following is an example output using the show spanning-tree interface ethernet command: >enable...
  • Page 293 Optional. Displays only spanning-tree protocol state information. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples The following is an example output using the show spanning-tree interface gigabit-ethernet command: >enable...
  • Page 294 Optional. Displays only spanning-tree protocol state information. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples The following is an example output using the show spanning-tree interface port-channel command: >enable...

  • Page 295: Show Spanning-Tree Pathcost Method

    Syntax Description No subcommands. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples The following is sample output using the show spanning-tree pathcost method command. In this case 32-bit values are being used when calculating path costs: >enable...

  • Page 296: Show Spanning-Tree Realtime

    Syntax Description No subcommands. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Release 10.1 The real time display option was introduced.
  • Page 297 Role ---------------- ---- --- --------- -------- -------------------------------------------------------- giga-eth 0/1 Root giga-eth 0/5 Altn ----------------------------------------------------------------------------------------------------- Exit - 'Ctrl-C', Freeze - 'f', Resume - 'r' 61200510L1-35E 1 (giga-eth 0/1) Cost Prio.Nbr Type 128.1 128.5 Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 298 Optional. Displays the priority and system-id of the spanning-tree root. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced.

  • Page 299: Show Spanning-Tree Summary

    Syntax Description No subcommands. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples The following is an example output using the show spanning-tree summary command: >enable...
  • Page 300 Displays the stack topology output in real time. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 8.1 Command was introduced. Release 10.1 The real time display option was introduced.
  • Page 301 IP address is 169.254.0.1, MAC address is 00:DE:AD:00:65:83 The following example displays all units that have registered with this stack-master. 61200510L1-35E Mgmt IP Address Source Interface 169.254.0.2 Stack port 169.254.0.3 Stack port Copyright © 2005 ADTRAN Enable Mode Command Set State...
  • Page 302 #show stack candidates Displaying all known Stack candidates... MAC Address System Name 00:A0:C8:00:8C:20 LabSwitch1 00:A0:C8:00:F5:6C LabSwitch2 00:A0:C8:02:CF:C0 LabSwitch3 61200510L1-35E Source Interface stack port stack port stack port Copyright © 2005 ADTRAN Enable Mode Command Set AOS Revision 08.00.18 08.00.19.D 08.00.20.D...

  • Page 303: Show Startup-Config

    600 ip policy-timeout udp all-ports 60 ip policy-timeout icmp 60 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 304 1/2 shutdown ip access-list standard MatchAll permit host 10.3.50.6 permit 10.200.5.0 0.0.0.255 ip access-list extended UnTrusted deny icmp 10.5.60.0 0.0.0.255 any source-quench deny tcp any any no ip snmp agent 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 305: Show Startup-Config Checksum

    Usage Examples The following example displays the MD5 checksum of the unit’s startup configuration: >enable #show startup-config checksum 10404D5DAB3FE35E307B6A79AC6AC8C0 #show running-config checksum 10404D5DAB3FE35E307B6A79AC6AC8C0 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 306: Show System

    Usage Examples The following is sample output for this command: >enable #show system ADTRAN, Inc. OS version 07.00.20 Checksum: 3B2FCC0F, built on Tue Jun 01 13:36:36 2004 Boot ROM version 07.00.20 Checksum: 604D, built on: Tue Jun 01 13:59:11 2004 Copyright (c) 1999-2004, ADTRAN, Inc.

  • Page 307: Show Tacacs+ Statistics

    Authentication Packets sent: Invalid responses: Timeouts: Average delay: Maximum delay: Socket Opens: Socket Closes: Socket Aborts: Socket Errors: Socket Timeouts: Socket Failed Connections: Socket Packets Sent: Socket Packets Received: 61200510L1-35E Authorization Accounting Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 308 (using the terminal length command; refer to Usage Examples The following is a sample from the show tcp info command: >enable #show tcp info TCP TCB Entries 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text> on page...
  • Page 309 FREE LISTEN FREE FREE FREE FREE FREE FREE FREE FREE 61200510L1-35E TYPE FLAGS RPORT LPORT SRVR CONN CONN CONN CONN 5761 SRVR SRVR Copyright © 2005 ADTRAN Enable Mode Command Set SWIN INTERFACE NONE NONE NONE NONE NONE NONE NONE...

  • Page 310: Show Thresholds

    Usage Examples >enable #show thresholds t1 1/1: SEFS 15 min threshold exceeded UAS 15 min threshold exceeded SEFS 24 hr threshold exceeded UAS 24 hr threshold exceeded t1 1/2: No thresholds exceeded 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 311 In order to maximize the amount of data displayed, increase the terminal length (using the terminal length command; refer to 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text>...
  • Page 312 Usage Examples The following is a sample of show users output: >enable #show users - CONSOLE 0 'adtran' logged in and enabled Idle for 00:00:00 - TELNET 0 (172.22.12.60:3998) 'password-only' logged in (not enabled) Idle for 00:00:14 - FTP (172.22.12.60:3999) 'adtran' logged in (not enabled)
  • Page 313 Command Reference Guide show version Use the show version command to display the current ADTRAN operating system (AOS) version information. Syntax Description No subcommands. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units.
  • Page 314 In order to maximize the amount of data displayed, increase the terminal length (using the terminal length command; refer to 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set terminal length <text>...
  • Page 315 0/1, eth 0/2 active eth 0/3, eth 0/4, eth 0/7, eth 0/9, eth 0/10, eth 0/11, eth 0/12 -------------- 1500 1500 Status Ports ------------- ---------------- active eth 0/1, eth 0/2 ------------- 1500 Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 316 Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example opens a Telnet session with a remote system (10.200.4.15): >enable #telnet 10.200.4.15 User Access Login: Password: 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...
  • Page 317 Specifies unit ID of the stack member to connect to via a Telnet session. Default Values No default value necessary for this command. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 8.1 Command was introduced.

  • Page 318: Terminal Length

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 6.1 Command was introduced. Usage Examples The following example sets the number of rows to 30. >enable #terminal length 30 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 319 Tracing route to 192.168.0.1 over a maximum of 30 hops 22ms 20ms 20ms 192.168.0.65 23ms 20ms 20ms 192.168.0.1 The following example specifies the source of the trace. The ip address 10.10.10.10 is the destination address: >enable #traceroute 10.10.10.10 source 192.168.0.3 61200510L1-35E Copyright © 2005 ADTRAN Enable Mode Command Set...

  • Page 320: Undebug All

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 2.1 Command was introduced. Usage Examples The following example disabled all activated debug messages: >enable #undebug all 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 321: Vlan Database

    Syntax Description No subcommands. Default Values No defaults necessary for this command. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example enters the VLAN Configuration mode: >enable...
  • Page 322 Command was introduced. Usage Examples The following example sends the message “Reboot in 5 minutes if no objections” to the CLI screen of everyone currently connected: >enable #wall Reboot in 5 minutes if no objections 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 323 Command was introduced. Usage Examples The following example saves the current configuration to the unit’s NVRAM: >enable #write memory 61200510L1-35E on page 87 for more information. on page 91 for more information. Copyright © 2005 ADTRAN Enable Mode Command Set copy <source>...

  • Page 324: Global Configuration Mode Command Set

    Global Configuration Mode Command Set OMMAND begin on page 330 begin on page 336 on page 338 on page 343 on page 349 on page 350 on page 351 Copyright © 2005 ADTRAN on page 346 on page 347 on page 348...
  • Page 325 404 on page 425 on page 430 on page 432 on page 433 on page 434 on page 436 on page 447 on page 452 Copyright © 2005 ADTRAN on page 378 on page 390 on page 431...
  • Page 326 455 on page 474 on page 480 on page 485 on page 500 on page 514 on page 530 Copyright © 2005 ADTRAN on page 456 on page 475 on page 476 on page 495 on page 525...
  • Page 327 (config)#aaa accounting commands 1 myList stop-only group tacacs+ To complete this command, Telnet must be applied to the lines. See Line (Telnet) Interface Config Command Set 61200510L1-35E Global Configuration Mode Command Set on page 553 for more detailed instructions. Copyright © 2005 ADTRAN on page 340.
  • Page 328 Command History Release 11.1 Command was introduced. Usage Examples The following command causes the unit to refrain from sending accounting records for users with null usernames: (config)#aaa accounting suppress null-username 61200510L1-35E Global Configuration Mode Command Set 340. Copyright © 2005 ADTRAN...
  • Page 329 Command History Release 11.1 Command was introduced. Usage Examples The following command sets the unit to send accounting records every 600 minutes to the server: (config)#aaa accounting update periodic 600 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 330 The following is a typical example of customizing the AAA authentication process: (config)# aaa authentication banner # Enter TEXT message. End with the character '#'. User login authentication:# (config)# (config)#aaa authentication fail-message # 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 331 Command Reference Guide Global Configuration Mode Command Set Enter TEXT message. End with the character '#'. Authentication denied.# (config)# (config)#aaa authentication username-prompt “Enter Username:” (config)#aaa authentication password-prompt “Enter Password:” 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 332 The following example specifies using the line password as the first method for enable authentication and using the enable password as the second: (config)#aaa authentication enable default line enable 61200510L1-35E Global Configuration Mode Command Set on page 340. Copyright © 2005 ADTRAN...
  • Page 333 The group method falls through if the servers in the remote group cannot be found. Refer to the command tacacs-server on page 527 for information on defining server groups. 61200510L1-35E Global Configuration Mode Command Set on page 340. radius-server Copyright © 2005 ADTRAN on page 492...
  • Page 334 (config)#aaa authentication login myList local group myGroup line The following command sets the default authentication list for logins to use the local database as the first fallback method: (config)#aaa authentication login default local 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 335 The login list named default is the default list used to authenticate users when no other list is assigned to the line. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 10.1 Command was introduced.
  • Page 336 (config)#aaa authorization commands 1 myList if-authenticated The following command uses the default list to authorize privileged (level 15) commands against the defined TACACS+ servers: (config)#aaa authorization commands 15 default group tacacs+ 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 337 Command was introduced. Usage Examples The following example enables authorization of configuration mode commands: (config)#aaa authorization config-command The following example enables authorization of console commands: (config)#aaa authorization console 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN on page...

  • Page 338: Aaa Group Server [Radius | Tacacs+]

    The default group cannot be changed and includes all RADIUS servers in the order they were specified by the radius-server commands. The same is true of TACACS+ servers specified by the tacacs-server commands. 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN Radius Group on page 1363 for more...
  • Page 339 The following example creates the named list myServers and enters the RADIUS group: (config)#aaa group server radius myServers (config-sg-radius)# The following example creates the named list myServers and enters the TACACS+ group: (config)#aaa group server tacacs myServers (config-sg-tacacs+)# 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 340: Aaa On

    Instant access LINE-PASSWORD Use the line password (telnet 0-4 or console 0-1) ENABLE-PASSWORD Use the enable password LOCAL-USERS Use the local-user database GROUP <groupname> Use a group of remote RADIUS servers 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 341 If the AAA process falls through the list completely, system behavior is based on portal: • Console access is granted if the process falls completely through (this prevents a lock-out condition). • Telnet and FTP are denied access. 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 342: Aaa Processes

    Increasing this number may speed up simultaneous authentication at the cost of system resources (e.g., memory). Usage Examples The following example specifies five available threads for the AAA subsystem: (config)#aaa processes 5 61200510L1-35E Global Configuration Mode Command Set on page 340. Copyright © 2005 ADTRAN...

  • Page 343: Arp Arpa

    Release 6.1 Command was extended to include NetVanta 2000 Series units. Usage Examples The following example enables standard ARP for the VLAN interface: (config)#interface vlan 1 (config-interface-vlan 1)#arp 196.173.22.253 00:A0:C8:00:00:01 arpa 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 344: Auto-Config

    [filename <name> | restart | retry-count <number>| server <name or address>] Use the auto-config command to enable the automatic self-configuration feature in ADTRAN OS. Use the no form of this command to halt the Auto-Config process. For more detailed information on auto-config, see the Auto-Config Configuration Guide on the documentation CD, PN 61200560L1-29.2.
  • Page 345 The following command specifies the TFTP server IP address from which to download the configuration file: (config)#auto-config server 192.33.5.99 The following command specifies the TFTP server hostname from which to download the configuration file: (config)#auto-config server myHost 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 346: Banner [Exec | Login | Motd]

    Exec banner appears after successful login. Usage Examples The following example configures the system to display a message of the day: (config)#banner motd *The system will be shut down today from 7PM to 11PM* 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 347: Boot Config [Cflash | Flash] [Cflash | Flash]

    This command applies to the NetVanta 1000R, 2000, 3000, 4000 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example specifies the file myimage.biz, stored in flash memory, as the startup image: (config)#boot system flash myimage.biz 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 348: Boot System Flash [No-Backup |

    Total Access 900 Series units. Command History Release 1.1 Command was introduced. Functional Notes Detailed instructions for upgrading the AOS and loading files into flash memory are found on the ADTRAN OS Documentation CD. 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 349: Bridge Protocol Ieee

    This command applies to the NetVanta 300, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example deletes the bridge protocol setting for bridge-group 17: (config)#no bridge 17 protocol ieee 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 350: Clock [Auto-Correct-Dst | No-Auto-Correct-Dst

    The following example allows for automatic DST correction: (config)#clock auto-correct-dst The following example overrides the one-hour offset for DST: (config)#clock no-auto-correct-dst 61200510L1-35E Global Configuration Mode Command Set clock timezone <text> on page 352 Copyright © 2005 ADTRAN for more information)
  • Page 351 Command was added to the Global command set. Usage Examples The following example sets the system software clock for 3:42 pm, August 22 2004: (config)#clock set 15:42:00 22 Au 2004 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 352 Command was introduced. Depending on the clock timezone chosen, one-hour Daylight Savings Time (DST) correction may be enabled automatically. See clock [auto-correct-dst | no-auto-correct-dst] 61200510L1-35E Global Configuration Mode Command Set on page 350 for more information. Copyright © 2005 ADTRAN...
  • Page 353 -5-Bogota clock timezone -5-Eastern-Time clock timezone -6-Central-America clock timezone -6-Central-Time clock timezone -6-Mexico-City clock timezone -6-Saskatchewan clock timezone -7-Arizona clock timezone -7-Mountain-Time clock timezone -8 clock timezone -9 clock timezone GMT-Casablanca clock timezone GMT-Dublin Copyright © 2005 ADTRAN...
  • Page 354 Command Reference Guide Global Configuration Mode Command Set Usage Examples The following example sets the timezone for Santiago, Chile. >enable (config)#clock timezone -4-Santiago 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 355 Functional Notes Cross-connects provide the mechanism for connecting a configured virtual (layer 2) endpoint with a physical (layer 1) interface. Supported layer 2 protocols include Frame Relay and point-to-point protocol (PPP). 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 356 For example, the following creates a Frame Relay interface labeled 7 and sets the signaling method to ansi. (config)# interface frame-relay 7 (config-fr 7)# frame-relay lmi-type ansi 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 357 (labeled 5) to make an association between the Frame Relay virtual interface (fr 7) and the TDM group configured on interface t1 1/1 (tdm-group 9). (config)# cross-connect 5 t1 1/1 9 fr 7 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 358: Crypto Ca Authenticate

    Enter the base 64 encoded CA certificate. End with two consecutive carriage returns or the word “quit” on a line by itself: -----BEGIN X509 CERTIFICATE----- MIIDEDCCAs6gAwIBAgICAXIwCwYHKoZIzjgEAwUAMFoxCzAJBgNVBAYTAkZJMSQw IgYDVQQKExtTU0ggQ29tbXVuaWNhdGlvbnMgU2VjdXJpdHkxETAPBgNVBAsTCFdl YiB0ZXN0MRIwEAYDVQQDEwlUZXN0IENBIDQwHhcNMDMwMTA5MTYyNTE1WhcNMDMx MjMxMjM1OTU5WjBaMQswCQYDVQQGEwJGSTEkMCIGA1UEChMbU1NIIENvbW11bmlj YXRpb25zIFNlY3VyaXR5MREwDwYDVQQLEwhXZWIgdGVzdDESMBAGA1UEAxMJVGVz dCBDQSA0MIIBtzCCASsGByqGSM44BAEwggEeAoGBAPTo+NdCWh87hOSnuZ7dUL07 twjZZwY3beLHnDsERhfN8XoOZZcffulKc/lqTrYiu7M5yPJsXQ3u8dbCb6RWFU0A T5Nd7/4cNn/hCmhbeb6xqsNZUsOcTZJxvClq8thkNo+gXg5bw0fiElgxZ/lEbFWL UzeO8KgM4izkq0CrGtaFAhUA2+ja4RgbbgTgJk+qTXAxicG/8JMCgYBZvcPMO2/Y 61200510L1-35E Global Configuration Mode Command Set enrollment url <url> on page 1220 Copyright © 2005 ADTRAN for more information. When...
  • Page 359 Command Reference Guide Global Configuration Mode Command Set Zc2sXYyrBPtv6k2ZGGYqXAUZ98/txm37JwQGafygePJ/64oeisVeDcLf2FTjveex W5saydjSK00jXjreRZcJFEDmfRhUtWR8K8tm8mEnB3eg9n09lkWibIjihHn7n5MF tBBAdbRHyctsr3DyofnieTt3DY78MDsNbgOBhQACgYEA6EKDS2IxrdMsogHfVvob PkDSv2FjOsP5Tomc/tf9jvvuf6+vj9XTw+uAg1BU9/TyjGzAtnRrCvOUkTYoVxRY vdDOi3GR2RcyNVdGrhYXWY1I5XuB5+NWij8VUQOgfXsJgbEMvPemECeYwQ4ASdhD vw0E8NI2AEkJXsCAvYfXWzujIzAhMAsGA1UdDwQEAwIBhjASBgNVHRMBAf8ECDAG AQH/AgEyMAsGByqGSM44BAMFAAMvADAsAhRa0ao0FbRQeWCc2oC24OZ1YZi8egIU IZhxKAclhXksZHvOj+yIld5x0ec= -----END X509 CERTIFICATE----- quit Hash: 4e904504dc4e5b95e08129430e2a0b97ceef0ad1394f905b42df2dfb8f751be0244a711bb0 6eddaa2f07dd640c187f14c16fa0bed28e038b28b6741a880539d6ed06a68b7e324bfdde6f3d0b17 83d94e58fd4943f5988a7a0f27f6b6b932dc0410378247160752853858dbe7a1951245cfb14b109e ffc430e177623720de56f4 * Do you accept this certificate? [y]y 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 360 Typically used only in the running-config and startup-config to restore certificates. Usage Examples The following example enters the Certificate Configuration mode for the CA profile MyProfile: (config)#crypto ca certificate chain MyProfile 61200510L1-35E Global Configuration Mode Command Set on page 1226 for more information. Copyright © 2005 ADTRAN...

  • Page 361: Crypto Ca Enroll

    If enrollment is set to url, the request is sent automatically to the certificate authority using the URL specified by the enrollment url command. 61200510L1-35E Global Configuration Mode Command Set enrollment url <url> on page 1220 on page 366 for more information. Copyright © 2005 ADTRAN for more information. This...
  • Page 362 * Enter IP address or name of interface to use:10.200.1.45 * Include fully qualified domain name [n]:y * Enter the fully qualified domain name to use:FullyQualifiedDomainName * Include an email address [n]:y * Enter the email address to use:myEmail@adtran.commyemail@email.com Generating request (including keys)... 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 363 Enter the PM-encoded certificate. End with two consecutive carriage returns or the word “quit” on a line by itself: -----BEGIN CERTIFICATE----- MIIDWTCCAwOgAwIBAgIKFLCsOgAAAAAAtjANBgkqhkiG9w0BAQUFADBjMQswCQYD VQQGEwJVUzEQMA4GA1UECBMHQUxBQkFNQTETMBEGA1UEBxMKSHVudHN2aWxsZTEa MBgGA1UEChMRQWR0cmFuVGVjaFN1cHBvcnQxETAPBgNVBAMTCHRzcm91dGVyMB4X DTAzMDYyNTE0MTM1NVoXDTAzMTIwNjE0NDkxM1owJDEPMA0GA1UEChMGYWR0cmFu MREwDwYDVQQDEwhNeVJvdXRlcjBcMA0GCSqGSIb3DQEBAQUAA0sAMEgCQQClUKqs fbTalej5m9gk2DMsbC9df3TilBz+7nRx3ZzGw75AQsqEMYeBY5aWi62W59jmxGSE WX+E8EwBVbZ6JKk5AgMBAAGjggHWMIIB0jAXBgNVHREEEDAOhwQKCgoKggZNeUZx ZG4wHQYDVR0OBBYEFJAvBRIjx1PROnkZ4v0D89yB1eErMIGcBgNVHSMEgZQwgZGA FHGwIRAr11495MgrLNPiLzjvrb4JoWekZTBjMQswCQYDVQQGEwJVUzEQMA4GA1UE CBMHQUxBQkFNQTETMBEGA1UEBxMKSHVudHN2aWxsZTEaMBgGA1UEChMRQWR0cmFu 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN enrollment terminal on page...
  • Page 364 Command Reference Guide Global Configuration Mode Command Set VGVjaFN1cHBvcnQxETAPBgNVBAMTCHRzcm91dGVyghAZql7OwISgsUhfaSeGh0Ot MGkGA1UdHwRiMGAwLaAroCmGJ2h0dHA6Ly90c3JvdXRlci9DZXJ0RW5yb2xsL3Rz cm91dGVyLmNybDAvoC2gK4YpZmlsZTovL1xcdHNyb3V0ZXJcQ2VydEVucm9sbFx0 c3JvdXRlci5jcmwwgY0GCCsGAQUFBwEBBIGAMH4wPAYIKwYBBQUHMAKGMGh0dHA6 Ly90c3JvdXRlci9DZXJ0RW5yb2xsL3Rzcm91dGVyX3Rzcm91dGVyLmNydDA+Bggr BgEFBQcwAoYyZmlsZTovL1xcdHNyb3V0ZXJcQ2VydEVucm9sbFx0c3JvdXRlcl90 c3JvdXRlci5jcnQwDQYJKoZIhvcNAQEFBQADQQBSGD4JbGJGk53qvyy0xXVoMQvy U8xNjUdvWqjgFOI+2m8ZYJcfhnt11rbP2f3Wm9TpjLe1WuBNxmpNjC9A2ab0 -----END CERTIFICATE----- Success! 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 365 Refer to Usage Examples The following allows you to manually paste in the CA’s CRL: (config)#crypto ca import MyProfile crl 61200510L1-35E Global Configuration Mode Command Set enrollment terminal on page 1219 Copyright © 2005 ADTRAN...
  • Page 366 The following example creates the CA profile called MyProfile and enters the CA Profile Configuration for that certificate authority: (config)#crypto ca profile MyProfile Configuring New CA Profile MyProfile. (ca-profile)# 61200510L1-35E Global Configuration Mode Command Set on page 1215 for more information. crypto ca enroll <name> on page 361 Copyright © 2005 ADTRAN for more information.

