Snmp-Agent Target-Host - H3C S5120-SI Series Command Reference Manual

snmp-agent target-host

Syntax
snmp-agent target-host trap address udp-domain ip-address [ udp-port port-number ] params
securityname security-string [ v1 | v2c | v3 [ authentication | privacy ] ]
undo snmp-agent target-host trap address udp-domain ip-address params securityname
security-string
View
System view
Default Level
3: Manage level
Parameters
trap: Specifies the host to be the target host which will receive traps and notifications from the device.
address: Specifies the destination IP address in the SNMP messages sent from the device.
udp-domain: Indicates that the trap is transmitted using UDP.
ip-address: The IPv4 address of the trap target host.
udp-port port-number: Specifies the number of the port on the target host to receive traps.
params securityname security-string: Specifies the authentication related parameter, which is an
SNMPv1 or SNMPv2c community name or an SNMPv3 user name, a string of 1 to 32 characters.
v1