  • Page 367: Crypto Ike

    Creates an IKE policy with the <policy priority> of your choice and enters the IKE Policy. Refer to IKE Policy Command Set 1260 for more information. Copyright © 2005 ADTRAN on page 1250 on page 1267 for more on page...
  • Page 368 Subnet is 10.10.20.0. For more detailed information on VPN configuration, refer to the technical support note VPN Configuration Guide located on the ADTRAN OS Documentation CD provided with your unit. Step 1: Enter the Global configuration mode (i.e., config terminal mode).
  • Page 369 IP address will be the source of the traffic to be encrypted. The destination IP address will be the receiver of the data on the other side of the VPN tunnel. (config)#ip access-list extended corporate_traffic (config-ext-nacl)#permit ip 10.10.10.0 0.0.0.255 10.10.20.0 0.0.0.255 log deny ip any any 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 370 Step 10: Configure a private interface. This process allows all traffic destined for the VPN tunnel to be routed to the appropriate gateway. (config)#interface ethernet 0/1 (config-eth 0/1)#ip address 10.10.10.254 255.255.255.0 (config-eth 0/1)#no shutdown (config-eth 0/1)#exit 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 371: Crypto Ike Remote-Id

    Use the crypto ike remote-id command to specify the remote ID and to associate a pre-shared key with the remote ID. For VPN configuration example scripts, refer to the technical support note VPN Configuration Guide located on the ADTRAN OS Documentation CD provided with your unit. Syntax Description address <IPv4 address>...
  • Page 372 “?” for a single character match. Currently, the “?” cannot be set up using the CLI, but it can be transferred to the unit via the startup-config. Example for typical asn1-dn format with no wildcards: crypto ike remote-id asn1-dn "CN=MyRouter, C=US, S=ALCA, L=Huntsville, O=Adtran, OU=TechSupport" (matches only remote ID strings with all fields exactly the same) 61200510L1-35E Copyright ©...
  • Page 373 Example for typical asn1-dn format with wildcards used to match a portion of the remote ID: crypto ike remote-id asn1-dn "CN=*, C=US, S=ALCA, L=Huntsville, O=Adtran, OU=*" (matches any remote ID string with the same values for the C, S, L, and O fields, and any values in the CN and...

  • Page 374: Crypto Ipsec Transform-Set

    (e.g., esp-3des, esp-sha-hmac, etc.). The transform set is then assigned to a crypto map using the map’s set transform-set command. Refer to set transform-set <setname1 - setname6> For VPN configuration example scripts, refer to the technical support note VPN Configuration Guide located on the ADTRAN OS Documentation CD provided with your unit. Syntax Description <setname>...
  • Page 375 The following example first creates a transform set (Set1) consisting of two security algorithms (up to three may be defined), and then assigns the transform set to a crypto map (Map1): (config)#crypto ipsec transform-set Set1 esp-3des esp-sha-hmac (cfg-crypto-trans)#exit (config)#crypto map Map1 1 ipsec-ike (config-crypto-map)#set transform-set Set1 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 376: Crypto Map

    Variations of this command include the following: crypto map <mapname> <mapindex> ipsec-ike crypto map <mapname> <mapindex> ipsec-manual For VPN configuration example scripts, refer to the technical support note VPN Configuration Guide located on the ADTRAN OS Documentation CD provided with your unit. Syntax Description <mapname>...
  • Page 377 If an SA does not exist, or if the packet fails any of the security checks (bad authentication, traffic does not match SA selectors, etc.), it is discarded. If all checks pass, the packet is forwarded normally. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 378 The following example sets the authentication protocol sent for incoming calls to PAP. This router may be authenticated by the peer using PAP: (config)#data-call sent authentication protocol pap 61200510L1-35E Global Configuration Mode Command Set on page Sets the authentication protocol expected for inbound calls. Configures CHAP authentication. Configures PAP authentication. Copyright © 2005 ADTRAN 200.

  • Page 379: Data-Call [Mtu | Multilink

    The following example specifies an MTU of 1200 on the demand routing interface: (config)#data-call MTU 1200 The following example enables multilink for inbound demand routing calls: (config)#data-call multilink 61200510L1-35E Global Configuration Mode Command Set on page 198 for more detailed syntax descriptions. Copyright © 2005 ADTRAN...

  • Page 380: Enable Password [Md5]

    By default, there is no configured enable password. Applicable Platforms This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 381 To provide extra security, the AOS can encrypt the Enable password when displaying the current configuration. For example, the following is a show configuration printout (password portion) with an unencrypted Enable password (ADTRAN): enable password ADTRAN Alternately, the following is a show configuration printout (password portion) with an Enable password of...

  • Page 382: Event-History On

    2002.07.12 15:34:03 INTERFACE_STATUS.eth 0/1 changed state to up. 2002.07.12 15:34:10 OPERATING_SYSTEM Warm Start 2002.07.12 15:34:12 PPP.NEGOTIATION LCP up 2002.07.12 15:34:12 PPP.NEGOTIATION IPCP up Usage Examples The following example enables the AOS event logging feature: (config)#event-history on 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 383: Event-History Priority [Error | Fatal | Info | Notice | Warning

    2002.07.12 15:34:02 INTERFACE_STATUS.t1 1/1 changed state to up. 2002.07.12 15:34:03 INTERFACE_STATUS.eth 0/1 changed state to up. 2002.07.12 15:34:10 OPERATING_SYSTEM Warm Start 2002.07.12 15:34:12 PPP.NEGOTIATION LCP up 2002.07.12 15:34:12 PPP.NEGOTIATION IPCP up 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 384 Command Reference Guide Global Configuration Mode Command Set Usage Examples The following example logs all events to the event history: (config)#event-history priority info 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 385: Exception Report [Filename

    45676 example-20050708080537 #config t (config)#no exception report file-name (config)#exit Appropriate commands must be issued to preserve configuration. #exception report generate Exception report generated. #show flash 1744 startup-config 45676 example-20050708080537 45900 exception-report-20050708080552 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 386: Ftp Authentication

    The following example specifies that the AOS use the default AAA login list for FTP authentication: (config)#ftp authentication default 61200510L1-35E Global Configuration Mode Command Set for more information). This list is only used if the AAA subsystem Copyright © 2005 ADTRAN...

  • Page 387: Garp Timer [Join | Leave | Leaveall]

    By default, the join timer is 200 milliseconds, the leave timer is 600 milliseconds, and the leaveall timer is 10000 milliseconds. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced.
  • Page 388 Syntax Description No subcommands. Default Values By default, GVRP is disabled. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Functional Notes Disabling GVRP globally will disable GVRP on all interfaces.

  • Page 389: Hostname

    Command History Release 1.1 Command was introduced. Usage Examples The following example creates a hostname for the AOS device of ATL_RTR to identify the system as the Atlanta router: (config)#hostname ATL_RTR 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 390: Interface [ | ] [Point-To-Point

    Command expanded to include demand, FXO, and PRI interfaces. Usage Examples The following example enters the serial interface mode for a serial module installed in slot 1: (config)#interface serial 1/1 (config-ser 1/1)# 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 391: Interface Range -

    The following example selects seven consecutive Ethernet ports for configuration: (config)#interface range eth 0/1-0/7 (config-eth 0/1-7)# The following example selects nonconsecutive FXS ports for configuration: (config)#interface range fxs 3/1-2, 3/3, 3/4-6, 3/8 (config-fxs 3/1-2, 3/3, 3/4-6, 3/8)# 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 392: Ip Access-List Extended

    192.168.0.0 0.0.0.255 will permit all traffic from the 192.168.0.0/24 network. <source port> Optional. The source port is used only when <protocol> is tcp or udp. 61200510L1-35E Global Configuration Mode Command Set Source IP Address Source IP Address Copyright © 2005 ADTRAN...
  • Page 393 (Port 496) rip (Port 520) snmp (Port 161) snmptrap (Port 162) sunrpc (Port 111) syslog (Port 514) tacacs (Port 49) talk (Port 517) tftp (Port 69) time (Port 37) who (Port 513) xdmcp (Port 177) Copyright © 2005 ADTRAN...
  • Page 394 (Port 110) smtp (Port 25) sunrpc (Port 111) syslog (Port 514) tacacs (Port 49) talk (Port 517) tftp (Port 69) telnet (Port 23) time (Port 37) uucp (Port 540) whois (Port 43) www (Port 80) Copyright © 2005 ADTRAN...
  • Page 395 Enter a functional description for the list such as “This list blocks all outbound web traffic”. Logs a message (if debug access-list is enabled for this access list) when the access list finds a packet match. 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 396 190.72.22.55.0/24 network: (config)#ip access-list extended AllowIKE (config-ext-nacl)#permit udp 190.72.22.55.0 0.0.0.255 eq 500 any eq 500 For more details, refer to the ADTRAN OS System Documentation CD or the ADTRAN website (www.adtran.com) for technical support notes regarding access-list configuration. Technology Review...
  • Page 397 <policy name>. The following example assigns access policy MatchAll to the Ethernet 0/1 interface: (config)#interface ethernet 0/1 (config-eth 0/1)#access-policy MatchAll 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 398 By default, all AOS security features are disabled and there are no configured access lists. Applicable Platforms This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 9000 Series units. Command History Release 2.1 Command was introduced. 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 399 Specifying a one in the wildcard mask equates to a “don’t care.” For example, the following denies all traffic from the 192.168.0.0/24 network: (config)#ip access-list standard MatchNetwork (config-std-nacl)#deny 192.168.0.0 0.0.0.255 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 400 (config)#ip access-list standard UnTrusted (config-std-nacl)#deny 190.72.22.248 0.0.0.3 For more details, refer to the ADTRAN OS System Documentation CD or the ADTRAN website (www.adtran.com) for technical support notes regarding access list configuration. Technology Review Creating access policies and lists to regulate traffic through the routed network is a four-step process: Step 1: Enable the security features of the AOS using the ip firewall command.
  • Page 401 <policy name>. The following example assigns access policy MatchAll to the Ethernet 0/1 interface: (config)#interface ethernet 0/1 (config-eth 0/1)#access-policy MatchAll 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 402: Ip Classless

    Command History Release 1.1 Command was introduced. Functional Notes AOS products only function in classless mode. You cannot disable this feature. Usage Examples The following example enables the system to forward classless packets: (config)#ip classless 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 403: Ip Crypto

    All other configuration parameters will remain intact, and VPN functionality will be disabled. For VPN configuration example scripts, refer to the VPN Configuration Guide located on the ADTRAN OS Documentation CD provided with your unit. Syntax Description No subcommands.

  • Page 404: Ip Default-Gateway

    Only use the ip default-gateway when IP routing is disabled on the router. For all other cases, use the ip route 0.0.0.0 0.0.0.0 <ip address> command. Usage Examples The following example disables IP routing and configures a default gateway for 192.22.71.50: (config)#no ip routing (config)#ip default-gateway 192.22.71.50 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 405: Ip Dhcp-Server Database Local

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 10.1 Command was introduced. Usage Examples The following example configures the DHCP database agent with local bindings: (config)#ip dhcp-server database local 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 406 DHCP IP address pool. This will avoid IP address overlap. Usage Examples The following example excludes an IP address of 172.22.5.100 and the range 172.22.5.200 through 172.22.5.250: (config)#ip dhcp-server excluded-address 172.22.5.100 (config)#ip dhcp-server excluded-address 172.22.5.200 172.22.5.250 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 407 0 prevents the DHCP server from using ping packets as part of the IP address assignment process. Usage Examples The following example configures the DHCP server to transmit four ping packets before assigning an address: (config)#ip dhcp-server ping packets 4 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 408 The following example configures the DHCP server to wait 900 milliseconds for a response to a transmitted DHCP ping packet before considering the ping a failure: (config)#ip dhcp-server ping timeout 900 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 409: Ip Dhcp-Server Pool

    Multiple address pools can be created to service different segments of the network with tailored configurations. Usage Examples The following example creates a DHCP server address pool (labeled SALES) and enters the DHCP server pool mode: (config)#ip dhcp-server pool SALES (config-dhcp)# 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 410: Ip Domain-Lookup

    Use the ip domain-lookup command to enable the DNS client in the router. This will allow the user to input web addresses instead of IP addresses for applications such as ping, Telnet, and traceroute. Usage Examples The following example enables DNS: (config)#ip domain-lookup 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 411: Ip Domain-Name

    IP host name that is not initially recognized will have the ip domain-name appended to it and the request will be resent. Usage Examples The following example defines adtran as the default domain name: (config)#ip domain-name adtran 61200510L1-35E Global Configuration Mode Command Set Copyright ©...

  • Page 412: Ip Domain-Proxy

    Usage Examples The following example enables DNS proxy: (config)#ip domain-proxy 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 413 Applicable Platforms This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 2.1 Command was introduced. 61200510L1-35E Global Configuration Mode Command Set on page 497. Copyright © 2005 ADTRAN...
  • Page 414 ACLs: standard and extended. Standard ACLs allow source IP address packet patterns only. Extended ACLs may specify patterns using most fields in the IP header and the TCP or UDP header. Usage Examples The following example enables the AOS security features: (config)#ip firewall 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 415 Case 3: Packets from interfaces without a configured policy class to interfaces with one These packets are routed normally and are not processed by the firewall. The ip firewall command has no effect on this traffic. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 416 Many attacks use similar invalid traffic patterns; therefore attacks other than the examples listed below may also be blocked by the firewall. To determine if a specific attack is blocked by the AOS firewall, please contact ADTRAN technical support. Invalid Traffic Pattern...
  • Page 417 If the firewall received a segment with an unexpected (or invalid) sequence number, the packet is dropped. All IP packets containing the IP source route option are dropped. Copyright © 2005 ADTRAN Common Attacks Winnuke, TCP XMAS Scan...
  • Page 418 H.323: H.245 Q.931 ASN1 PER decoding and Encoding ICQ® Microsoft® Games Net2Phone PPTP Quake® Real-Time Streaming Protocol SMTP HTTP CUseeme L2TP PcAnywhere™ Microsoft Gaming Zone To determine if a specific application requires special processing, contact technical support. ADTRAN at www.adtran.com. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 419 Disabling the IP firewall ALG may cause the firewall to block some of the traffic for the specified protocol. Usage Examples The following example disables ALG for FTP: (config)#no ip firewall alg ftp 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 420 Series units. Command History Release 2.1 Command was introduced. Usage Examples The following example specifies a threshold of 25 attacks before generating a log message: (config)#ip firewall attack-log threshold 25 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 421: Ip Firewall Check Reflexive-Traffic

    If enabled, this traffic will be processed through the access policy on that interface and any actions specified will be executed on the traffic. Usage Examples The following example enables the AOS reflexive traffic check: (config)#ip firewall check reflexive-traffic 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 422: Ip Firewall Check Syn-Flood

    AOS stateful inspection firewall to filter out phony service requests and allow only legitimate requests to pass through. Usage Examples The following example enables the AOS SYN-flood check: (config)#ip firewall check syn-flood 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 423: Ip Firewall Check Winnuke

    AOS stateful inspection firewall to filter all OOB data to prevent network problems. Usage Examples The following example enables the firewall to filter all OOB data: (config)#ip firewall check winnuke 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 424 Series units. Command History Release 2.1 Command was introduced. Usage Examples The following example specifies a threshold of 15 connections before generating a log message: (config)#ip firewall policy-log threshold 15 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 425: Ip Forward-Protocol Udp

    (Port 496) rip (Port 520) snmp (Port 161) snmptrap (Port 162) sunrpc (Port 111) syslog (Port 514) tacacs (Port 49) talk (Port 517) tftp (Port 69) time (Port 37) who (Port 513) xdmcp (Port 177) Copyright © 2005 ADTRAN...
  • Page 426 UDP service on the other side of the WAN link. Usage Examples The following example forwards all Domain Name Server (DNS) broadcast traffic to the DNS server with IP address 192.33.5.99: (config)#ip forward-protocol udp domain (config)#interface eth 0/1 (config-eth 0/1)#ip helper-address 192.33.5.99 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 427 Total Access 900 Series units. Command History Release 2.1 Command was introduced. Usage Examples The following example applies the configured ACP (labeled Inbound_FTP) to inbound FTP traffic: (config)#ip ftp access-class Inbound_FTP in 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 428 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 4.1 Command was introduced. Usage Examples The following example enables the IP FTP agent: (config)#ip ftp agent 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 429 Usage Examples The following example configures the unit to use the loopback 1 interface as the source IP for FTP traffic: (config)#ip ftp source-interface loopback 1 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 430: Ip Host

    The name may be any combination of numbers and letters as long as it is not a valid IP address or does not exceed 256 characters. Usage Examples The following example defines two static mappings: (config)#ip host mac 10.2.0.2 (config)#ip host dal 172.38.7.12 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 431 This command applies to the NetVanta 300, 1000, 1000R, and 2000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example enables web access to the router: (config)#ip http server 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 432: Ip Igmp Join

    ICMP echo requests for the joined groups. Usage Examples The following example configures the unit to join with the specified multicast group: (config)#ip igmp join 172.0.1.50 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 433: Ip Load-Sharing [Per-Destination | Per-Packet

    Command History Release 10.1 Command was introduced. Usage Examples The following example turns on load-sharing per destination: (config)# ip load-sharing per-destination The following example disables load-sharing: (config)# no ip load-sharing 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 434: Ip Mcast-Stub Helper-Address

    Also, if it receives a leave, it will not send a leave until it is certain that there are no more subscribers on any downstream interface. Usage Examples The following example specifies 172.45.6.99 as the helper address: (config)#ip mcast-stub helper-address 172.45.6.99 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 435: Ip Multicast-Routing

    This command applies to the NetVanta 300, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 7.1 Command was introduced. Usage Examples The following example enables multicast functionality: (config)#ip multicast-routing 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 436: Ip Name-Server

    The following example specifies host 172.34.1.111 as the primary name server and host 172.34.1.2 as the secondary server: (config)#ip name-server 172.341.1.111 172.34.1.2 This command will be reflected in the configuration file as follows: ip name-server 172.34.1.111 172.34.1.2 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 437 By default, all AOS security features are disabled and there are no configured access lists. Applicable Platforms This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 2.1 Command was introduced. 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 438 IP address. The overload keyword is not an option when performing NAT on the destination IP address; each private address must have a unique public address. This hides private IP addresses from outside the local network. Usage Examples Refer to the Technology Review (which follows) for command syntax examples. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 439 IP address with the entered IP address. The overload keyword allows multiple source IP addresses to be replaced with the single IP address entered. This hides private IP addresses from outside the local network. 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 440 Apply the created access policy to an interface. To assign an access policy to an interface, enter the interface configuration mode for the desired interface and enter access policy <policy name>. The following example assigns access policy MatchAll to the Ethernet 0/1 interface: (config)#interface ethernet 0/1 (config-eth 0/1)#access-policy MatchAll 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 441 (Port 37) who (Port 513) xdmcp (Port 177) kshell (Port 544) login (Port 513) lpd (Port 515) nntp (Port 119) pim-auto-rp (Port 496) pop2 (Port 109) pop3 (Port 110) smtp (Port 25) ssh (Port 22) Copyright © 2005 ADTRAN...
  • Page 442 Added AHP, GRE, and ESP policies. 61200510L1-35E Global Configuration Mode Command Set sunrpc (Port 111) syslog (Port 514) tacacs (Port 49) talk (Port 517) telnet (Port 23) time (Port 37) uucp (Port 540) whois (Port 43) www (Port 80) Copyright © 2005 ADTRAN...
  • Page 443 (config)#ip policy-timeout esp 1200 The following example creates a customized policy timeout of 1200 seconds for GRE: (config)#ip policy-timeout gre 1200 The following example creates a customized policy timeout of 1200 seconds for AHP: (config)#ip policy-timeout ahp 1200 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 444 Usage Examples The following example adds a description to the prefix-list test: (config)#ip prefix-list test description “An example prefix list” 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 445 A route that is denied at the beginning entry of a prefix list will not be allowed, even if it matches a permitting entry further down the list. 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 446 (config)#ip prefix-list test seq 5 deny 10.0.0.0/8 The following example creates a prefix list entry in the prefix list test matching any network of length 24 or less: (config)#ip prefix-list test seq 10 permit 0.0.0.0/0 le 24 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 447: Ip Radius Source-Interface

    If this value is not defined, the address of the source network interface is used. Usage Examples The following example configures the Ethernet 0/1 port to be the source interface: (config)#ip radius source-interface ethernet 0/1 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 448 The following example adds a static route to the 10.220.0.0/16 network through the next-hop router 192.22.45.254 and a default route to 175.44.2.10: (config)#ip route 10.220.0.0 255.255.0.0 192.22.45.254 (config)#ip route 0.0.0.0 0.0.0.0 175.44.2.10 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 449: Ip Routing

    This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example enables the AOS IP routing functionality: (config)#ip routing 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 450: Ip Scp Server

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 10.1 Command was introduced. Usage Examples The following example enables the secure copy server: (config)#ip scp server 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 451: Ip Snmp Agent

    Allows a MIB browser to access standard MIBs within the product. This also allows the product to send traps to a trap management station. Usage Examples The following example enables the IP SNMP agent: (config)#ip snmp agent 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 452: Ip Sntp Source-Interface

    Usage Examples The following example configures the unit to use the loopback 1 interface as the source IP for SNTP traffic: (config)#ip sntp source-interface loopback 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 453 The following example configures the SSH server to listen on TCP port 2200 instead of the default port 22: (config)#ip ssh-server 2200 To return to the default settings, use the no version of the command. For example: (config)#no ip ssh-server 2200 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 454: Ip Subnet-Zero

    This command applies to the NetVanta 300, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example subnet-zero is enabled: (config)#ip subnet-zero 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 455: Ip Tftp Source-Interface

    Usage Examples The following example configures the unit to use the loopback 1 interface as the source IP for TFTP traffic: (config)#ip tftp source-interface loopback 1 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 456 Line (Telnet) Interface Config Command Set for information on the subcommands found in that command set. on page 545 for information on the subcommands found in Copyright © 2005 ADTRAN on page 532, Line Line (SSH) Interface...
  • Page 457 The following example begins the configuration for all available Telnet sessions: (config)#line telnet 0 4 (config-telnet0-4)# The following example begins the configuration for all available SSH sessions: (config)#line ssh 0 4 (config-ssh0-4)# 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 458 Defines the delay between LLDP frame transmission attempts during normal operation (in seconds). Defines the multiplier to be applied to the transmit interval to compute the time-to-live for data sent in an LLDP frame. Specifies the interval, delay, or multiplier. Copyright © 2005 ADTRAN...
  • Page 459 The following example sets the LLDP transmit interval to 15 seconds: (config)#lldp transmit-interval 15 The following example sets the LLDP TTL multiplier to 2 and the time-to-live for all LLDP frames transmitted from this unit to 30 seconds; (config)#lldp transmit-interval 15 (config)#lldp ttl-multiplier 2 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 460: Logging Console

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example enables the AOS to log events to all consoles: (config)#logging console 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 461 Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example specifies three email addresses to use when sending logged messages: (config)#logging email address-list admin@adtranemail.com;ntwk@adtranemail.com;support@adtranemail.com 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 462 Command was introduced. Functional Notes When AOS experiences an exception it will generate a file with detailed information that ADTRAN’s Technical Support can use to diagnose the problem, This command allows the unit to email the exception report to a list of addresses upon rebooting after the exception. This command should be used in conjunction with the other logging email commands.
  • Page 463 The domain name is appended to the sender name when sending event notifications. Refer to the ip domain-name <name> on page 411 command for related information. Usage Examples The following example enables the AOS email event notification feature: (config)#logging email on 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 464 The following example sends all messages with warning level or greater to the email addresses listed using the logging email address-list command: (config)#logging email priority-level warning 61200510L1-35E Global Configuration Mode Command Set on page 461 and logging email on Copyright © 2005 ADTRAN on page 463...
  • Page 465 Release 1.1 Command was introduced. Usage Examples The following example specifies an email server (with address 172.5.67.99) to use when sending logged messages: (config)#logging email receiver-ip 172.5.67.99 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN on page 464...
  • Page 466 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 6.1 Command was introduced. Usage Examples The following example sets a sender for outgoing messages: (config)#logging email sender myUnit@myNetwork.com 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 467 Usage Examples The following example configures the unit to use the loopback 1 interface as the source IP for email messages: (config)#logging email source-interface loopback 1 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 468: Logging Facility

    Mail system news USENET news sys9 - sys14 System use syslog System log user User process uucp UNIX-to-UNIX copy system 61200510L1-35E Global Configuration Mode Command Set on page 470 for related information. Facility types are Copyright © 2005 ADTRAN...
  • Page 469 Command Reference Guide Global Configuration Mode Command Set Usage Examples The following example configures the syslog facility to the cron facility type: (config)#logging facility cron 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 470 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example enables the AOS syslog event feature: (config)#logging forwarding on 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 471 The following example sends all messages with warning level or greater to the syslog server listed using the logging forwarding receiver-ip command. (config)#logging forwarding priority-level warning 61200510L1-35E Global Configuration Mode Command Set for more information. Use the no form of this command to Copyright © 2005 ADTRAN...
  • Page 472 Command History Release 1.1 Command was introduced. Usage Examples The following example specifies a syslog server (with address 172.5.67.99) to use when logging messages: (config)#logging forwarding receiver-ip 172.5.67.99 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN on page 471...
  • Page 473 Usage Examples configures the unit to use the loopback 1 interface as the source IP for event log traffic: (config)#logging forwarding source-interface loopback 1 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 474: Mac Address-Table Aging-Time

    This command applies to the NetVanta 300, 1000, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example sets the aging time to 10 minutes: (config)#mac address-table aging-time 600 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 475 Release 10.1 Command was introduced. Usage Examples The following example adds a static MAC address to PPP 1 on bridge 4: (config)#mac address-table static 00:A0:C8:00:00:01 bridge 4 interface ppp 1 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 476 Specifies a valid slot/port interface ID (e.g., eth 0/1). Default Values By default, there are no static entries configured. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced.
  • Page 477 Ecuador - Ecuador Modem configuration Egypt - Egypt Modem configuration Finland - Finland Modem configuration France - France Modem configuration Germany - Germany Modem configuration Greece - Greece Modem configuration 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 478 - Taiwan Modem configuration Thailand - Thailand Modem configuration Trinidad - Trinidad Modem configuration Tunisia - Tunisia Modem configuration Turkey - Turkey Modem configuration - UAE Modem configuration - UK Modem configuration 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 479 Uruguay - Uruguay Modem configuration Venezuela - Venezuela Modem configuration Yemen - Yemen Modem configuration Usage Example The following example specifies to use the USA/Cananda modem configuration. (config)#modem countrycode USA/Canada 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 480 Optional. Sets the direction of traffic on the source interface (transmit and receive, receive only, or transmit only). Default Values Direction of traffic defaults to both. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples...
  • Page 481 Syntax Description No subcommands. Default Values No default value is necessary for this command. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 10.1 Command was introduced. Usage Examples The following example sets all global port-authentication settings to their default states:...
  • Page 482 Specifies the maximum number of authentication requests. Default Values By default, the maximum number of authentication requests is set at 2. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 10.1 Command was introduced.
  • Page 483 Use the port-auth re-authentication command to enable re-authentication. Syntax Description No subcommands necessary. Default Values By default, re-authentication is disabled. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 10.1 Command was introduced. Usage Examples The following example enables re-authentication:...
  • Page 484 By default, quiet-period is set to 60 seconds, re-authperiod is set to 3600 seconds (1 hour), and tx-period is set to 30 seconds. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 10.1 Command was introduced.
  • Page 485 Specifies the source MAC address. Default Values By default, load balance is set to src-mac. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Functional Notes During port aggregation, the port channel interface must determine on which physical port to transmit packets.
  • Page 486 By default, CoS 0 and 1 are mapped to queue 1; CoS 2 and 3 are mapped to queue 2; CoS 4 and 5 are mapped to queue 3; CoS 6 and 7 are mapped to queue 4. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced.
  • Page 487 Sets the map to the following default values: DSCP Default Values By default, this command is disabled. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 7.1 Command was introduced. Functional Notes When one of the specified DSCP values is detected in an incoming packet, the CoS priority is altered based on the corresponding map value.
  • Page 488 Any traffic for the interface that is not sent to the priority queue is sent using the default queuing method for the interface (such as weighted fair queuing). 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 489 The following example demonstrates basic settings for a QoS map and assigns a map to the Frame Relay interface: >enable #config terminal (config)#qos map VOICEMAP 10 (config-qos-map)#match precedence 5 (config-qos-map)#priority 512 (config-qos-map)#exit (config)#interface fr 1 (config-fr 1)#qos-policy out VOICEMAP 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 490 Syntax Description No subcommands. Default Values By default, the queue type is weighted round robin (WRR). Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example enables strict-priority queuing:...
  • Page 491 Default Values By default, all four weights are set to 25. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced.

  • Page 492: Radius Server

    3 attempts timeout 5 seconds enable-username $enab15$ Applicable Platforms This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 493 When the last server is removed from a list, the list is automatically deleted. Usage Examples The following example shows a typical configuration of these parameters: (config)#radius-server challenge-noecho (config)#radius-server deadtime 10 (config)#radius-server timeout 2 (config)#radius-server retry 4 (config)#radius-server key my secret key 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 494: Radius-Server Host

    Command was expanded to include the key encrypted command. Usage Examples The following example shows a typical configuration of these parameters: (config)#radius-server host 1.2.3.4 (config)#radius-server host 3.3.1.2 acct-port 1646 key my key 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 495 You can then define the attributes of the route map from the Route Map Configuration Command set. Enter a ? at the (config-route-map)# prompt to explore the available options. 61200510L1-35E Global Configuration Mode Command Set on page 1294 for more information. Copyright © 2005 ADTRAN...

  • Page 496: Router Bgp

    Before the route is installed into the route table (forwarding table), a check is made of other sources that may have information about the same subnet (static routes, IGP, etc.) The route with the lowest administrative distance is installed. 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 497: Router Ospf

    OSPF configured interface. No modification to the policy class is required to allow OSPF packets into the system. Usage Examples The following example uses the router ospf command to enter the OSPF Configuration mode: (config)#router ospf 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 498: Router Rip

    240 seconds. Consider a connected route (one on a local interface). If the interface fails, an update is immediately triggered for that route only (advertised with a metric of 16). 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 499 A broadcast or multicast packet to port 520 that indicates the route for a given destination network. Update An advertisement sent on a regular 30-second interval including all routes exclusive of those learned on an interface. 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 500: Service Password-Encryption

    You cannot recover a lost encrypted password. You must erase the startup-config and set a new password. Usage Examples The following example enables password encryption for all passwords on the unit: (config)#service password-encryption 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 501: Snmp-Server Chassis-Id

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example configures a chassis ID of A432692: (config)#snmp-server chassis-id A432692 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 502 (config)#snmp-server community MyCommunity view blockinterfaces rw 61200510L1-35E Global Configuration Mode Command Set on page 512 on page 392 on page 398 Copyright © 2005 ADTRAN snmp-server view ip access-list standard for more information on...
  • Page 503 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 10.1 Command was introduced. Usage Examples The following example specifies 6536999 for the pager number: (config)#snmp-server contact pager 6536999 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 504: Snmp-Server Contact

    Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example specifies Network Administrator x4000 for the sysContact string: (config)#snmp-server contact “Network Administrator x4000” 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 505 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example enables the SNMP traps: (config)#snmp-server enable traps snmp 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 506 Command was introduced. Usage Examples The following example sends all SNMP traps to the host at address 190.3.44.69 and community string My Community: (config)#snmp-server host 190.3.44.69 traps My Community snmp 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 507 Usage Examples The following example sends all SNMP traps to the host at address 190.3.44.69 and community string My Community using SNMPv2C: (config)#snmp-server host 190.3.44.69 traps version 2c My Community snmp 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 508: Snmp-Server Location

    Populates the system location string using an alphanumeric string enclosed in quotation marks (up to 32 characters in length). Default Values By default, the snmp-server location is set to ADTRAN. Applicable Platforms This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units.
  • Page 509 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000 and Total Access 900 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example specifies the URL http://www.mywatch.com as the device’s management software: (config)#snmp-server management-url http://www.mywatch.com 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 510 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000 and Total Access 900 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example specifies the label watch for the management software: (config)#snmp-server management-url-label watch 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 511: Snmp-Server Source-Interface

    Command was introduced. Usage Examples The following example specifies that the Ethernet interface (ethernet 0/1) should be the source for all SNMP traps and get/set requests: (config)#snmp-server source-interface ethernet 0/1 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 512 (named blockInterfaces) to exclude the OID subtree family 1.3.3.1.2.1.2: (config)#snmp-server view blockInterfaces 1.3.6.1.2.1.2.* excluded The following example shows how to create a view (named block) to include a specific OID: (config)#snmp-server view block 1.3.6.1.2.1.2. included 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 513 This command applies to the NetVanta 300, 1000, and 1000R and Total Access 900 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example sets the SNTP retry timeout to 10 seconds: (config)#sntp retry-time 10 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 514 The following example sets the SNTP server to time.nist.gov using SNTP version 1 (the default version): (config)#sntp server time.nist.gov The following example sets the SNTP server as time.nist.gov. All requests for time use version 2 of the SNTP: (config)#sntp server time.nist.gov version 2 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 515 This command applies to the NetVanta 300, 1000, 1000R and Total Access 900 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example sets the SNTP wait time to two days: (config)#sntp wait-time 172800 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 516: Spanning-Tree Edgeport Bpdufilter Default

    (config)#spanning-tree edgeport bpdufilter default To disable the BPDU filter on a specific interface, issue the appropriate commands for the given interface using the following commands as an example: (config)#interface ethernet 0/1 (config-eth 0/1)#spanning-tree bpdufilter disable 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 517 The following example enables the BPDU guard on all ports by default. (config)#spanning-tree bpduguard default To disable the BPDU guard on a specific interface, issue the appropriate commands for the given interface using the following commands as an example: (config)#interface ethernet 0/1 (config-eth 0/1)#spanning-tree bpduguard disable 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 518: Spanning-Tree Edgeport Default

    The following example configures all interfaces running spanning tree to be edgeports by default: (config)#spanning-tree edgeport default An individual interface can be configured to not be considered an edgeport. For example: (config)#interface ethernet 0/1 (config-eth 0/1)#spanning-tree edgeport disable (config)#interface ethernet 0/1 (config-eth 0/1)#no spanning-tree edgeport 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 519: Spanning-Tree Forward-Time

    This command applies to the NetVanta 300, 1000, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example sets the forwarding time to 18 seconds: (config)#spanning-tree forward-time 18 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 520: Spanning-Tree Hello-Time

    This command applies to the NetVanta 300, 1000, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example configures a spanning-tree hello-time interval of 10,000 seconds: (config)#spanning-tree hello-time 10000 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 521: Spanning-Tree Max-Age

    This command applies to the NetVanta 300, 1000, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example configures a wait interval of 45 seconds: (config)#spanning-tree max-age 45 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 522 This command applies to the NetVanta 300, 1000, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example sets the spanning-tree mode to rapid spanning-tree protocol: (config)#spanning-tree mode rstp 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 523 This command applies to the NetVanta 300, 1000, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example specifies that the spanning-tree protocol use a long pathcost method: (config)#spanning-tree pathcost method long 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 524: Spanning-Tree Priority

    This command applies to the NetVanta 300, 1000, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example sets spanning-tree priority to the maximum level: (config)#spanning-tree priority 0 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 525 Setting this value puts you in stack member mode, as opposed to stack master mode. Default Values By default, stack vlan is 2386, and the stack IP network is 169.254.0.0/24. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples The following are variations of the stack command: This example configures the unit to be the stack master and use the default stack VLAN and IP network.
  • Page 526 (config)#stack member 00:A0:C8:00:8C:20 2 This example specifies that this unit is in the stack using VLAN 2000 as its management VLAN; also specifies that this unit is in stack member mode (not a stack-master). (config)#stack vlan 2000 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 527: Tacacs-Server

    Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example sets a timeout limit of 60 seconds for the specified server: (config)#tacacs-server host 10.5.6.7 timeout 60 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 528 ES 15Min 65 thresholds ES 24Hr 648 thresholds LCV 15Min 13340 thresholds LCV 24Hr 133400 thresholds LES 15Min 65 thresholds LES 24Hr 648 thresholds PCV 15Min 72 thresholds PCV 24Hr 691 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...
  • Page 529 Command was introduced. Usage Examples The following example sets the threshold for the 15 minute and 24 hour bursty errored seconds counter to 25 and 200, respectively: (config)#thresholds BES 15Min 25 (config)#thresholds BES 24Hr 200 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 530: Username Password

    All users defined using the username/password command are valid for access to the unit using the login local-userlist command. Usage Examples The following example creates a username of ADTRAN with password ADTRAN: (config)#username ADTRAN password ADTRAN 61200510L1-35E Global Configuration Mode Command Set...
  • Page 531 This command applies to the NetVanta 300, 1000, 1000R, and 2000 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example enters the VLAN configuration mode for VLAN 1: (config)#vlan 1 (config-vlan 1)# 61200510L1-35E Global Configuration Mode Command Set Copyright © 2005 ADTRAN...

  • Page 532: Line (Console) Interface Config Command Set

    543 stopbits [1 | 2] on page 544 61200510L1-35E Line (Console) Interface Config Command Set ONFIG OMMAND on page 533 on page 534 on page 536 on page 539 on page 541 on page 542 Copyright © 2005 ADTRAN...
  • Page 533 Command History Release 11.1 Command was introduced. Usage Examples The following example applies the default accounting method to line 1: (config)#aaa on (config)#line console 0 (config-con0)#accounting commands 1 default 61200510L1-35E Line (Console) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 534 Command History Release 11.1 Command was introduced. Usage Examples The following example applies the default authorization method to line 1: (config)#aaa on (config)#line console 0 (config-con0)#authorization commands 1 default 61200510L1-35E Line (Console) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 535 Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example configures 7 databits per character for the console terminal session: (config)#line console 0 (config-con 0)#databits 7 61200510L1-35E Line (Console) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 536 Total Access 900 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example configures no flow control for the line console: (config)#line console 0 (config-con 0)#flowcontrol none 61200510L1-35E Line (Console) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 537 Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example specifies a timeout of 2 minutes: (config)#line console 0 (config-con 0)#line-timeout 2 61200510L1-35E Line (Console) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 538 Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example enables the security login feature and specifies a password on the available console session: (config)#line console 0 (config-console 0)#login (config-console 0)#password mypassword 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 539: Login Authentication

    This prevents a lockout configuration. Usage Examples The following example specifies that myList will be used for authenticating users connecting on this line: (config)#line console 0 (config-con 0)#login authentication myList 61200510L1-35E Line (Console) Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 540: Login Local-Userlist

    CONSOLE port: (config)#username my_user password my_password (config)#line console 0 (config-con 0)#login local-userlist When connecting to the unit, the following prompts are displayed: User Access Login Username: ADTRAN Password: Router# 61200510L1-35E Line (Console) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 541 Parity bits are appended to data frames to ensure that parity (whether it be odd or even) is maintained. Usage Examples The following example specifies mark parity for the console terminal session: (config)#line console 0 (config-con 0)#parity mark 61200510L1-35E Line (Console) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 542 To provide extra security, the AOS can encrypt the enable password when displaying the current configuration. For example, the following is a show configuration printout (password portion) with an unencrypted enable password (ADTRAN): enable password ADTRAN Alternately, the following is a show configuration printout (password portion) with an enable password of...
  • Page 543 Release 1.1 Command was introduced. Usage Examples The following example configures the CONSOLE port for 19200 bps: (config)#line console 0 (config-con 0)#speed 19200 61200510L1-35E Line (Console) Interface Config Command Set port. This setting must match your CONSOLE Copyright © 2005 ADTRAN...
  • Page 544 Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example configures 2 stopbits per character for the console terminal session: (config)#line console 0 (config-con 0)#stopbits 2 61200510L1-35E Line (Console) Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 545: Line (Ssh) Interface Config Command Set

    <minutes> on page 549 login on page 550 login authentication <aaa login list> login local-userlist on page 552 61200510L1-35E Line (SSH) Interface Config Command Set ONFIG OMMAND on page 547 on page 548 on page 551 Copyright © 2005 ADTRAN...
  • Page 546 Enter the line (ssh) : (config)#line ssh 0 4 Associate the access list with the SSH session: (config-ssh0-4)#access-class Trusted in 61200510L1-35E Line (SSH) Interface Config Command Set and ip access-list extended <listname> Copyright © 2005 ADTRAN on page 392 for more information...
  • Page 547 Command History Release 11.1 Command was introduced. Usage Examples The following example applies the default accounting method to line 1: (config)#aaa on (config)#line ssh 1 (config-ssh1)#accounting commands 1 default 61200510L1-35E Line (SSH) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 548 Command History Release 11.1 Command was introduced. Usage Examples The following example applies the default authorization method to line 1: (config)#aaa on (config)#line ssh 1 (config-ssh1)#authorization commands 1 default 61200510L1-35E Line (SSH) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 549 Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example specifies a timeout of 2 minutes for all SSH sessions: (config)#line ssh 0 4 (config-ssh0-4)#line-timeout 2 61200510L1-35E Line (SSH) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 550 Release 11.1 Command was introduced. Usage Examples The following example enables the security login feature and specifies a password on all the available SSH sessions (0 through 4): (config)#line ssh 0 4 (config-ssh0-4)#login (config-ssh0-4)#password mypassword 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 551 SSH uses the local user database. Usage Examples The following example specifies that myList will be used for authenticating users connecting on this line: (config)#line ssh 2 (config-ssh2)#login authentication myList 61200510L1-35E Line (SSH) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 552 The following example creates a local userlist and enables the security login feature: (config)#username my_user password my_password (config)#line ssh 0 (config-ssh0)#login local-userlist When connecting to the unit, the following prompts are displayed: User Access Login Username: my_user Password: 61200510L1-35E Line (SSH) Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 553: Line (Telnet) Interface Config Command Set

    558 login authentication <aaa login list> login local-userlist on page 560 password [md5] <password> 61200510L1-35E Line (Telnet) Interface Config Command Set ONFIG OMMAND on page 555 on page 556 on page 559 on page 561 Copyright © 2005 ADTRAN...
  • Page 554 (config)#permit 192.22.56.0 0.0.0.255 Enter the line (telnet): (config)#line telnet 0 4 Associate the access list with the Telnet session: (config-telnet0-4)#access-class Trusted in 61200510L1-35E Line (Telnet) Interface Config Command Set on page 392 for more information about configuring Copyright © 2005 ADTRAN...
  • Page 555 Command History Release 11.1 Command was introduced. Usage Examples The following example applies the default accounting method to Telnet session 1: (config)#aaa on (config)#line telnet 1 (config-telnet1)#accounting commands 1 default 61200510L1-35E Line (Telnet) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 556 Command History Release 11.1 Command was introduced. Usage Examples The following example applies the default authorization method to line 1: (config)#aaa on (config)#line telnet 1 (config-telnet1)#authorization commands 1 default 61200510L1-35E Line (Telnet) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 557 This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example specifies a timeout of 2 minutes: (config)#line telnet 0 (config-telnet0)#line-timeout 2 61200510L1-35E Line (Telnet) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 558 Release 1.1 Command was introduced. Usage Examples The following example enables the security login feature and specifies a password on all the available Telnet sessions (0 through 4): (config)#line telnet 0 4 (config-telnet0-4)#login (config-telnet0-4)#password mypassword 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 559 Usage Examples The following example specifies that myList will be used for authenticating users connecting on this line: (config)#line telnet 2 (config-telnet2)#login authentication myList 61200510L1-35E Line (Telnet) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 560 The following example displays creating a local userlist and enabling the security login feature: (config)#username my_user password my_password (config)#line telnet 0 (config-telnet0)#login local-userlist When connecting to the unit, the following prompts are displayed: User Access Login Username: my_user Password: Router# 61200510L1-35E Line (Telnet) Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 561 To provide extra security, the AOS can encrypt the enable password when displaying the current configuration. For example, the following is a show configuration printout (password portion) with an unencrypted enable password (ADTRAN): enable password ADTRAN Alternately, the following is a show configuration printout (password portion) with an enable password of...

  • Page 562: Adsl Interface Config Command Set

    All other commands for this command set are described in this section in alphabetical order. retrain on page 563 snr-margin [showtime monitor | training monitor] <margin> training-mode [G.DMT | G.LITE | Multi-Mode | T1.413] 61200510L1-35E ONFIG OMMAND on page 565 Copyright © 2005 ADTRAN ADSL Interface Config Command Set on page 564...
  • Page 563 Applicable Platforms This command applies to the NetVanta 300, 1000R, 3000, 4000 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example forces a modem retrain: (config)#interface adsl 0/1 (config-adsl 0/1)#retrain 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 564 Release 8.1 Command was introduced. Usage Examples The following example enables SNR margin monitoring during showtime with a minimum level of 7 dB: (config)#interface adsl 0/1 (config-adsl 0/1)#snr-margin showtime monitor 7 61200510L1-35E ADSL Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 565 This command applies to the NetVanta 300, 1000R, 3000, 4000 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example sets the training mode to T1.413: (config)#interface adsl 0/1 (config-adsl 0/1)#training-mode T1.413 61200510L1-35E ADSL Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 566: Bri Interface Configuration Command Set

    <spid> <ldn> on page 575 isdn switch-type [basic-5ess | basic-dms | basic-net3 | basic-ni] resource pool-member <pool-name> [<cost>] 61200510L1-35E BRI Interface Configuration Command set OMMAND SET on page 573 on page 576 on page 577 Copyright © 2005 ADTRAN...
  • Page 567 Usage Examples The following example defines a bonding txadd-timer value of 95 seconds: (config)#interface bri 1/2 (config-bri 1/2)#bonding txadd-timer 95 61200510L1-35E BRI Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 568 Usage Examples The following example defines a bonding txcid-timer value of 8 seconds: (config)#interface bri 1/2 (config-bri 1/2)#bonding txcid-timer 8 61200510L1-35E BRI Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 569 Specifies the length of time both endpoints allot to attempt to equalize the network delay between the bearer channels before deciding the bonding call has failed. Usage Examples The following example defines a bonding txdeq-timer value of 80 seconds: (config)#interface bri 1/2 (config-bri 1/2)#bonding txdeq-timer 80 61200510L1-35E BRI Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 570 TXADD01. Usage Examples The following example defines a bonding txfa-timer value of 15 seconds: (config)#interface bri 1/2 (config-bri 1/2)#bonding txfa-timer 15 61200510L1-35E BRI Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 571 Usage Examples The following example defines a bonding txinit-timer value of 15 seconds: (config)#interface bri 1/2 (config-bri 1/2)#bonding txinit-timer 15 61200510L1-35E BRI Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 572 DTE equipment using the bonding module also has timer constraints for completing non-bonding parameter negotiation. Usage Examples The following example defines a bonding txnull-timer value of 8 seconds: (config)#interface bri 1/2 (config-bri 1/2)#bonding txnull-timer 8 61200510L1-35E BRI Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 573 Usage Examples The following example configures the unit to always provide the given number as the caller ID number: (config)#interface bri 1/2 (config-bri 1/2)#caller-id override always 5551000 61200510L1-35E BRI Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 574 The AOS does not support “SPID-less” 5ESS signaling. SPIDs are required for all configured BRI endpoints. Usage Examples The following example defines a SPID of 704 555 1111 0101 with an LDN of 555-1111: (config)#interface bri 1/2 (config-bri 1/2)#isdn spid1 70455511110101 5551111 61200510L1-35E BRI Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 575 The AOS does not support “SPID-less” 5ESS signaling. SPIDs are required for all configured BRI endpoints. Usage Examples The following example defines a SPID of 704 555 1111 0101 with and LDN of 555-1111: (config)#interface bri 1/2 (config-bri 1/2)#isdn spid2 70455511110101 5551111 61200510L1-35E BRI Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 576 National ISDN signaling on the BRI interface. Usage Examples The following example configures a BRI interface for a circuit with Lucent 5ESS (custom) signaling: (config)#interface bri 1/2 (config-bri 1/2)#isdn switch-type basic-5ess 61200510L1-35E BRI Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 577 Command History Release 11.1 Command was introduced. Usage Examples The following example configures a BRI interface as a member of resource pool MyPool: (config)#interface bri 1/2 (config-bri 1/2)#resource pool-member MyPool 61200510L1-35E BRI Interface Configuration Command set Copyright © 2005 ADTRAN...

  • Page 578: Dds Interface Configuration Command Set

    [dte | line | remote] remote-loopback on page 583 snmp trap on page 584 snmp trap link-status on page 585 61200510L1-35E DDS Interface Configuration Command Set OMMAND on page 579 on page 580 on page 582 Copyright © 2005 ADTRAN...
  • Page 579 See for related information. Usage Examples The following example configures the clock rate for 56 kbps operation: (config)#interface dds 1/1 (config-dds 1/1)#clock rate bps56k 61200510L1-35E DDS Interface Configuration Command Set data-coding scrambled Copyright © 2005 ADTRAN on page 581...
  • Page 580 Usage Examples The following example configures the unit to recover clocking from the circuit: (config)#interface dds 1/1 (config-dds 1/1)#clock source line 61200510L1-35E DDS Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 581: Data-Coding Scrambled

    Frame Relay or if using PPP to another device other than an AOS product also running scrambled. Usage Examples The following example enables the DDS OS scrambler: (config)#interface dds 1/1 (config-dds 1/1)#data-coding scrambled 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 582 This command applies to the NetVanta 1000R, 3000, and 4000 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example activates a line loopback on the DDS interface: (config)#interface dds 1/1 (config-dds 1/1)#loopback line 61200510L1-35E DDS Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 583: Remote-Loopback

    This command applies to the NetVanta 1000R, 3000, and 4000 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example enables remote loopbacks on the DDS interface: (config)#interface dds 1/1 (config-dds 1/1)#remote-loopback 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 584: Snmp Trap

    Release 5.1 Command was expanded to include Ethernet sub-interfaces and Gigabit Ethernet interfaces. Usage Examples The following example enables SNMP capability on the DDS interface: (config)#interface dds 1/1 (config-dds 1/1)#snmp trap 61200510L1-35E DDS Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 585: Snmp Trap Link-Status

    The snmp trap link-status command is used to control the RFC2863 ifLinkUpDownTrapEnable OID (OID number 1.3.6.1.2.1.31.1.1.1.14.0). Usage Examples The following example disables the link-status trap on the DDS interface: (config)#interface dds 1/1 (config-dds 1/1)#no snmp trap link-status 61200510L1-35E DDS Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 586: Interface Configuration Command Set

    [message-oriented | none | robbed-bit] snmp trap link-status on page 594 test-pattern [ones | zeros] on page 595 61200510L1-35E DSX-1 Interface Configuration Command Set ONFIGURATION OMMAND on page 590 on page 591 on page 593 Copyright © 2005 ADTRAN...
  • Page 587 The line coding configured in the unit must match the line coding of the DSX-1 circuit. A mismatch will result in line errors (e.g., BPVs). Usage Examples The following example configures the DSX-1 interface for AMI line coding: (config)#interface t1 1/2 (config-t1 1/2)#coding ami 61200510L1-35E DSX-1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 588 D4 and ESF are two methods of collecting and organizing frames over the circuit. Usage Examples The following example configures the DSX-1 interface for D4 framing: (config)#interface t1 1/2 (config-t1 1/2)#framing d4 61200510L1-35E DSX-1 Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 589: Line-Length

    266 to 399 feet • 400 to 533 feet • 534 to 655 feet Usage Examples The following example configures the DSX-1 interface line-length for 300 feet: (config)#interface t1 1/2 (config-t1 1/2)#line-length 300 61200510L1-35E DSX-1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 590 The following diagram depicts the difference between a line and payload loopback. NI CSU Line Loopback Usage Examples The following example initiates a payload loopback of the DSX-1 interface: (config)#interface t1 1/2 (config-t1 1/2)#loopback network payload 61200510L1-35E DSX-1 Interface Configuration Command Set T1 Network Interface Payload Loopback Copyright © 2005 ADTRAN...
  • Page 591 The following diagram depicts the difference between a line and payload loopback. NI CSU Line Loopback Usage Examples The following example initiates a remote line loopback using the inband channel: (config)#interface t1 1/2 (config-t1 1/2)#loopback remote line inband 61200510L1-35E DSX-1 Interface Configuration Command Set T1 Network Interface Copyright © 2005 ADTRAN...
  • Page 592 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example enables remote loopbacks on the DSX-1 interface: (config)#interface t1 1/2 (config-t1 1/2)#remote-loopback 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 593 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example configures the DSX-1 port for PRI compatibility: (config)#interface t1 1/2 (config-t1 1/2)#signaling-mode none 61200510L1-35E DSX-1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 594 The snmp trap link-status command is used to control the RFC2863 ifLinkUpDownTrapEnable OID (OID number 1.3.6.1.2.1.31.1.1.1.14.0). Usage Examples The following example disables the link-status trap on the DSX-1 interface: (config)#interface t1 1/2 (config-t1 1/2)#no snmp trap link-status 61200510L1-35E DSX-1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 595 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example activates the pattern generator for a stream of continuous ones: (config)#interface t1 1/2 (config-t1 1/2)#test-pattern ones 61200510L1-35E DSX-1 Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 596: E1 Interface Configuration Command Set

    [clear | insert | ones| p215 | p220 | p511 | qrss | zeros] ts16 on page 612 61200510L1-35E E1 Interface Configuration Command Set OMMAND on page 597 on page 601 on page 609 Copyright © 2005 ADTRAN on page 610 on page 611...
  • Page 597 When operating on a circuit that is providing timing, setting the clock source to line can avoid errors such as Clock Slip Seconds (CSS). Usage Examples The following example configures the unit to recover clocking from the primary circuit: (config)#interface e1 1/1 (config-e1 1/1)#clock source line 61200510L1-35E E1 Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 598: Coding [Ami | Hdb3]

    The line coding configured in the unit must match the line coding of the E1 circuit. A mismatch will result in line errors (e.g., BPVs). Usage Examples The following example configures the E1 interface for AMI line coding: (config)#interface e1 1/1 (config-e1 1/1)#coding ami 61200510L1-35E E1 Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 599: Framing [Crc4]

    The framing value must match the configuration of the E1 circuit. A mismatch will result in a loss of frame alarm. Usage Examples The following example configures the E1 interface for CRC-4 framing: (config)#interface e1 1/1 (config-e1 1/1)#framing crc4 61200510L1-35E E1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 600 Sa4. Usage Examples The following example enables detection of a loop alarm on the E1 interface: (config)#config e1 1/1 (config-e1 1/1)#loop-alarm-detect 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 601 The following diagram depicts a line loopback. NI CSU Usage Examples The following example initiates a line loopback of the E1 interface: (config)#interface e1 1/1 (config-e1 1/1)#loopback network line 61200510L1-35E E1 Interface Configuration Command Set 1 Network Interface ine oopback Copyright © 2005 ADTRAN...
  • Page 602 This command causes a V.54 inband loop code to be sent in the payload towards the far end. Usage Examples The following example sends a V.54 inband loop code to the far end: (config)#interface e1 1/1 (config-e1 1/1)#loopback remote v54 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 603 (Sa bits) in bit positions 4 through 8. Usage Examples The following example enables transmission of AIS in response to a loss of frame: config)#interface e1 1/1 (config-e1 1/1)#remote alarm ais 61200510L1-35E E1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 604 This controls the acceptance of any remote loopback requests. When enabled, remote loopbacks are detected and cause a loopback to be applied. When disabled, remote loopbacks are ignored. Usage Examples The following example enables remote loopbacks on the E1 interface: (config)#interface e1 1/1 (config-e1 1/1)#remote-loopback 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 605 Bits in position 4 through 8 are called spare bits. Values of 0 or 1 are accepted. TS0 odd frame Bit position Bit use RAI = 1 Usage Examples The following example sets the Tx value of Sa4 to 0: (config)#interface e1 1/1 (config-e1 1/1)#sa4tx-bit 0 61200510L1-35E E1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 606 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 7.1 Command was introduced. Usage Examples The following is sample output from this command: (config)#interface e1 1/1 (config-e1 1/1)#show test-pattern QRSS Errored Seconds: 6 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 607 The snmp trap line-status command is used to control the RFC2495 dsx1LineStatusChangeTrapEnable OID (OID number 1.3.6.1.2.1.10.18.6.1.17.0). Usage Examples The following example disables the line-status trap on the T1 interface: (config)#interface e1 1/1 (config-t1 1/1)#no snmp trap line-status 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 608: Snmp Trap Link-Status

    The snmp trap link-status command is used to control the RFC 2863 ifLinkUpDownTrapEnable OID (OID number 1.3.6.1.2.1.31.1.1.1.14.0). Usage Examples The following example disables the link-status trap on the E1 interface: (config)#interface e1 1/1 (config-e1 1/1)#no snmp trap link-status 61200510L1-35E E1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 609 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example disables SNMP threshold reached trap on the E1 interface: (config)#interface e1 1/1 (config-e1 1/1)#no snmp trap threshold-reached 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 610 The following example creates a TDM group (labeled 5) of 10 DS0s at 64 kbps each: (config)#interface e1 1/1 (config-e1 1/1)#tdm-group 5 timeslots 1-10 speed 64 61200510L1-35E E1 Interface Configuration Command Set on page 1045 for related information. Copyright © 2005 ADTRAN...
  • Page 611 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example activates the pattern generator for a stream of continuous ones: (config)#interface e1 1/1 (config-e1 1/1)#test-pattern ones 61200510L1-35E E1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 612 Applicable Platforms This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example enables timeslot 16 multiframing: (config)#interface e1 1/1 (config-e1 1/1)#ts16 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 613: Ethernet Interface Configuration Command Set

    To activate the Ethernet Configuration mode for a range of Ethernet interfaces, enter the interface range command at the Global Configuration mode prompt. For example: >enable #configure terminal (config)#interface range ethernet 0/1, 0/8 (config-eth 0/1, 0/8)# 61200510L1-35E Ethernet Interface Configuration Command Set ONFIGURATION OMMAND Copyright © 2005 ADTRAN...
  • Page 614 - Assign access control policy for this interface - A text name assigned by an SNMP NMS - Set ARP commands - Set bandwidth informational parameter - Assign the current interface to a bridge group on page 618 on page 627 Copyright © 2005 ADTRAN...
  • Page 615 <rate> <burstrate> 61200510L1-35E Ethernet Interface Configuration Command Set on page 630 on page 631 on page 634 on page 635 on page 645 on page 648 on page 663 Copyright © 2005 ADTRAN on page 633 on page...
  • Page 616 Release 5.1 Command was expanded to include Ethernet sub-interfaces and Gigabit Ethernet interfaces. Usage Examples The following example enables standard ARP for the Ethernet interface: (config)#interface eth 0/1 (config-eth 0/1)#arp arpa 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 617 (e.g., Ethernet to T1 bridge, Ethernet to Frame Relay sub-interface). Usage Examples The following example assigns the Ethernet interface to bridge-group 17: (config)#interface eth 0/1 (config-eth 0/1)#bridge-group 17 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 618 Statically adds the interface to a channel group. Default Values By default, the interface is not part of a channel group. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced.

  • Page 619: Crypto Map

    This allows you to apply multiple crypto maps if you have created maps which share the same name but have different map index numbers. For VPN configuration example scripts, refer to the technical support note Configuring VPN located on the ADTRAN OS Documentation CD provided with your unit. Syntax Description <mapname>...
  • Page 620 The destination information is the local side. Usage Examples The following example applies all crypto maps with the name MyMap to the Ethernet interface: (config)#interface eth 0/1 (config-eth 0/1)#crypto map MyMap 61200510L1-35E Ethernet Interface Configuration Command Set Static Filter (out) IPSec Encrypt Copyright © 2005 ADTRAN...
  • Page 621 IP address. Unlike a Dynamic DNS host, a Static DNS host does not expire after 35 days without updates, but updates take longer to propagate though the DNS system. This service is provided for up to five hostnames. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 622 IP address support. Usage Examples The following example sets the dynamic-dns to dyndns-custom with hostname host, username user, and password pass: (config)#interface eth 0/1 (config-eth 0/1)#dynamic-dns dyndns-custom host user pass 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 623: Full-Duplex

    Refer to speed [10 | 100 | auto | nonegotiate] more information. The 10BaseT, 100BaseTX, and 100BaseFX signalling systems support full-duplex operation (because they have transmit and receive signal paths that can be simultaneously active). 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN on page 645...
  • Page 624 Command Reference Guide Ethernet Interface Configuration Command Set Usage Examples The following example configures the Ethernet interface for full-duplex operation: (config)#interface ethernet 0/1 (config-eth 0/1)#full-duplex 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 625: Half-Duplex

    Refer to speed [10 | 100 | auto | nonegotiate] for more information. Usage Examples The following example configures the Ethernet interface for half-duplex operation: (config)#interface ethernet 0/1 (config-eth 0/1)#half-duplex 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN on page 645...

  • Page 626: Lldp Receive

    This command applies to the NetVanta 300, 1000, 1000R, 2000, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example configures Ethernet interface 0/1 to receive LLDP packets: (config)#interface eth 0/1 (config-eth 0/1)#lldp receive 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 627 For example, use the lldp send and-receive command to enable transmit and receive of all LLDP information. Then use the no lldp send port-description command to prevent LLDP from transmitting port description information. 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 628 The following example configures Ethernet interface 0/1 to transmit LLDP packets containing all enabled information types: (config)#interface eth 0/1 (config-eth 0/1)#lldp send The following example configures Ethernet interface 0/1 to transmit and receive LLDP packets containing all information types: (config)#interface eth 0/1 (config-eth 0/1)#lldp send-and-receive 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 629: Mac Address

    Use the mac-address command to specify the Media Access Control (MAC) address of the unit. Only the last three values of the MAC address can be modified. The first three values contain the ADTRAN reserved number (00:0A:C8) by default. Use the no form of this command to return to the default MAC address programmed by ADTRAN.
  • Page 630 Default Values By default, e authentication mode is port-based. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 10.1 Command was introduced. Usage Examples The following example configures the unit for MAC-based authentication mode:...
  • Page 631 Blocks only incoming traffic when the port becomes unauthorized. Default Values By default, traffic is blocked in both directions. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 10.1 Command was introduced. Usage Examples...
  • Page 632 Syntax Description No subcommands. Default Values By default, this command is disabled. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 10.1 Command was introduced. Usage Examples The following example enables multiple hosts to access an authorized port:...
  • Page 633 Forces the port into an unauthorized state. Default Values By default, all ports are forced to an authorized state. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 10.1 Command was introduced. Usage Examples...
  • Page 634 Command History Release 9.1 Command was introduced. Usage Examples The following example configures the ethernet interface to detect and supply power to PDs: (config)#interface ethernet 0/3 (config-eth 0/3)#power inline auto 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 635 (0 to 7). Default Values By default, the interface is untrusted with a default CoS of 0. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Functional Notes Set the interface to trust cos if received 802.1P CoS values are considered valid (i.e., no need to...
  • Page 636 Release 5.1 Command was expanded to include Ethernet sub-interfaces and Gigabit Ethernet interfaces. Usage Examples The following example enables SNMP capability on the Ethernet interface: (config)#interface eth 0/1 (config-eth 0/1)#snmp trap 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 637: Snmp Trap Link-Status

    The snmp trap link-status command is used to control the RFC2863 ifLinkUpDownTrapEnable OID (OID number 1.3.6.1.2.1.31.1.1.1.14.0). Usage Examples The following example disables the link-status trap on the interface: (config)#interface ethernet 0/1 (config-eth 0/1)#no snmp trap link-status 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 638 (config)#interface eth 0/3 (config-eth 0/3)#spanning-tree bpdufilter enable The BPDU filter can be disabled on the eth 0/3 by issuing the following commands: (config)#interface eth 0/3 (config-eth 0/3)#spanning-tree bpdufilter disable 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN on page...
  • Page 639 (config)#interface eth 0/3 (config-eth 0/3)#spanning-tree bpduguard enable The BPDU guard can be disabled on the eth 0/3 by issuing the following commands: (config)#interface eth 0/3 (config-eth 0/3)#spanning-tree bpduguard disable 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN on page...

  • Page 640: Spanning-Tree Cost

    Specifies a cost value of 1 to 200,000,000. Default Values By default, the cost value is set to 1000/(link speed in Mbps). Applicable Platforms This command applies to the NetVanta 300 and 1000R Series units. Command History Release 5.1 Command was introduced.

  • Page 641: Spanning-Tree Edgeport

    The following example configures the interface to be an edgeport: (config)#interface eth 0/1 (config-eth 0/1)#spanning-tree edgeport An individual interface can be configured to not be considered an edgeport. For example: (config)#interface ethernet 0/1 (config-eth 0/1)#no spanning-tree edgeport 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 642 Usage Examples The following example forces the link type to point-to-point, even if the port is configured to be half-duplex: (config)#interface eth 0/3 (config-eth 0/3)#spanning-tree link-type point-to-point 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 643 This command applies to the NetVanta 1000, 1000R, 3000, 4000, and 5000 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example specifies that the spanning tree protocol use a long pathcost method: (config)#spanning-tree pathcost method long 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 644: Spanning-Tree Port-Priority

    Usage Examples The following example sets the interface to a priority of 100: (config)#interface eth 0/3 (config-eth 0/3)#spanning-tree port-priority 100 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 645 Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example configures the Ethernet port for 100 Mb operation: (config)#interface ethernet 0/1 (config-eth 0/1)#speed 100 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 646 AOS to no longer block packets. This level must be less than the rising level. Range: 0 to 100 percent. Default Values By default, storm-control is disabled. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Functional Notes This setting configures the rising and falling suppression values.
  • Page 647 (config-eth 0/1)#storm-control multicast level 85 The following example sets the rising suppression level to 80 percent for broadcast packets, with a falling level of 50 percent: (config)#interface eth 0/1 (config-eth 0/1)#storm-control broadcast level 80 50 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 648 Shuts down the interface during a storm. Default Values By default, this command is disabled; the interface will only filter traffic. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced.

  • Page 649: Switchport Access Vlan

    Specifies a valid VLAN interface ID (1 to 4094). Default Values By default, this is set to VLAN 1 (the default VLAN). Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced.

  • Page 650: Switchport Gvrp

    Syntax Description No subcommands. Default Values By default, GVRP is disabled on all ports. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Functional Notes Enabling GVRP on any interface enables GVRP globally.
  • Page 651 Sets port to transmit and receive packets on all VLANs included within its VLAN allowed list. Default Values By default, switchport mode is set to access. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced. Functional Notes Configuring the interface for stack mode (using the switchport mode stack command) enables the switch to communicate with other switches that it is stacking capable.

  • Page 652: Switchport Protected

    Syntax Description No subcommands. Default Values This command is disabled by default. Applicable Platforms This command applies to the NetVanta 1000 and 1000R Series units. Command History Release 10.1 Command was introduced. Usage Example In the example below, all three of the ports are on VLAN 3, and eth 0/1 and eth 0/2 are designated as protected ports.

  • Page 653: Switchport Port-Security

    Syntax Description No subcommands. Default Values This command is disabled by default. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Functional Notes You cannot enable port security on a port that is already configured as the following: •...
  • Page 654 Configures the address to be removed after the specified time, regardless of activity. Default Values By default, dynamic and static aging are disabled. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples...
  • Page 655 Configures the interface to shut down after the specified time, regardless of activity. Default Values By default, this command is disabled and set to type absolute. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples...

  • Page 656: Switchport Port-Security Mac-Address

    MAC address is not specified. Default Values By default, sticky learning is disabled and there are no configured MAC addresses. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced.

  • Page 657: Switchport Port-Security Maximum

    Specifies the maximum number of secure MAC addresses to be associated with the interface. Range: 1 to 132. Default Values The default value for this command is 1. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples...
  • Page 658 Default Values The default for this command is shutdown. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced. Usage Examples...
  • Page 659 Specifies a list of valid VLAN interface IDs. Refer to Functional Notes, below. Default Values By default, all valid VLANs are allowed. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced.
  • Page 660 Default Values By default, no VLANs are in the VLAN GVRP trunking fixed list (switchport trunk fixed vlan none). Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 8.1 Command was introduced.
  • Page 661 The following example changes the configured list of fixed VLANs to include only VLANs 1 to 1000: (config-eth 0/20)#switchport trunk fixed vlan 1-1000 The following example changes the configured list of fixed VLANs to include no VLANs (except those VLANs that are native): (config-eth 0/20)#switchport trunk fixed vlan none 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 662: Switchport Trunk Native Vlan

    Specifies a valid VLAN interface ID (1 to 4094). Default Values By default, this is set to VLAN 1. Applicable Platforms This command applies to the NetVanta 300, 1000, and 1000R Series units. Command History Release 5.1 Command was introduced.
  • Page 663 The following example sets the outbound rate of eth 0/1 to 128 kbps and applies a QoS policy that all RTP traffic is given priority over all other traffic: (config)#qos map voip 1 (config-qos-map)#match ip rtp 10000 10500 all (config-qos-map)#priority unlimited (config-qos-map)#interface eth 0/1 (config-eth)#traffic-shape rate 128000 (config-eth)#qos-policy out voip 61200510L1-35E Ethernet Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 664: Interface Configuration Command Set

    666 loopback network [line | payload] snmp trap link-status on page 668 test-pattern [ones | zeros] on page 669 ts16 on page 670 61200510L1-35E G.703 Interface Configuration Command set ONFIGURATION OMMAND SET on page 667 Copyright © 2005 ADTRAN...
  • Page 665 The line coding configured in the unit must match the line coding of the E1 circuit. A mismatch will result in line errors (e.g., BPVs). Usage Examples The following example configures the G.703 interface for AMI line coding: (config)#interface e1 1/2 (config-e1 1/2)#coding ami 61200510L1-35E G.703 Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 666 The framing value must match the configuration of the E1 circuit. A mismatch will result in a loss of frame alarm. Usage Examples The following example configures the G.703 interface for CRC4 framing: (config)#interface e1 1/2 (config-e1 1/2)#framing crc4 61200510L1-35E G.703 Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 667 The following diagram depicts a line loopback. NI CSU Usage Examples The following example initiates a line loopback of the G.703 interface: (config)#interface e1 1/2 (config-e1 1/2)#loopback network line 61200510L1-35E G.703 Interface Configuration Command set 1 Network Interface ine oopback Copyright © 2005 ADTRAN...

  • Page 668: Snmp Trap Link-Status

    The snmp trap link-status command is used to control the RFC 2863 ifLinkUpDownTrapEnable OID (OID number 1.3.6.1.2.1.31.1.1.1.14.0). Usage Examples The following example disables the link-status trap on the G.703 interface: (config)#interface e1 1/2 (config-e1 1/2)#no snmp trap link-status 61200510L1-35E G.703 Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 669 Command was expanded to include E1 and G.703 interfaces. Usage Examples The following example activates the pattern generator for a stream of continuous ones: (config)#interface e1 1/2 (config-e1 1/2)#test-pattern ones 61200510L1-35E G.703 Interface Configuration Command set Copyright © 2005 ADTRAN...
  • Page 670 Applicable Platforms This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example enables timeslot 16 multiframing: (config)#interface e1 1/2 (config-e1 1/2)#ts16 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 671: Modem Interface Configuration Command Set

    All other commands for this command set are described in this section in alphabetical order. caller-id override [always <number> | if-no-cid <number>] dialin on page 673 init-string <string> on page 674 resource pool-member <pool-name> [<cost>] 61200510L1-35E Modem Interface Configuration Command Set ONFIGURATION OMMAND on page 675 Copyright © 2005 ADTRAN on page 672...
  • Page 672 Usage Examples The following example configures the unit to always provide the given number as the caller ID number: (config)#interface modem 1/2 (config-modem 1/2)#caller-id override always 5555555 61200510L1-35E Modem Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 673 Applicable Platforms This command applies to the NetVanta 1000R, 3000, and 4000 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example enables remote console dial-in: (config)#interface modem 1/2 (config-modem 1/2)#dialin 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 674 All initialization strings must begin with AT. Disables command echo. Response messages on. Formats result codes in long word form. Specifies extended response set, dial tone, and busy signal detection for result codes following modem operations. Selects standard buffered connection only. Copyright © 2005 ADTRAN...
  • Page 675 Command History Release 11.1 Command was introduced. Usage Examples The following example configures a BRI interface as a member of resource pool MyPool: (config)#interface modem 1/2 (config-modem 1/2)#resource pool-member MyPool 61200510L1-35E Modem Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 676: Serial Interface Configuration Command Set

    681 serial-mode [eia530 | v35 | x21] snmp trap on page 683 snmp trap link-status on page 684 61200510L1-35E Serial Interface Configuration Command Set ONFIGURATION OMMAND on page 677 on page 682 Copyright © 2005 ADTRAN...
  • Page 677 Usage Examples The following example configures the serial interface to recover the clock signal from the received signal and use it to generate et-clock: (config)#interface serial 1/1 (config-ser 1/1)#et-clock-source rxclock 61200510L1-35E Serial Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 678 DCD is not present. When configured to ignore DCD, the serial interface will continue to attempt to establish a connection even when DCD is not present. Usage Examples The following example configures the serial interface to ignore a loss of the DCD signal: (config)#interface serial 1/1 (config-ser 1/1)#ignore dcd 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 679 If the serial interface cable is long, causing a phase shift in the data, the et-clock can be inverted using the invert etclock command. This switches the phase of the clock, which compensates for a long cable. Usage Examples The following example configures the serial interface to invert et-clock: (config)#interface serial 1/1 (config-ser 1/1)#invert etclock 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 680 If the transmit clock of the connected device is inverted, use the invert rxclock command to configure the receiving interface appropriately. Usage Examples The following example configures the serial interface to invert receive clock: (config)#interface serial 1/1 (config-ser 1/1)#invert rxclock 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 681: Invert Txclock

    If the transmit clock of the connected device is inverted, use the invert rxclock command to configure the receiving interface appropriately. Usage Examples The following example configures the serial interface to invert the transmit clock: (config)#interface serial 1/1 (config-ser 1/1)#invert txclock 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 682 Functional Notes The pinouts for each of the available interfaces can be found in the Hardware Configuration Guide located on the ADTRAN OS Documentation CD (provided in shipment). Usage Examples The following example configures the serial interface to work with the X.21 adapter cable:...
  • Page 683 Release 5.1 Command was expanded to include Ethernet sub-interfaces and Gigabit Ethernet interfaces. Usage Examples The following example enables SNMP on the serial interface: (config)#interface serial 1/1 (config-ser 1/1)#snmp trap 61200510L1-35E Serial Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 684: Snmp Trap Link-Status

    The snmp trap link-status command is used to control the RFC 2863 ifLinkUpDownTrapEnable OID (OID number 1.3.6.1.2.1.31.1.1.1.14.0). Usage Examples The following example disables the link-status trap on the serial interface: (config)#interface serial 1/1 (config-ser 1/1)#no snmp trap link-status 61200510L1-35E Serial Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 685: Shdsl Interface Configuration Command Set

    693 loopback remote inband on page 694 outage-retrain on page 695 test-pattern [clear | insert | 2^15 | show] 61200510L1-35E SHDSL Interface Configuration Command Set ONFIGURATION OMMAND on page 686 on page 690 on page 696 Copyright © 2005 ADTRAN...
  • Page 686 This command applies to the NetVanta 1000R, 3000, and 4000 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example sets the loop attenuation threshold at 45 dB: (config)#interface shdsl 1/1 (config-shdsl 1/1)#alarm-threshold loop-attenuation 45 61200510L1-35E SHDSL Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 687 “inactive” image and the new recently updated code becomes the “active” image. Usage Examples The following example causes the firmware upgrade to take effect: (config)#interface shdsl 1/1 (config-shdsl 1/1)#boot alternate-image 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 688 This command applies to the NetVanta 1000R, 3000, and 4000 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example changes the operating mode of the SHDSL interface to CO: (config)#interface shdsl 1/1 (config-shdsl 1/1)#equipment-type co 61200510L1-35E SHDSL Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 689 This command applies to the NetVanta 1000R, 3000, and 4000 Series units. Command History Release 4.1 Command was introduced. Usage Examples The following example disables inband loopback pattern detection: (config)#interface shdsl 1/1 (config-shdsl 1/1)#no inband-detection 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 690 PN127 and V.54 are industry-standard loopback patterns used to allow remote loopbacks. Usage Examples The following example sets the inband loopback pattern for PN127: (config)#interface shdsl 1/1 (config-shdsl 1/1)#inband-protocol pn127 61200510L1-35E SHDSL Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 691 The following example changes the line rate of the SHDSL interface to 264 kbps: (config)#interface shdsl 1/1 (config-shdsl 1/1)#linerate 264 61200510L1-35E SHDSL Interface Configuration Command Set 688). The first two selections listed in the CLI (72 and 136 kbps) are not Copyright © 2005 ADTRAN...

  • Page 692: Loopback Network

    This command applies to the NetVanta 1000R, 3000, and 4000 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example initiates a loopback on the SHDSL interface: (config)#interface shdsl 1/1 (config-shdsl 1/1)#loopback network 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 693: Loopback Remote

    This command applies to the NetVanta 1000R, 3000, and 4000 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example initiates a remote line loopback: (config)#interface shdsl 1/1 (config-shdsl 1/1)#loopback remote 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 694 Release 4.1 Command was introduced. Usage Examples The following example injects a loop-down pattern into the data stream, causing existing loopbacks at the far end to stop: (config)#interface shdsl 1/1 (config-shdsl 1/1)#no loopback remote inband 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 695 This command applies to the NetVanta 1000R, 3000, and 4000 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example forces a retrain sequence on the SHDSL interface: (config)#interface shdsl 1/1 (config-shdsl 1/1)#outage-retrain 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 696 This command applies to the NetVanta 1000R, 3000, and 4000 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example sends a 2 (config)#interface shdsl 1/1 (config-shdsl 1/1)#test-pattern 2^15 61200510L1-35E SHDSL Interface Configuration Command Set test pattern: Copyright © 2005 ADTRAN...

  • Page 697: T1 Interface Configuration Command Set

    [clear | insert | ones | p215 | p220 | p511 | qrss | zeros] 61200510L1-35E T1 Interface Configuration Command Set OMMAND on page 702 on page 711 Copyright © 2005 ADTRAN on page 698 on page 712 on page 713...
  • Page 698 When operating on a circuit that is providing timing, setting the clock source to line can avoid errors such as Clock Slip Seconds (CSS). Usage Examples The following example configures the unit to recover clocking from the primary circuit: (config)#interface t1 1/1 (config-t1 1/1)#clock source line 61200510L1-35E T1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 699 The line coding configured in the unit must match the line coding of the T1 circuit. A mismatch will result in line errors (e.g., BPVs). Usage Examples The following example configures the T1 interface for AMI line coding: (config)#interface t1 1/1 (config-t1 1/1)#coding ami 61200510L1-35E T1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 700 FDL allows the transmission of trouble flags such as the Yellow Alarm signal. Refer to page 701 for related information. Usage Examples The following example disables the FDL channel for the T1 circuit: (config)#interface t1 1/1 (config-t1 1/1)#fdl none 61200510L1-35E T1 Interface Configuration Command Set Copyright © 2005 ADTRAN framing [d4 | esf]...
  • Page 701 D4 and ESF are two methods of collecting and organizing frames over the circuit. Usage Examples The following example configures the T1 interface for D4 framing: (config)#interface t1 1/1 (config-t1 1/1)#framing d4 61200510L1-35E T1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 702 (measured in cable length), the greater the attenuation value. For example, two units in close proximity should be configured for the maximum attenuation (-22.5 dB). Usage Examples The following example configures the T1 interface LBO for -22.5 dB: (config)#interface t1 1/1 (config-t1 1/1)#lbo -22.5 61200510L1-35E T1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 703 The following diagram depicts the difference between a line and payload loopback. NI CSU Line Loopback Usage Examples The following example initiates a payload loopback of the T1 interface: (config)#interface t1 1/1 (config-t1 1/1)#loopback network payload 61200510L1-35E T1 Interface Configuration Command Set T1 Network Interface Payload Loopback Copyright © 2005 ADTRAN...
  • Page 704 NI CSU Line Loopback Usage Examples The following example initiates a remote line loopback using the FDL: (config)#interface t1 1/1 (config-t1 1/1)#loopback remote line fdl 61200510L1-35E T1 Interface Configuration Command Set T1 Network Interface Payload Loopback Copyright © 2005 ADTRAN...
  • Page 705 The following diagram depicts the difference between a line and payload loopback. T1 Network Interface NI CSU Payload Loopback Line Loopback Usage Examples The following example initiates a remote payload loopback: (config)#interface t1 1/1 (config-t1 1/1)#loopback remote payload 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 706 Command was expanded to include the T1 interface. Usage Examples The following example enables transmission of RAI in response to a loss of frame: (config)#interface t1 1/1 (config-t1 1/1)#remote-alarm rai 61200510L1-35E T1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 707 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example enables remote loopbacks on the T1 interface: (config)#interface t1 1/1 (config-t1 1/1)#remote-loopback 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 708 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 7.1 Command was introduced. Usage Examples The following is sample output from this command: (config)#interface t1 1/1 (config-t1 1/1)#show test-pattern QRSS Errored Seconds: 6 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 709 The snmp trap line-status command is used to control the RFC2495 dsx1LineStatusChangeTrapEnable OID (OID number 1.3.6.1.2.1.10.18.6.1.17.0). Usage Examples The following example disables the line-status trap on the T1 interface: (config)#interface t1 1/1 (config-t1 1/1)#no snmp trap line-status 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 710: Snmp Trap Link-Status

    The snmp trap link-status command is used to control the RFC2863 ifLinkUpDownTrapEnable OID (OID number 1.3.6.1.2.1.31.1.1.1.14.0). Usage Examples The following example disables the link-status trap on the T1 interface: (config)#interface t1 1/1 (config-t1 1/1)#no snmp trap link-status 61200510L1-35E T1 Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 711 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example disables SNMP threshold reached trap on the T1 interface: (config)#interface t1 1/1 (config-t1 1/1)#no snmp trap threshold-reached 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 712 The following example creates a TDM group (labeled 5) of 10 DS0s at 64 kbps each: (config)#interface t1 1/1 (config-t1 1/1)#tdm-group 5 timeslots 1-10 speed 64 61200510L1-35E T1 Interface Configuration Command Set on page 1045 for related information. Copyright © 2005 ADTRAN...
  • Page 713 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example activates the pattern generator for a stream of continuous ones: (config)#interface t1 1/1 (config-t1 1/1)#test-pattern ones 61200510L1-35E T1 Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 714: Atm Interface Config Command Set

    35 All other commands for this command set are described in this section in alphabetical order. snmp trap on page 715 snmp trap link-status on page 716 61200510L1-35E ATM Interface Config Command Set OMMAND Copyright © 2005 ADTRAN...
  • Page 715 Command was expanded to include Ethernet sub-interfaces and Gigabit Ethernet interfaces. Release 8.1 Command was expanded to include ATM interfaces. Usage Examples The following example enables SNMP on the ATM interface: (config)#interface atm 1 (config-atm 1)#snmp trap 61200510L1-35E ATM Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 716 The snmp trap link-status command is used to control the RFC2863 ifLinkUpDownTrapEnable OID (OID number 1.3.6.1.2.1.31.1.1.1.14.0). Usage Examples The following example disables the link-status trap on the ATM interface: (config)#interface atm 1 (config-atm 1)#no snmp trap link-status 61200510L1-35E ATM Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 717: Atm Sub-Interface Config Command Set

    <mapname> spanning-tree commands begin on page 776 61200510L1-35E ATM Sub-Interface Config Command Set ONFIG OMMAND on page 718 on page 744 on page 746 on page 769 on page 771 on page 772 on page 774 Copyright © 2005 ADTRAN...

  • Page 718: Access-Policy

    ATM sub-interface labeled 1.1: Enable the AOS security features: (config)#ip firewall Create the access list (this is the packet selector): (config)#ip access-list extended InWeb (config-ext-nacl)#permit tcp any host 63.12.5.253 eq 80 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 719 All packets passed by the access list(s) entered and destined for the interface using the access policy listed will be permitted to enter the router system. This allows for configurations to permit packets to a single interface and not the entire system. 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 720 Apply the created access policy to an interface. To assign an access policy to an interface, enter interface configuration mode for the desired interface and enter access policy <policy name>. The following example assigns access policy MatchAll to the ATM sub-interface: (config)#interface atm 1.1 (config-atm 1.1)#access-policy MatchAll 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 721 This command applies to the NetVanta 300, 1000R, 3000, and 4000 Series units. Command History Release 9.1 Command was introduced. Usage Examples The following example enables routed bridge encapsulation: (config)#interface atm 1.1 (config-atm 1.1)#atm routed-bridged ip 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 722 This is a routing parameter only and does not affect the physical interface. Usage Examples The following example sets bandwidth of the ATM sub-interface to 10 Mbps: (config)#interface atm 1.1 (config-atm 1.1)#bandwidth 10000 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 723 (Ethernet to T1 bridge, Ethernet to Frame Relay sub-interface). Usage Examples The following example assigns the ATM sub-interface labeled 1.1 to bridge group 1: (config)#interface atm 1.1 (config-atm 1.1)#bridge-group 1 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 724: Crypto Map

    This allows you to apply multiple crypto maps if you have created maps which share the same name but have different map index numbers. For VPN configuration example scripts, refer to the technical support note Configuring VPN located on the ADTRAN OS Documentation CD provided with your unit. Syntax Description <mapname>...
  • Page 725 The destination information is the local side. Usage Examples The following example applies all crypto maps with the name MyMap to the ATM sub-interface: (config)#interface atm 1.1 (config-atm 1.1)#crypto map MyMap 61200510L1-35E ATM Sub-Interface Config Command Set Static Filter (out) IPSec Encrypt Copyright © 2005 ADTRAN...
  • Page 726 Command History Release 1.1 Command was introduced. Release 8.1 ATM sub-interface was added. Usage Examples The following example enables automatic dial-backup on the endpoint: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup auto-backup 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 727 Release 8.1 ATM sub-interface was added. Usage Examples The following configures the AOS to automatically restore the primary connection when the failure condition clears: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup auto-restore 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 728 Usage Examples The following example configures the AOS to wait 60 seconds (on an endpoint with an active alarm condition) before attempting dial-backup operation: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup backup-delay 60 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 729 Answers and backs up primary link on failure. Answers and backs up regardless of primary link state. Originates backup call on primary link failure. Originates or answers call on primary link failure. Originates on failure; answers and backs up always. Copyright © 2005 ADTRAN...
  • Page 730 192.168.100.254 255.255.255.0 no shutdown interface modem 1/3 no shutdown interface t1 1/1 coding b8zs framing esf clock source line tdm-group 1 timeslots 1-24 no shutdown interface fr 1 point-to-point 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 731 3. If a match is found, the call connects and the AOS pulls down the primary connection if it is not already in a down state. 4. If no match is found from Caller ID, the call is terminated. 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN dial-backup number on page...
  • Page 732 Release 8.1 ATM sub-interface was added. Usage Examples The following example configures the AOS to wait 120 seconds before retrying a failed dial-backup call: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup connect-timeout 120 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 733 Command was introduced. Release 8.1 ATM sub-interface was added. Usage Examples The following example configures the AOS to force this endpoint into dial-backup: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup force backup 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 734 ATM sub-interface was added. Usage Examples The following example configures the AOS to retry a dial-backup call 4 times before considering backup operation not available: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup maximum-retry 4 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 735 The following example configures the AOS to dial 704-555-1212 (digital 64 kbps connection) to initiate dial-backup operation on this endpoint: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup number 7045551212 digital-64k 1 1 atm 3.1 61200510L1-35E ATM Sub-Interface Config Command Set on page 729. Copyright © 2005 ADTRAN...
  • Page 736 Release 1.1 Command was introduced. Release 8.1 ATM sub-interface was added. Usage Examples The following example assigns the highest priority to this endpoint: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup priority 100 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 737 Command was introduced. Release 8.1 ATM sub-interface was added. Usage Examples The following example configures the AOS to randomize the dial-backup timers associated with this endpoint: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup randomize-timers 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 738 Command was introduced. Release 8.1 ATM sub-interface was added. Usage Examples The following example configures a redial delay of 25 seconds on this endpoint: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup redial-delay 25 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 739 Usage Examples The following example configures the AOS to wait 30 seconds before disconnecting dial-backup operation and restoring the primary connection for this endpoint: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup restore-delay 30 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 740 The following example enables dial-backup Monday through Friday 8:00 am to 7:00 pm: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup schedule enable-time 08:00 (config-atm 1.1)#dial-backup schedule disable-time 19:00 (config-atm 1.1)#no dial-backup schedule day Saturday (config-atm 1.1)#no dial-backup schedule day Sunday 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 741 This command applies to the NetVanta 1000R, 3000, and 4000 Series units. Command History Release 1.1 Command was introduced. Release 8.1 ATM sub-interface was added. Usage Examples The following example deactivates the configured dial-backup interface: (config)#interface atm 1.1 (config-atm 1.1)#dial-backup shutdown 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 742 IP address. Unlike a Dynamic DNS host, a Static DNS host does not expire after 35 days without updates, but updates take longer to propagate though the DNS system. This service is provided for up to five hostnames. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 743 IP address support. Usage Examples The following example sets the dynamic-dns to dyndns-custom with hostname host, username user, and password pass: (config)#interface atm 1.1 (config-atm 1.1)#dynamic-dns dyndns-custom host user pass 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 744 For IP with bridging, the encapsulation type can only be aal5snap. For bridging, the encapsulation type can only be aal5snap. Usage Examples The following example sets the encapsulation type to all5snap: (config)#interface atm 1.1 (config-atm 1.1)#encapsulation aal5snap 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 745 Command was introduced. Release 8.1 ATM sub-interface was added. Usage Examples The following example enables WFQ on the interface with a threshold set at 100 packets: (config)#interface atm 1.1 (config-atm 1.1)#fair-queue 100 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 746 Release 5.1 Command was introduced. Release 8.1 ATM sub-interface was added. Usage Examples The following example sets the overall output queue size to 700: (config)#interface atm 1.1 (config-atm 1.1)#hold-queue 700 out 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 747 The following example sets up the router to only allow Telnet traffic into the ATM sub-interface: (config)#ip access-list extended TelnetOnly (config-ext-nacl)#permit tcp any any eq telnet (config-ext-nacl)#interface atm 1.1 (config-atm 1.1)#ip access-group TelnetOnly in 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 748: Ip Address Dhcp

    (For units with a single Ethernet interface, the MAC ADDRESS assigned to Ethernet 0/1 is used in this field). 61200510L1-35E ATM Sub-Interface Config Command Set on page 1334 Copyright © 2005 ADTRAN for a detailed on page 1334 for a detailed...
  • Page 749 Release 2.1 Command was introduced. Release 8.1 Command was expanded to include ATM sub-interface. 61200510L1-35E ATM Sub-Interface Config Command Set FECN BECN 16 / 0x0401 50 / 0x0C21 60 / 0x0CC1 70 / 0x1061 80 / 0x1401 Copyright © 2005 ADTRAN...
  • Page 750 Using DHCP reduces the number of dedicated IP addresses the ISP must obtain. Consult your ISP to determine the proper values for the client-id and hostname fields. Usage Examples The following example enables DHCP operation on the ATM sub-interface 1.1: (config)#interface atm 1.1 (config-atm 1.1)#ip address dhcp 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 751 IP addresses on the secondary subnet. Usage Examples The following example configures a secondary IP address of 192.22.72.101/30: (config)#interface atm 1.1 (config-atm 1.1)#ip address 192.22.72.101 255.255.255.252 secondary 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 752 Command was introduced. Release 8.1 ATM sub-interface was added. Usage Examples The following example releases the IP DHCP address for the ATM sub-interface 1.1: (config)#interface atm 1.1 (config-atm 1.1)#ip dhcp release 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 753: Ip Helper-Address

    3. The media access control (MAC) address of the frame is an all-ones broadcast address (ffff.ffff.ffff). 4. The destination IP address is broadcast defined by all ones (255.255.255.255) or a subnet broadcast (for example, 192.33.4.251 for the 192.33.4.248/30 subnet). 61200510L1-35E ATM Sub-Interface Config Command Set on page 425 for more information. Copyright © 2005 ADTRAN...
  • Page 754 Command Reference Guide ATM Sub-Interface Config Command Set Usage Examples The following example forwards all DNS broadcast traffic to the DNS server with IP address 192.33.5.99: (config)#ip forward-protocol udp domain (config)#interface atm 1.1 (config-atm 1.1)#ip helper-address 192.33.5.99 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 755 Packets received on the correct RPF interface are forwarded to this interface regardless of whether any receivers have joined the specified group using IGMP. Sets the interface’s IGMP version. The default setting is version 2. Copyright © 2005 ADTRAN...
  • Page 756 Release 8.1 ATM sub-interface was added. Usage Examples The following example sets the query message interval on the interface to 200 milliseconds: (config)#interface atm 1.1 (config-atm 1.1)#ip igmp last-member-query-interval 200 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 757 Usage Examples The following example enables multicast forwarding and IGMP on the interface: (config)#interface atm 1.1 (config-atm 1.1)#ip mcast-stub downstream 61200510L1-35E ATM Sub-Interface Config Command Set on page 434 ip mcast-stub upstream Copyright © 2005 ADTRAN on page 759...
  • Page 758 757 ip mcast-stub upstream on page 759 for more information. Usage Examples The following example sets the helper address as the IGMP proxy: (config)#interface atm 1.1 (config-atm 1.1)#ip mcast-stub helper-enable 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 759 <ip address> more information. Usage Examples The following example enables multicast forwarding on the interface: (config)#interface atm 1.1 (config-atm 1.1)#ip mcast-stub upstream 61200510L1-35E ATM Sub-Interface Config Command Set on page 434 ip mcast-stub downstream Copyright © 2005 ADTRAN on page 757...
  • Page 760 This command applies to the NetVanta 300, 1000R, 3000, and 4000 Series units. Command History Release 3.1 Command was introduced. Release 8.1 ATM sub-interface was added. 61200510L1-35E ATM Sub-Interface Config Command Set 5 seconds 1 second 10 seconds: Ethernet, point-to-point, Frame Relay, and PPP 40 seconds Copyright © 2005 ADTRAN...
  • Page 761 Command Reference Guide ATM Sub-Interface Config Command Set Usage Example The following example sets the maximum number of seconds allowed between hello packets to 25,000: (config)#interface atm 1.1 (config-atm 1.1)#ip ospf dead-interval 25000 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 762 Release 8.1 ATM sub-interface was added. Usage Examples The following example specifies that no authentication will be used on the ATM sub-interface 1.1: (config)#interface atm 1.1 (config-atm 1.1)#ip ospf authentication null 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 763 ATM sub-interface was added. Functional Notes A point-to-point network will not elect designated routers. Usage Examples The following example designates a broadcast network type: (config)#interface atm 1.1 (config-atm 1.1)#ip ospf network broadcast 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 764: Ip Proxy-Arp

    Enabling proxy ARP on an interface may introduce unnecessary ARP traffic on the network. Usage Examples The following enables proxy ARP on the ATM sub-interface 1.1: (config)#interface atm 1.1 (config-atm 1.1)#ip proxy-arp 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 765 The AOS only accepts one version (either 1 or 2) on a given interface. Usage Examples The following example configures the ATM sub-interface 1.1 to accept only RIP version 2 packets: (config)#interface atm 1.1 (config-atm 1.1)#ip rip receive version 2 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 766 The AOS only transmits one version (either 1 or 2) on a given interface. Usage Examples The following example configures the ATM sub-interface 1.1 to transmit only RIP version 2 packets: (config)#interface atm 1.1 (config-atm 1.1)#ip rip send version 2 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 767 Fast switching allows an IP interface to provide optimum performance when processing IP traffic. Usage Examples The following example enables fast switching on the ATM sub-interface 1.1: (config)#interface atm 1.1 (config-atm 1.1)#ip route-cache 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 768 Usage Examples The following example configures the ATM sub-interface 1.1 to use the IP address assigned to the Ethernet interface (eth 0/1): (config)#interface atm 1.1 (config-atm 1.1)#ip unnumbered eth 0/1 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 769 (config-fr 1)#max-reserved-bandwidth 80 Usage Examples The following example configures the ATM sub-interface 1.1 to reserve a maximum of 80 percent of the total bandwidth for QoS: (config)#interface atm 1.1 (config-atm 1.1)#max-reserved-bandwidth 80 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 770 ATM Sub-Interface Config Command Set 64 to 1520 64 to 1520 64 to 1500 64 to 256 64 to 1520 64 to 1500 64 to 18,190 64 to 1520 64 to 1500 1500 1500 1500 1500 1500 1500 1500 1500 Copyright © 2005 ADTRAN...

  • Page 771: Oam Retry

    Usage Examples The following example configures the OAM parameters with an up-count of 2, down-count of 2, and retry frequency of 10: (config)#interface atm 1.1 (config-atm 1.1)#oam retry 2 2 10 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 772 Command History Release 8.1 Command was introduced. Usage Examples The following example enables OAM loopback cell generation with a frequency of 5 seconds: (config)#interface atm 1.1 (config-atm 1.1)#oam-pvc managed 5 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 773 This command applies to the NetVanta 300, 1000R, 3000, and 4000 Series units. Command History Release 8.1 Command was introduced. Usage Examples The following example sets the VPI to 8 and the VCI to 35: (config)#interface atm 1.1 (config-atm 1.1)#pvc 8/35 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 774 This actually helps QoS keep higher priority class-based traffic working better than best-effort traffic when the bandwidth drops. 61200510L1-35E ATM Sub-Interface Config Command Set on page 488 for more information). Copyright © 2005 ADTRAN qos map...
  • Page 775 Command Reference Guide ATM Sub-Interface Config Command Set Usage Examples The following example applies the QoS map VOICEMAP to the ATM sub-interface 1.1: (config)#interface atm 1.1 (config-atm 1.1)#qos-policy out VOICEMAP 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 776 It normally should not be used in a live network. Usage Examples The following example enables the BPDU filter on the interface: (config)#interface atm 1.1 (config-atm 1.1)#spanning-tree bpdufilter enable 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 777 Command History Release 5.1 Command was introduced. Release 8.1 ATM sub-interface was added. Usage Examples The following example enables the bpduguard on the interface: (config)#interface atm 1.1 (config-atm 1.1)#spanning-tree bpduguard enable 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 778: Spanning-Tree Edgeport

    An individual interface can be configured to not be considered an edgeport. For example: (config)#interface atm 1.1 (config-atm 1.1)#spanning-tree edgeport disable (config)#interface atm 1.1 (config-atm 1.1)#no spanning-tree edgeport 61200510L1-35E ATM Sub-Interface Config Command Set on page 518). Use the no form of this command Copyright © 2005 ADTRAN...
  • Page 779 Setting the link type to auto allows the spanning tree to automatically configure the link type based on the duplex of the link. Setting the link type to point-to-point allows a half-duplex link to act as if it were a point-to-point link. 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 780: Spanning-Tree Path-Cost

    Spanning-tree protocol provides a way to prevent loopback or parallel paths in bridged networks. Using the priority values and path costs assigned to each bridging interface, the spanning-tree protocol determines the root path and identifies whether to block or allow other paths. 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 781: Spanning-Tree Port-Priority

    Usage Examples The following example sets the maximum priority on the ATM sub-interface labeled 1.1 in bridge group 17: (config)#interface atm 1.1 (config-atm 1.1)#spanning-tree priority 0 61200510L1-35E ATM Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 782: Demand Interface Configuration Command Set

    [dyndns | dyndns-custom | dyndns-static] <hostname> <username> <password> on page 799 61200510L1-35E Demand Interface Configuration Command Set ONFIGURATION OMMAND on page 784 on page 788 on page 789 on page 790 on page 791 on page 794 on page 798 Copyright © 2005 ADTRAN...
  • Page 783 841 username <username> password <password> 61200510L1-35E Demand Interface Configuration Command Set on page 803 on page 826 on page 830 on page 839 on page 840 on page 842 Copyright © 2005 ADTRAN on page 828...

  • Page 784: Access-Policy

    PPP interface: Enable the AOS security features: (config)#ip firewall Create the access list (this is the packet selector): (config)#ip access-list extended InWeb (config-ext-nacl)#permit tcp any host 63.12.5.253 eq 80 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 785 All packets passed by the access list(s) entered and destined for the interface using the access policy listed will be permitted to enter the router system. This allows for configurations to permit packets to a single interface and not the entire system. 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 786 Apply the created access policy to an interface. To assign an access policy to an interface, enter interface configuration mode for the desired interface and enter access policy <policy name>. The following example assigns access policy MatchAll to the virtual PPP interface labeled 1: (config)#interface demand 1 (config-demand 1)#access-policy MatchAll 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 787 This is a routing parameter only and does not affect the physical interface. Usage Examples The following example sets the bandwidth of the demand interface to 10 Mbps: (config)#interface demand 1 (config-demand 1)#bandwidth 10000 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 788: Called-Number

    Command History Release 11.1 Command was introduced. Usage Examples The following example links calls with a DNIS number of 2565558409 to the demand interface 1: (config)#interface demand 1 (config-demand 1)#called-number 2565558409 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 789 Command History Release 11.1 Command was introduced. Usage Examples The following example links calls with a CLID number of 2565559911 to the demand interface 1: (config)#interface demand 1 (config-demand 1)#caller-number 2565559911 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 790 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example configures demand interface 1 to only answer calls: (config)#interface demand 1 (config-demand 1)#connect-mode answer 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 791 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example configures the connection sequence to begin with the last successful entry: (config)#interface demand 1 (config-demand 1)#connect-order last-successful 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 792 By default any dial resource may be used. Applicable Platforms This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 11.1 Command was introduced. 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 793 Command Reference Guide Demand Interface Configuration Command Set Usage Examples The following example instructs demand interface 1 to place the call using ISDN 64k: (config)#interface demand 1 (config-demand 1)#connect-sequence 65 dial-string 2565559911 forced-isdn-64k 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 794 The following example instructs demand interface 1 to attempt its connection sequence 500 times: (config)#interface demand 1 (config-demand 1)#connect-sequence attempts 500 61200510L1-35E Demand Interface Configuration Command Set on page 795 for more information. Use the no form of Copyright © 2005 ADTRAN...
  • Page 795 The following example configures demand interface 1 to wait 60 seconds between retry attempts with a maximum number of 500 retries: (config)#interface demand 1 (config-demand 1)#connect-sequence interface-recovery retry-interval 60 max-retries 500 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 796: Crypto Map

    This allows you to apply multiple crypto maps if you have created maps which share the same name but have different map index numbers. For VPN configuration example scripts, refer to the technical support note Configuring VPN located on the ADTRAN OS Documentation CD provided with your unit. Syntax Description <mapname>...
  • Page 797 The destination information is the local side. Usage Examples The following example applies all crypto maps with the name MyMap to the demand interface: (config)#interface demand 1 (config-demand 1)#crypto map MyMap 61200510L1-35E Demand Interface Configuration Command Set Static Filter (out) IPSec Encrypt Copyright © 2005 ADTRAN...
  • Page 798 Command was introduced. Usage Examples The following example configures demand interface 1 to hold 50 packets in the queue for up to 120 seconds: (config)#interface demand 1 (config-demand 1)#demand-hold-queue 50 timeout 120 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 799 Custom DNS-aware clients as Dynamic DNS. 61200510L1-35E Demand Interface Configuration Command Set service allows you to alias a dynamic IP address to a static hostname in service provides a full DNS solution, giving you complete Copyright © 2005 ADTRAN...
  • Page 800 IP address support. Usage Examples The following example sets the dynamic-dns to dyndns-custom with hostname host, username user, and password pass: (config)#interface demand 1 (config-demand 1)#dynamic-dns dyndns-custom host user pass 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 801 Command expanded to include the demand interface. Usage Examples The following example enables WFQ on the interface with a threshold set at 100 packets: (config)#interface demand 1 (config-demand 1)#fair-queue 100 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 802 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example sets fast idle to 1,073,752 seconds: (config)#interface demand 1 (config-demand 1)#fast-idle 1073752 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 803 Command was introduced. Release 11.1 Command expanded to include the demand interface. Usage Examples The following example sets the overall output queue size to 700: (config)#interface demand 1 (config-demand 1)#hold-queue 700 out 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 804: Idle-Timeout

    Command History Release 11.1 Command was introduced. Usage Examples The following example configures demand interface 1 to time out after 360 seconds: (config)#interface demand 1 (config-demand 1)#idle-timeout 360 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN on page 828...
  • Page 805 The following example sets up the router to only allow Telnet traffic into the demand interface: (config)#ip access-list extended TelnetOnly (config-ext-nacl)#permit tcp any any eq telnet (config-ext-nacl)#interface demand 1 (config-demand 1)#ip access-group TelnetOnly in 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 806 The following example enables the demand interface to negotiate an IP address from the far end connection without inserting a default route: (config)#interface demand 1 (config-demand 1)#ip address negotiated no-default 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 807 IP addresses on the secondary subnet. Usage Examples The following example configures a secondary IP address of 192.22.72.101/30: (config)#interface demand 1 (config-demand 1)#ip address 192.22.72.101 255.255.255.252 secondary 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 808: Ip Helper-Address

    3. The media access control (MAC) address of the frame is an all-ones broadcast address (ffff.ffff.ffff). 4. The destination IP address is broadcast defined by all ones (255.255.255.255) or a subnet broadcast (for example, 192.33.4.251 for the 192.33.4.248/30 subnet). 61200510L1-35E Demand Interface Configuration Command Set on page 425 for more information. Copyright © 2005 ADTRAN...
  • Page 809 Command Reference Guide Demand Interface Configuration Command Set Usage Examples The following example forwards all DNS broadcast traffic to the DNS server with IP address 192.33.5.99: (config)#ip forward-protocol udp domain (config)#interface demand 1 (config-demand 1)#ip helper-address 192.33.5.99 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 810 Packets received on the correct RPF interface are forwarded to this interface regardless of whether any receivers have joined the specified group using IGMP. Sets the interface’s IGMP version. The default setting is version 2. Copyright © 2005 ADTRAN...
  • Page 811 Command expanded to include the demand interface. Usage Examples The following example sets the query message interval on the interface to 200 milliseconds: (config)#interface demand 1 (config-demand 1)#ip igmp last-member-query-interval 200 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 812 Usage Examples The following example enables multicast forwarding and IGMP on the interface: (config)#interface demand 1 (config-demand 1)#ip mcast-stub downstream 61200510L1-35E Demand Interface Configuration Command Set on page 434 ip mcast-stub upstream Copyright © 2005 ADTRAN on page 814...
  • Page 813 The following example sets the helper address as the IGMP proxy: (config)#interface demand 1 (config-demand 1)#ip mcast-stub helper-enable 61200510L1-35E Demand Interface Configuration Command Set on page 434 ip mcast-stub downstream for more information. Copyright © 2005 ADTRAN on page 812 , and...
  • Page 814 <ip address> more information. Usage Examples The following example enables multicast forwarding on the interface: (config)#interface demand 1 (config-demand 1)#ip mcast-stub upstream 61200510L1-35E Demand Interface Configuration Command Set on page 434 ip mcast-stub downstream Copyright © 2005 ADTRAN on page 812...
  • Page 815 Command expanded to include the demand interface. Usage Example The following example sets the maximum number of seconds allowed between hello packets to 25,000: (config)#interface demand 1 (config-demand 1)#ip ospf dead-interval 25000 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 816 Command expanded to include the demand interface. Usage Examples The following example specifies that no authentication will be used on the demand interface: (config)#interface demand 1 (config-demand 1)#ip ospf authentication null 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 817 Command expanded to include the demand interface. Functional Notes A point-to-point network will not elect designated routers. Usage Examples The following example designates a broadcast network type: (config)#interface demand 1 (config-demand 1)#ip ospf network broadcast 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 818: Ip Policy Route-Map

    Command History Release 11.1 Command was introduced. Usage Examples The following example associates the route map named MyMap with demand interface 1: (config)#interface demand 1 (config-demand 1)#ip policy route-map MyMap 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 819: Ip Proxy-Arp

    Enabling proxy ARP on an interface may introduce unnecessary ARP traffic on the network. Usage Examples The following example enables proxy ARP on the virtual demand interface: (config)#interface demand 1 (config-demand 1)#ip proxy-arp 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 820 The AOS only accepts one version (either 1 or 2) on a given interface. Usage Examples The following example configures the virtual demand interface to accept only RIP version 2 packets: (config)#interface demand 1 (config-demand 1)#ip rip receive version 2 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 821 The AOS only transmits one version (either 1 or 2) on a given interface. Usage Examples The following example configures the virtual demand interface to transmit only RIP version 2 packets: (config)#interface demand 1 (config-demand 1)#ip rip send version 2 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 822 Fast-cache switching allows an IP interface to provide optimum performance when processing IP traffic. Usage Examples The following example enables fast-cache switching on the virtual demand interface: (config)#interface demand 1 (config-demand 1)#ip route-cache 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 823 The following example configures the demand interface (labeled demand 1) to use the IP address assigned to the Ethernet interface (eth 0/1): (config)#interface demand 1 (config-demand 1)#ip unnumbered eth 0/1 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 824: Keep Alive

    Usage Examples The following example specifies a keepalive time of 5 seconds on the virtual demand interface: (config)#interface demand 1 (config-demand 1)#keepalive 5 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 825: Lldp Receive

    Command was introduced. Release 11.1 Command expanded to include the demand interface. Usage Examples The following example configures the demand interface to receive LLDP packets: (config)#interface demand 1 (config-demand 1)#lldp receive 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 826 For example, use the lldp send and-receive command to enable transmit and receive of all LLDP information. Then use the no lldp send port-description command to prevent LLDP from transmitting port description information. 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 827 The following example configures the demand interface to transmit LLDP packets containing all enabled information types: (config)#interface demand 1 (config-demand 1)#lldp send The following example configures the demand interface to transmit and receive LLDP packets containing all information types: (config)#interface demand 1 (config-demand 1)#lldp send and-receive 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 828 Command was introduced. Usage Examples The following example instructs demand interface 1 to use the access list MyACL when checking for interesting traffic: (config)#interface demand 1 (config-demand 1)#match-interesting list MyACL in 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 829 Demand Interface Configuration Command Set 64 to 1520 64 to 1520 64 to 1500 64 to 256 64 to 1520 64 to 1500 64 to 18,190 64 to 1520 64 to 1500 1500 1500 1500 1500 1500 1500 1500 1500 Copyright © 2005 ADTRAN...
  • Page 830 This command is useful if the peer does not send the IP address option during PPP negotiations. Usage Examples The following example sets the default peer IP address to 192.22.71.50: (config)#interface demand 1 (config-demand 1)#peer default ip address 192.22.71.50 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 831 (say the local router). The local router then looks up the username and password in the username database within the PPP interface, and if they match sends an authentication acknowledge back to the peer. 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 832 “response” back to the local router. This data is encrypted. The local router verifies that the username and password are in its own username database within the PPP interface, and if so sends a "success" back to the peer. 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 833 Notice the peer is expecting username “nearend” even though the local router's hostname is “Local.” Therefore the local router can use the ppp chap hostname command to send the correct name on the challenge. 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 834 "same" in the response, it uses the one in the ppp chap password command. The local router then verifies that user "Peer" with password "different" is valid and sends a "success." 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 835 Command was introduced. Release 11.1 Command expanded to include the demand interface. Usage Examples The following example specifies a PPP CHAP hostname of my_host: (config)#interface demand 1 (config-demand 1)#ppp chap hostname my_host 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 836: Ppp Chap Password

    Command expanded to include the demand interface. Usage Examples The following example specifies a PPP CHAP password of my_password: (config)#interface demand 1 (config-demand 1)#ppp chap password my_password 61200510L1-35E Demand Interface Configuration Command Set on page 831. Copyright © 2005 ADTRAN...
  • Page 837 The multilink bundle will remain active with a minimum of one physical link. Physical links may be dynamically added or removed from the multilink bundle with minor interruption to traffic flow. Usage Examples The following example enables MPPP: (config)#interface demand 1 (config-demand 1)#ppp multilink 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 838 Usage Examples The following example specifies a PPP PAP sent-username of local and a password of my_password: (config)#interface demand 1 (config-demand 1)#ppp pap sent-username local password my_password 61200510L1-35E Demand Interface Configuration Command Set on page 831. Copyright © 2005 ADTRAN...
  • Page 839 Usage Examples The following example applies the QoS map VOICEMAP to the demand 1 interface: (config)#interface demand 1 (config-demand 1)#qos-policy out VOICEMAP 61200510L1-35E Demand Interface Configuration Command Set on page 488 for more information). Copyright © 2005 ADTRAN qos map...
  • Page 840 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example associates the resource pool named Pool1 with demand interface 1: (config)#interface demand 1 (config-demand 1)#resource pool Pool1 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 841: Snmp Trap Link-Status

    The snmp trap link-status command is used to control the RFC2863 ifLinkUpDownTrapEnable OID (OID number 1.3.6.1.2.1.31.1.1.1.14.0). Usage Examples The following example disables the link-status trap on the virtual demand interface: (config)#interface demand 1 (config-demand 1)#no snmp trap link-status 61200510L1-35E Demand Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 842: Username Password

    PAP uses this entry to check received information from the peer. CHAP uses this entry to check the received peer hostname and a common password. Usage Examples The following example creates a username of ADTRAN with password ADTRAN for the demand link labeled 5: (config)#interface demand 5...

  • Page 843: Frame Relay Interface Config Command Set

    <percent> qos-policy out <mapname> snmp trap on page 863 snmp trap link-status on page 864 61200510L1-35E Frame Relay Interface Config Command Set ONFIG OMMAND on page 845 on page 859 on page 860 on page 861 Copyright © 2005 ADTRAN...
  • Page 844 This is a routing parameter only and does not affect the physical interface. Usage Examples The following example sets bandwidth of the Frame Relay interface to 10 Mbps: (config)#interface frame-relay 1 (config-fr 1)#bandwidth 10000 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 845: Encapsulation Frame-Relay Ietf

    This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example configures the endpoint for IETF encapsulation: (config)#interface frame-relay 1 (config-fr 1)#encapsulation frame-relay ietf 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 846 Command History Release 5.1 Command was introduced. Usage Examples The following example enables WFQ on the interface with a threshold set at 100 packets: (config)#interface frame-relay 1 (config-fr 1)#fair-queue 100 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 847 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example configures the Frame Relay endpoint for DCE signaling: (config)#interface frame-relay 1 (config-fr 1)#frame-relay intf-type dce 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 848 1 and 255, but the default is used for most applications. Usage Examples The following example sets the N391 counter for three polls: (config)#interface frame-relay 1 (config-fr 1)#frame-relay lmi-n391dce 3 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 849: Frame-Relay Lmi-N391Dte

    1 and 255, but the default is used for most applications. Usage Examples The following example sets the N391 counter for three polls: (config)#interface frame-relay 1 (config-fr 1)#frame-relay lmi-n391dte 3 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 850: Frame-Relay Lmi-N392Dce

    If N392 = and N393 = 4, then if three errors occur within any four events, the interface is determined inactive. Usage Examples The following example sets the N392 threshold for 5 seconds: (config)#interface frame-relay 1 (config-fr 1)#frame-relay lmi-n392dce 5 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 851: Frame-Relay Lmi-N392Dte

    If N392 = 3 and N393 = 4, then if three errors occur within any four events, the interface is determined inactive. Usage Examples The following example sets the N392 threshold for five errors: (config)#interface frame-relay 1 (config-fr 1)#frame-relay lmi-n392dte 5 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 852: Frame-Relay Lmi-N393Dce

    This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example sets the N393 threshold for five events: (config)#interface frame-relay 1 (config-fr 1)#frame-relay lmi-n393dce 5 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 853: Frame-Relay Lmi-N393Dte

    This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example sets the N393 threshold for five events: (config)#interface frame-relay 1 (config-fr 1)#frame-relay lmi-n393dte 5 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 854: Frame-Relay Lmi-T391Dte

    The T391 timer sets the time (in seconds) between polls to the Frame Relay network. Usage Examples The following example sets the T391 timer for 15 seconds: (config)#interface frame-relay 1 (config-fr 1)#frame-relay lmi-t391dte 15 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 855: Frame-Relay Lmi-T392Dce

    T391 setting of the attached Frame Relay device. Usage Examples The following example sets the T392 timer for 15 seconds: (config)#interface frame-relay 1 (config-fr 1)#frame-relay lmi-t392dce 15 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 856 Command History Release 1.1 Command was introduced. Release 2.1 Added signaling type none to provide support for dial-backup to ADTRAN IQ and Express series products. Usage Examples The following example sets the signaling method for the endpoint to cisco: (config)#interface frame-relay 1...
  • Page 857 A single active link is sufficient for the bundle to be up. All defined bundle links must be active for the bundle to be up. A minimum threshold of links must be active for the bundle to be up. Copyright © 2005 ADTRAN...
  • Page 858 The following example specifies Class B operation: (config)#interface frame-relay 1 (config-fr 1)#frame-relay multilink bandwidth-class b The following example specifies Class C operation with a threshold of 5: (config)#interface frame-relay 1 (config-fr 1)#frame-relay multilink bandwidth-class c 5 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 859 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example sets the overall output queue size to 700: (config)#interface frame-relay 1 (config-fr 1)#hold-queue 700 out 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 860 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example sets the reserved bandwidth maximum at 80 percent: (config)#interface frame-relay 1 (config-fr 1)#max-reserved-bandwidth 80 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 861 This actually helps QoS keep higher priority class-based traffic working better than best-effort traffic when the bandwidth drops. 61200510L1-35E Frame Relay Interface Config Command Set on page 488 for more information). Copyright © 2005 ADTRAN qos map...
  • Page 862 Command Reference Guide Frame Relay Interface Config Command Set Usage Examples The following example applies the QoS map VOICEMAP to the Frame Relay interface: (config)#interface frame-relay 1 (config-fr 1)#qos-policy out VOICEMAP 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 863 Command was expanded to include Ethernet sub-interfaces and Gigabit Ethernet interfaces. Usage Examples The following example enables SNMP on the virtual Frame Relay interface: (config)#interface frame-relay 1 (config-fr 1)#snmp trap 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 864: Snmp Trap Link-Status

    The snmp trap link-status command is used to control the RFC2863 ifLinkUpDownTrapEnable OID (OID number 1.3.6.1.2.1.31.1.1.1.14.0). Usage Examples The following example disables the link-status trap on the Frame Relay interface: (config)#interface frame-relay 1 (config-fr 1)#no snmp trap link-status 61200510L1-35E Frame Relay Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 865: Frame Relay Sub-Interface Config Command Set

    [management-address l port-description l system-capabilities l system-description l system-name l and-receive] mtu <size> on page 919 spanning-tree commands begin on page 920 61200510L1-35E Frame Relay Sub-Interface Config Command Set NTERFACE ONFIG on page 866 on page 917 Copyright © 2005 ADTRAN OMMAND...

  • Page 866: Access-Policy

    Frame Relay sub-interface labeled 1.16: Enable the AOS security features: (config)#ip firewall Create the access list (this is the packet selector): (config)#ip access-list extended InWeb (config-ext-nacl)#permit tcp any host 63.12.5.253 eq 80 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 867 All packets passed by the access list(s) entered and destined for the interface using the access policy listed will be permitted to enter the router system. This allows for configurations to permit packets to a single interface and not the entire system. 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 868 Apply the created access policy to an interface. To assign an access policy to an interface, enter the interface configuration mode for the desired interface and enter access policy <policy name>. The following example assigns access policy MatchAll to the Frame Relay sub-interface labeled 1: (config)#interface frame-relay 1.16 (config-fr 1.16)#access-policy MatchAll 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 869 This is a routing parameter only and does not affect the physical interface. Usage Examples The following example sets bandwidth of the Frame Relay interface to 10 Mbps: (config)#interface frame-relay 1.16 (config-fr 1.16)#bandwidth 10000 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 870 (Ethernet to T1 bridge, Ethernet to Frame Relay sub-interface). Usage Examples The following example assigns the Frame Relay sub-interface labeled 1.16 to bridge group 1: (config)#interface frame-relay 1.16 (config-fr 1.16)#bridge-group 1 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 871: Crypto Map

    This allows you to apply multiple crypto maps if you have created maps which share the same name but have different map index numbers. For VPN configuration example scripts, refer to the technical support note Configuring VPN located on the ADTRAN OS Documentation CD provided with your unit. Syntax Description <mapname>...
  • Page 872 Usage Examples The following example applies all crypto maps with the name MyMap to the Frame Relay interface: (config)#interface frame-relay 1.16 (config-fr 1.16)#crypto map MyMap 61200510L1-35E Frame Relay Sub-Interface Config Command Set Static Filter (out) IPSec Encrypt Copyright © 2005 ADTRAN...
  • Page 873 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example enables automatic dial-backup on the endpoint: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup auto-backup 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 874 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example configures the AOS to automatically restore the primary connection when the failure condition clears: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup auto-restore 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 875 The following example configures the AOS to wait 60 seconds (on an endpoint with an active alarm condition) before attempting dial-backup operation: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup backup-delay 60 61200510L1-35E Frame Relay Sub-Interface Config Command Set on page Copyright © 2005 ADTRAN 876.
  • Page 876 However, the numbers dialed are configured in the primary interface. Full sample configurations follow: Sample configuration for remote router (dialing out) hostname "Remote3200" enable password adtran interface eth 0/1 ip address 192.168.1.254 255.255.255.0 no shutdown interface modem 1/3 no shutdown 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 877 1 timeslots 1-24 no shutdown interface fr 1 point-to-point frame-relay lmi-type ansi no shutdown cross-connect 1 t1 1/1 1 fr 1 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 878 3. If a match is found, the call connects and the AOS pulls down the primary connection if it is not already in a down state. 4. If no match is found from Caller ID, the call is terminated. 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN dial-backup number on page...
  • Page 879 Command was introduced. Usage Examples The following example configures the AOS to wait 120 seconds before retrying a failed dial-backup call: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup connect-timeout 120 61200510L1-35E Frame Relay Sub-Interface Config Command Set on page Copyright © 2005 ADTRAN 876.
  • Page 880 Release 1.1 Command was introduced. Usage Examples The following example configures the AOS to force this interface into dial-backup: (config)#interface frame-relay 1.16 (config-fr 1.161)#dial-backup force backup 61200510L1-35E Frame Relay Sub-Interface Config Command Set on page 876. Copyright © 2005 ADTRAN...
  • Page 881 The following example configures the AOS to retry a dial-backup call four times before considering backup operation not available: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup maximum-retry 4 61200510L1-35E Frame Relay Sub-Interface Config Command Set on page 876. Copyright © 2005 ADTRAN...
  • Page 882 The following example configures the AOS to dial 704-555-1212 (digital 64 kbps connection) to initiate dial-backup operation on this endpoint using sub-interface Frame Relay 3.1: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup number 7045551212 digital-64k 1 1 fr 3.1 61200510L1-35E Frame Relay Sub-Interface Config Command Set on page 876. Copyright © 2005 ADTRAN...
  • Page 883 Command History Release 1.1 Command was introduced. Usage Examples The following example assigns the highest priority to this endpoint: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup priority 100 61200510L1-35E Frame Relay Sub-Interface Config Command Set on page 876. Copyright © 2005 ADTRAN...
  • Page 884 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example configures the AOS to randomize the dial-backup timers associated with this endpoint: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup randomize-timers 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 885 Release 1.1 Command was introduced. Usage Examples The following example configures a redial delay of 25 seconds on this endpoint: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup redial-delay 25 61200510L1-35E Frame Relay Sub-Interface Config Command Set on page Copyright © 2005 ADTRAN 876.
  • Page 886 The following example configures the AOS to wait 30 seconds before disconnecting dial-backup operation and restoring the primary connection for this endpoint: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup restore-delay 30 61200510L1-35E Frame Relay Sub-Interface Config Command Set on page 876. Copyright © 2005 ADTRAN...
  • Page 887 The following example enables dial-backup Monday through Friday 8:00 am to 7:00 pm: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup schedule enable-time 08:00 (config-fr 1.16)#dial-backup schedule disable-time 19:00 (config-fr 1.16)#no dial-backup schedule day Saturday (config-fr 1.16)#no dial-backup schedule day Sunday 61200510L1-35E Frame Relay Sub-Interface Config Command Set 876. Copyright © 2005 ADTRAN...
  • Page 888 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 Series units. Command History Release 1.1 Command was introduced. Usage Examples The following example deactivates the configured dial-backup interface: (config)#interface frame-relay 1.16 (config-fr 1.16)#dial-backup shutdown 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 889 IP address. Unlike a Dynamic DNS host, a Static DNS host does not expire after 35 days without updates, but updates take longer to propagate though the DNS system. This service is provided for up to five hostnames. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 890 IP address support. Usage Examples The following example sets the Dynamic DNS to dyndns-custom with hostname host, username user, and password pass: (config)#interface frame-relay 1.16 (config-fr 1.16)#dynamic-dns dyndns-custom host user pass 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 891 , and it is recommended that the sum always be greater than 8000. Usage Examples The following example configures the Frame Relay sublink with a committed burst value of 128,000 bits: (config)#interface frame-relay 1.1 (config-fr 1.16)#frame-relay bc 128000 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 892 , and it is recommended that the sum always be greater than 8000. Usage Examples The following example configures the Frame Relay sublink with an excessive burst value of 64,000 bits: (config)#interface frame-relay 1.1 (config-fr 1.16)#frame-relay be 64000 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 893 The following example disables FRF.12 fragmentation on a sublink: (config)#interface frame-relay 1.16 (config-fr 1.16)#no frame-relay fragment 61200510L1-35E Frame Relay Sub-Interface Config Command Set frame-relay bc <committed burst value> on page 892 for more information. Copyright © 2005 ADTRAN on page 891...

  • Page 894: Frame-Relay Interface-Dlci

    Command History Release 1.1 Command was introduced. Usage Examples The following example configures a DLCI of 72 for this Frame Relay endpoint: (config)#interface frame-relay 1.16 (config-fr 1.16)#frame-relay interface-dlci 72 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 895 The following example sets up the router to only allow Telnet traffic into the Frame Relay sub-interface: (config)#interface frame-relay 1.16 (config)#ip access-list extended TelnetOnly (config-ext-nacl)#permit tcp any any eq telnet (config-ext-nacl)#int frame-relay 1.16 (config-fr 1.16)#ip access-group TelnetOnly in 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 896: Ip Address Dhcp

    (For units with a single Ethernet interface, the MAC ADDRESS assigned to Ethernet 0/1 is used in this field). 61200510L1-35E Frame Relay Sub-Interface Config Command Set on page 1334 Copyright © 2005 ADTRAN for a detailed on page 1334 for a detailed...
  • Page 897 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 2.1 Command was introduced. 61200510L1-35E Frame Relay Sub-Interface Config Command Set FECN BECN 16 / 0x0401 50 / 0x0C21 60 / 0x0CC1 70 / 0x1061 80 / 0x1401 Copyright © 2005 ADTRAN...
  • Page 898 ISP to determine the proper values for the client-id and hostname fields. Usage Examples The following example enables DHCP operation on the virtual Frame Relay interface (labeled 1.16): (config)#interface frame-relay 1.16 (config-fr 1.16)#ip address dhcp 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 899 IP addresses on the secondary subnet. Usage Examples The following example configures a secondary IP address of 192.22.72.101/30: (config)#interface frame-relay 1.16 (config-fr 1.16)#ip address 192.22.72.101 255.255.255.252 secondary 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 900 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. Usage Examples The following example releases the IP DHCP address for the virtual interface: (config)#interface frame-relay 1.16 (config-fr 1.16)#ip dhcp release 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 901: Ip Helper-Address

    4. The destination IP address is broadcast defined by all ones (255.255.255.255) or a subnet broadcast (for example, 192.33.4.251 for the 192.33.4.248/30 subnet). 61200510L1-35E Frame Relay Sub-Interface Config Command Set on page 425 for more information. Copyright © 2005 ADTRAN...
  • Page 902 Frame Relay Sub-Interface Config Command Set Usage Examples The following example forwards all DNS broadcast traffic to the DNS server with IP address 192.33.5.99: (config)#interface frame-relay 1.16 (config)#ip forward-protocol udp domain (config)#interface frame-relay 1.16 (config-fr 1.16)#ip helper-address 192.33.5.99 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 903 Packets received on the correct RPF interface are forwarded to this interface regardless of whether any receivers have joined the specified group using IGMP. Sets the interface’s IGMP version. The default setting is version 2. Copyright © 2005 ADTRAN...
  • Page 904 Command Reference Guide Frame Relay Sub-Interface Config Command Set Usage Examples The following example sets the query message interval on the interface to 200 milliseconds: (config)#interface frame-relay 1.16 (config-fr 1.16)#ip igmp last-member-query-interval 200 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 905 Refer ip mcast-stub helper-address <ip address> on page 434 for more information. Usage Examples The following example enables multicast forwarding and IGMP on the interface: (config)#interface frame-relay 1.16 (config-fr 1.16)#ip mcast-stub downstream 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 906 The following example sets the helper address as the IGMP proxy: (config)#interface frame relay 1.16 (config-fr 1.16)#ip mcast-stub helper-enable 61200510L1-35E Frame Relay Sub-Interface Config Command Set on page 434 ip mcast-stub downstream for more information. Copyright © 2005 ADTRAN on page 905 , and...
  • Page 907 Refer ip mcast-stub helper-address <ip address> on page 434 ip mcast-stub downstream on page 905 more information. Usage Examples The following example enables multicast forwarding on the interface: (config)#interface frame-relay 1.16 (config-fr 1.16)#ip mcast-stub upstream 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 908 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 3.1 Command was introduced. 61200510L1-35E Frame Relay Sub-Interface Config Command Set 5 seconds 1 second 10 seconds: Ethernet, point-to-point, Frame Relay, and PPP 40 seconds Copyright © 2005 ADTRAN...
  • Page 909 Release 3.1 Command was introduced. Usage Examples The following example specifies that no authentication will be used on the Frame Relay interface: (config)#interface frame-relay 1.16 (config-fr 1.16)#ip ospf authentication null 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 910 Command was introduced. Functional Notes A point-to-point network will not elect designated routers. Usage Examples The following example designates a broadcast network type: (config)#interface frame-relay 1.16 (config-fr 1.16)#ip ospf network broadcast 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 911: Ip Proxy-Arp

    Enabling proxy ARP on an interface may introduce unnecessary ARP traffic on the network. Usage Examples The following enables proxy ARP on the Frame Relay sub-interface: (config)#interface frame-relay 1.16 (config-fr 1.16)#ip proxy-arp 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 912 The AOS only accepts one version (either 1 or 2) on a given interface. Usage Examples The following example configures a Frame Relay sub-interface to accept only RIP version 2 packets: (config)#interface frame-relay 1.16 (config-fr 1.16)#ip rip receive version 2 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 913 The AOS only transmits one version (either 1 or 2) on a given interface. Usage Examples The following example configures a Frame Relay sub-interface to transmit only RIP version 2 packets: (config)#interface frame-relay 1.16 (config-fr 1.16)#ip rip send version 2 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 914 Fast switching allows an IP interface to provide optimum performance when processing IP traffic. Usage Examples The following example enables fast-cache switching on a Frame Relay sub-interface: (config)#interface frame-relay 1.16 (config-fr 1.16)#ip route-cache 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 915 The following example configures the Frame Relay interface (labeled frame-relay 1.16) to use the IP address assigned to the Ethernet interface (eth 0/1): (config)#interface frame-relay 1.16 (config-fr 1.16)#ip unnumbered eth 0/1 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 916: Lldp Receive

    This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 9.1 Command was introduced. Usage Examples The following example configures the Frame Relay sub-interface to receive LLDP packets: (config)#interface frame-relay 1.16 (config-fr 1.16)#lldp receive 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 917 For example, use the lldp send and-receive command to enable transmit and receive of all LLDP information. Then use the no lldp send port-description command to prevent LLDP from transmitting port description information. 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 918 The following example configures the Frame Relay sub-interface to transmit LLDP packets containing all enabled information types: (config)#interface frame-relay 1.16 (config-fr 1.16)#lldp send The following example configures the Frame Relay sub-interface to transmit and receive LLDP packets containing all information types: (config)#interface frame-relay 1.16 (config-fr 1.16)#lldp send and-receive 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 919 Frame Relay Sub-Interface Config Command Set 64 to 1520 64 to 1520 64 to 1500 64 to 256 64 to 1520 64 to 1500 64 to 18,190 64 to 1520 64 to 1500 1500 1500 1500 1500 1500 1500 1500 1500 Copyright © 2005 ADTRAN...
  • Page 920 It normally should not be used in a live network. Usage Examples The following example enables the BPDU filter on the interface: (config)#interface frame-relay 1.16 (config-fr 1.16)#spanning-tree bpdufilter enable 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 921 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 5.1 Command was introduced. Usage Examples The following example enables the BPDU guard on the interface: (config)#interface frame-relay 1.16 (config-fr 1.16)#spanning-tree bpduguard enable 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 922: Spanning-Tree Edgeport

    The following example configures the interface to be an edgeport: (config)#interface frame-relay 1.16 (config-fr 1.16)#spanning-tree edgeport An individual interface can be configured to not be considered an edgeport. For example: (config)#interface frame-relay 1.16 (config-fr 1.16)#spanning-tree edgeport disable (config)#interface frame-relay 1.16 (config-fr 1.16)#no spanning-tree edgeport 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 923 Setting the link type to point-to-point allows a half-duplex link to act as if it were a point-to-point link. 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 924 Spanning-tree protocol provides a way to prevent loopback or parallel paths in bridged networks. Using the priority values and path costs assigned to each bridging interface, the spanning-tree protocol determines the root path and identifies whether to block or allow other paths. 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...
  • Page 925 Usage Examples The following example sets the maximum priority on the Frame Relay sub-interface labeled 1.16 in bridge group 17: (config)#interface frame-relay 1.16 (config-fr 1.16)#spanning-tree priority 0 61200510L1-35E Frame Relay Sub-Interface Config Command Set Copyright © 2005 ADTRAN...

  • Page 926: Hdlc Command Set

    <seconds> on page 974 lldp receive on page 975 lldp send [management-address l port-description l system-capabilities l system-description l system-name l and-receive] 61200510L1-35E on page 928 on page 955 on page 976 Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 927 Command Reference Guide max-reserved-bandwidth <percent> mtu <size> on page 979 qos-policy out <mapname> snmp trap link-status on page 982 61200510L1-35E on page 978 on page 980 Copyright © 2005 ADTRAN HDLC Command Set...

  • Page 928: Access-Policy

    HDLC interface labeled 1: Enable the AOS security features: (config)#ip firewall Create the access list (this is the packet selector): (config)#ip access-list extended InWeb (config-ext-nacl)#permit tcp any host 63.12.5.253 eq 80 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 929 This allows for configurations to permit packets to a single interface and not the entire system. discard list <access list names> policy <access policy name> 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 930 Apply the created access policy to an interface. To assign an access policy to an interface, enter interface configuration mode for the desired interface and enter access policy <policy name>. The following example assigns access policy MatchAll to the HDLC interface: (config)#interface hdlc 1 (config-hdlc 1)#access-policy MatchAll 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 931 The following example defines a unique character string for the virtual HDLC interface (1): (config)#interface hdlc 1 (config-ppp 1)#alias link “HDLC_link_1” Technology Review Please refer to RFC1990 for a more detailed discussion on HDLC links and bundles. 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 932 This is a routing parameter only and does not affect the physical interface. Usage Examples The following example sets bandwidth of the HDLC interface to 10 Mbps: (config)#interface hdlc 1 (config-hdlc 1)#bandwidth 10000 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 933 (Ethernet to T1 bridge, Ethernet to Frame Relay sub-interface, etc.). Usage Examples The following example assigns the HDLC interface labeled 1 to bridge-group 1: (config)#interface hdlc 1 (config-hdlc 1)#bridge-group 1 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...

  • Page 934: Crypto Map

    This allows you to apply multiple crypto maps if you have created maps which share the same name but have different map index numbers. For VPN configuration example scripts, refer to the technical support note Configuring VPN located on the ADTRAN OS Documentation CD provided with your unit. Syntax Description <mapname>...
  • Page 935 The destination information is the local-side. Usage Examples The following example applies all crypto maps with the name MyMap to the HDLC 1 interface: (config)#interface hdlc 1 (config-hdlc 1)#crypto map MyMap 61200510L1-35E Static Filter (out) IPSec Encrypt Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 936 Command was introduced. Release 5.1 Command was expanded to include the PPP interface. Usage Examples The following example enables automatic dial-backup on the endpoint: (config)#interface ppp 1 (config-ppp 1)#dial-backup auto-backup 61200510L1-35E on page 939. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 937 Command was expanded to include the PPP interface. Usage Examples The following example configures the AOS to automatically restore the primary connection when the failure condition clears: (config)#interface ppp 1 (config-ppp 1)#dial-backup auto-restore 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 938 Command was expanded to include the PPP interface. Usage Examples The following example configures the AOS to wait 60 seconds (on an endpoint with an active alarm condition) before attempting dial-backup operation: (config)#interface ppp 1 (config-ppp 1)#dial-backup backup-delay 60 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 939 Full sample configurations follow: Sample configuration for remote router (dialing out) hostname "Remote3200" enable password adtran interface eth 0/1 ip address 192.168.1.254 255.255.255.0 no shutdown interface modem 1/3 no shutdown 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 940 0/1 ip address 192.168.100.254 255.255.255.0 no shutdown interface modem 1/3 no shutdown interface t1 1/1 coding b8zs framing esf clock source line tdm-group 1 timeslots 1-24 no shutdown interface ppp 1 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 941 3. If a match is found, the call connects and the AOS pulls down the primary connection if it is not already in a down state. 4. If no match is found from Caller ID, the call is terminated. 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set dial-backup number on page...
  • Page 942 Command was expanded to include the PPP interface. Usage Examples The following example configures the AOS to wait 120 seconds before retrying a failed dial-backup call: (config)#interface ppp 1 (config-ppp 1)#dial-backup connect-timeout 120 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 943 Command was expanded to include the PPP interface. Usage Examples The following example configures the AOS to force this interface into dial-backup: (config)#interface ppp 1 (config-ppp 1)#dial-backup force backup 61200510L1-35E on page 939. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 944 Command was expanded to include the PPP interface. Usage Examples The following example configures the AOS to retry a dial-backup call four times before considering backup operation not available: (config)#interface ppp 1 (config-ppp 1)#dial-backup maximum-retry 4 61200510L1-35E on page 939. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 945 The following example configures the AOS to dial 704-555-1212 (digital 64 kbps connection) to initiate dial-backup operation on this endpoint using interface PPP 3: (config)#interface ppp 1 (config-ppp 1)#dial-backup number 7045551212 digital-64k 1 1 ppp 3 61200510L1-35E on page 939. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 946 Command was introduced. Release 5.1 Command was expanded to include the PPP interface. Usage Examples The following example assigns the highest priority to this endpoint: (config)#interface ppp 1 (config-ppp 1)#dial-backup priority 100 61200510L1-35E 939. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 947 Command was expanded to include the PPP interface. Usage Examples The following example configures the AOS to randomize the dial-backup timers associated with this endpoint: (config)#interface ppp 1 (config-ppp 1)#dial-backup randomize-timers 61200510L1-35E 939. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 948 Command was expanded to include the PPP interface. Usage Examples The following example configures a redial delay of 25 seconds on this endpoint: (config)#interface ppp 1 (config-ppp 1)#dial-backup redial-delay 25 61200510L1-35E on page 939. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 949 The following example configures the AOS to wait 30 seconds before disconnecting dial-backup operation and restoring the primary connection for this endpoint: (config)#interface ppp 1 (config-ppp 1)#dial-backup restore-delay 30 61200510L1-35E on page 939. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 950 The following example enables dial-backup Monday through Friday 8:00 am to 7:00 pm: (config)#interface ppp 1 (config-ppp 1)#dial-backup schedule enable-time 08:00 (config-ppp 1)#dial-backup schedule disable-time 19:00 (config-ppp 1)#no dial-backup schedule day Saturday (config-ppp 1)#no dial-backup schedule day Sunday 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 951 Command History Release 1.1 Command was introduced. Release 5.1 Command was expanded to include the PPP interface. Usage Examples The following example deactivates the configured dial-backup interface: (config)#interface ppp 1 (config-ppp 1)#dial-backup shutdown 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 952 IP address. Unlike a Dynamic DNS host, a Static DNS host does not expire after 35 days without updates, but updates take longer to propagate though the DNS system. This service is provided for up to five hostnames. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 953 IP address support. Usage Examples The following example sets the dynamic-dns to dyndns-custom with hostname host, username user, and password pass: (config)#interface hdlc 1 (config-hdlc 1)#dynamic-dns dyndns-custom host user pass 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 954 This command applies to the NetVanta 300, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 9.1 Command was introduced. Usage Examples The following example enables WFQ on the interface with a threshold set at 100 packets: (config)#interface hdlc 1 (config-hdlc 1)#fair-queue 100 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 955 This command applies to the NetVanta 300, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 9.1 Command was introduced. Usage Examples The following example sets the overall output queue size to 700: (config)#interface hdlc 1 (config-hdlc 1)#hold-queue 700 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 956 The following example sets up the unit to only allow Telnet traffic (as defined in the user-configured TelnetOnly IP access list) into the HDLC interface: (config)#ip access-list extended TelnetOnly (config-ext-nacl)#permit tcp any any eq telnet (config-ext-nacl)#int hdlc 1 (config-hdlc 1)#ip access-group TelnetOnly in 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 957 IP addresses on the secondary subnet. Usage Examples The following example configures a secondary IP address of 192.22.72.101/30: (config)#hdlc 1 (config-hdlc 1)#ip address 192.22.72.101 255.255.255.252 secondary 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...

  • Page 958: Ip Helper-Address

    3. The media access control (MAC) address of the frame is an all-ones broadcast address (ffff.ffff.ffff). 4. The destination IP address is broadcast defined by all ones (255.255.255.255) or a subnet broadcast (for example, 192.33.4.251 for the 192.33.4.248/30 subnet). 61200510L1-35E on page 425 for more information. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 959 Command Reference Guide HDLC Command Set Usage Examples The following example forwards all DNS broadcast traffic to the DNS server with IP address 192.33.5.99: (config)#ip forward-protocol udp domain (config)#interface hdlc 1 (config-hdlc 1)#ip helper-address 192.33.5.99 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 960 Packets received on the correct RPF interface are forwarded to this interface regardless of whether any receivers have joined the specified group using IGMP. Sets the interface’s IGMP version. The default setting is version 2. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 961 Command Reference Guide HDLC Command Set Command History Release 9.1 Command was introduced. Usage Examples The following example sets the query message interval on the interface to 200 milliseconds: (config)#interface hdlc 1 (config-hdlc 1)#ip igmp last-member-query-interval 200 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 962 <ip address> on page 434 ip mcast-stub upstream on page 964 for more information. Usage Examples The following example enables multicast forwarding and IGMP on the HDLC interface: (config)#interface hdlc 1 (config-hdlc 1)#ip mcast-stub downstream 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 963 The following example sets the helper address as the IGMP proxy: config)#interface hdlc 1 (config-hdlc 1)#ip mcast-stub helper-enable 61200510L1-35E on page 434 ip mcast-stub downstream for more information. Copyright © 2005 ADTRAN HDLC Command Set on page 962 , and...
  • Page 964 <ip address> on page 434 ip mcast-stub downstream on page 962 more information. Usage Examples The following example enables multicast forwarding on the HDLC interface: (config)#interface hdlc 1 (config-hdlc 1)#ip mcast-stub upstream 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 965 Range: 0 to 32767. Sets the estimated time required to send an LSA on the interface. Range: 0 to 32767. 5 seconds 1 second 10 seconds: Ethernet, point-to-point, Frame Relay, and PPP 40 seconds Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 966 Command Reference Guide HDLC Command Set Usage Example The following example sets the maximum number of seconds allowed between hello packets to 25,000: (config)#interface hdlc 1 (config-hdlc 1)#ip ospf dead-interval 25000 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 967 Command History Release 9.1 Command was introduced. Usage Examples The following example specifies that no authentication will be used on the HDLC interface: (config)#interface hdlc 1 (config-hdlc 1)#ip ospf authentication null 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 968 Release 9.1 Command was introduced. Functional Notes A point-to-point network will not elect designated routers. Usage Examples The following example designates a broadcast network type: (config)#interface hdlc 1 (config-hdlc 1)#ip ospf network broadcast 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...

  • Page 969: Ip Proxy-Arp

    Enabling proxy ARP on an interface may introduce unnecessary ARP traffic on the network. Usage Examples The following enables proxy ARP on the HDLC interface: (config)#interface hdlc 1 (config-hdlc 1)#ip proxy-arp 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 970 The AOS only accepts one version (either 1 or 2) on a given interface. Usage Examples The following example configures the HDLC interface to accept only RIP version 2 packets: (config)#interface hdlc 1 (config-hdlc 1)#ip rip receive version 2 61200510L1-35E on page 1326 for more information. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 971 The AOS only transmits one version (either 1 or 2) on a given interface. Usage Examples The following example configures the HDLC interface to transmit only RIP version 2 packets: (config)#interface hdlc 1 (config-hdlc 1)#ip rip send version 2 61200510L1-35E on page 1326 for more information. Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 972 Fast switching allows an IP interface to provide optimum performance when processing IP traffic. Usage Examples The following example enables fast switching on the HDLC interface: (config)#interface hdlc 1 (config-hdlc 1)#ip route-cache 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 973 Usage Examples The following example configures the HDLC interface to use the IP address assigned to the Ethernet interface (eth 0/1): (config)#interface hdlc 1 (config-hdlc 1)#ip unnumbered eth 0/1 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...

  • Page 974: Keep Alive

    If three keepalive packets are sent to an interface with no response, the interface is considered down. To detect interface failures quickly, specify a smaller keepalive time. Usage Examples The following example specifies a keepalive time of 5 seconds on the HDLC interface: (config)#interface hdlc 1 (config-hdlc 1)#keepalive 5 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...

  • Page 975: Lldp Receive

    This command applies to the NetVanta 300, 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 9.1 Command was introduced. Usage Examples The following example configures the HDLC interface to receive LLDP packets: (config)#interface hdlc 1 (config-hdlc 1)#lldp receive 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 976 For example, use the lldp send and-receive command to enable transmit and receive of all LLDP information. Then use the no lldp send port-description command to prevent LLDP from transmitting port description information. 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 977 The following example configures the HDLC interface to transmit LLDP packets containing all enabled information types: (config)#interface hdlc 1 (config-hdlc 1)#lldp send The following example configures the HDLC to transmit and receive LLDP packets containing all information types: (config)#interface hdlc 1 (config-hdlc 1)#lldp send and-receive 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 978 This command applies to the NetVanta 1000R, 3000, 4000, and 5000 and Total Access 900 Series units. Command History Release 11.1 Command was introduced. Usage Examples The following example sets the reserved-bandwidth maximum at 80 percent: (config)#interface hdlc 1 (config-hdlc 1)#max-reserved-bandwidth 80 61200510L1-35E Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 979 64 to 1520 64 to 1520 64 to 1500 64 to 256 64 to 1520 64 to 1500 64 to 18,190 64 to 1520 64 to 1500 1500 1500 1500 1500 1500 1500 1500 1500 Copyright © 2005 ADTRAN HDLC Command Set...
  • Page 980 QoS map uses the maximum theoretical bandwidth on an interface, not the actual bandwidth at that time. This actually helps QoS keep higher priority class-based traffic working better than best-effort traffic when the bandwidth drops. 61200510L1-35E on page 488 for more information). Copyright © 2005 ADTRAN HDLC Command Set qos map <mapname>...
  • Page 981 Command Reference Guide HDLC Command Set Usage Examples The following example applies the QoS map VOICEMAP to the HDLC interface: (config)#interface hdlc 1 (config-hdlc 1)#qos-policy out VOICEMAP 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 982: Snmp Trap Link-Status

    The snmp trap link-status command is used to control the RFC2863 ifLinkUpDownTrapEnable OID (OID number 1.3.6.1.2.1.31.1.1.1.14.0). Usage Examples The following example disables the link-status trap on the HDLC interface: (config)#interface hdlc 1 (config-hdlc 1)#no snmp trap link-status 61200510L1-35E Copyright © 2005 ADTRAN...

  • Page 983: Loopback Interface Configuration Command Set

    992 ip commands begin on page 993 mtu <size> on page 1010 snmp trap on page 1011 snmp trap link-status on page 1012 61200510L1-35E Loopback Interface Configuration Command Set ONFIGURATION on page 984 Copyright © 2005 ADTRAN OMMAND...

  • Page 984: Access-Policy

    Enable the AOS security features: (config)#ip firewall Create the access list (this is the packet selector): (config)#ip access-list extended InWeb (config-ext-nacl)#permit tcp any host 63.12.5.253 eq 80 61200510L1-35E Loopback Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 985 All packets passed by the access list(s) entered and destined for the interface using the access policy listed will be permitted to enter the router system. This allows for configurations to permit packets to a single interface and not the entire system. 61200510L1-35E Loopback Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 986 Apply the created access policy to an interface. To assign an access policy to an interface, enter the interface configuration mode for the desired interface and enter access policy <policy name>. The following example assigns access policy MatchAll to the loopback interface labeled 1: (config)#interface loopback 1 (config-loop 1)#access-policy MatchAll 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 987 This is a routing parameter only and does not affect the physical interface. Usage Examples The following example sets bandwidth of the loopback interface to 10 Mbps: (config)#interface loopback 1 (config-loop 1)#bandwidth 10000 61200510L1-35E Loopback Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 988: Crypto Map

    This allows you to apply multiple crypto maps if you have created maps which share the same name but have different map index numbers. For VPN configuration example scripts, refer to the technical support note Configuring VPN located on the ADTRAN OS Documentation CD provided with your unit. Syntax Description <mapname>...
  • Page 989 The destination information is the local-side. Usage Examples The following example applies all crypto maps with the name MyMap to the loopback interface: (config)#interface loopback 1 (config-loop 1)#crypto map MyMap 61200510L1-35E Loopback Interface Configuration Command Set Static Filter (out) IPSec Encrypt Copyright © 2005 ADTRAN...
  • Page 990 IP address. Unlike a Dynamic DNS host, a Static DNS host does not expire after 35 days without updates, but updates take longer to propagate though the DNS system. This service is provided for up to five hostnames. 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 991 IP address support. Usage Examples The following example sets the dynamic-dns to dyndns-custom with hostname host, username user, and password pass: (config)#interface loopback 1 (config-loop 1)#dynamic-dns dyndns-custom host user pass 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 992 The following example sets up the router to allow only Telnet traffic into the loopback interface: (config)#ip access-list extended TelnetOnly (config-ext-nacl)#permit tcp any any eq telnet (config-ext-nacl)#interface loopback 1 (config-loop 1)#ip access-group TelnetOnly in 61200510L1-35E Loopback Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 993 IP addresses on the secondary subnet. Usage Examples The following example configures a secondary IP address of 192.22.72.101/30: (config)#interface loopback 1 (config-loop 1)#ip address 192.22.72.101 255.255.255.252 secondary 61200510L1-35E Loopback Interface Configuration Command Set Copyright © 2005 ADTRAN...

  • Page 994: Ip Helper-Address

    3. The media access control (MAC) address of the frame is an all-ones broadcast address (ffff.ffff.ffff). 4. The destination IP address is broadcast defined by all ones (255.255.255.255) or a subnet broadcast (for example, 192.33.4.251 for the 192.33.4.248/30 subnet). 61200510L1-35E Loopback Interface Configuration Command Set on page 425 for more information. Copyright © 2005 ADTRAN...
  • Page 995 Command Reference Guide Loopback Interface Configuration Command Set Usage Examples The following example forwards all DNS broadcast traffic to the DNS server with IP address 192.33.5.99: (config)#ip forward-protocol udp domain (config)#interface loopback 1 (config-loop 1)#ip helper-address 192.33.5.99 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 996 Packets received on the correct RPF interface are forwarded to this interface regardless of whether any receivers have joined the specified group using IGMP. Sets the interface’s IGMP version. The default setting is version 2. Copyright © 2005 ADTRAN...
  • Page 997 Command Reference Guide Loopback Interface Configuration Command Set Usage Examples The following example sets the query message interval on the interface to 200 milliseconds: (config)#interface loopback 1 (config-loop 1)#ip igmp last-member-query-interval 200 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 998 Usage Examples The following example enables multicast forwarding and IGMP on the interface: (config)#interface loopback 1 (config-loop 1)#ip mcast-stub downstream 61200510L1-35E Copyright © 2005 ADTRAN...
  • Page 999 IGMP proxy. Usage Examples The following example sets the helper address as the IGMP proxy: (config)#interface loopback 1 (config-loop 1)#ip mcast-stub helper-enable 61200510L1-35E Loopback Interface Configuration Command Set Copyright © 2005 ADTRAN...
  • Page 1000 Usage Examples The following example enables multicast forwarding on the interface: (config)#interface loopback 1 (config-loop 1)#ip mcast-stub upstream 61200510L1-35E Copyright © 2005 ADTRAN 1000...

Table of Contents

Save PDF
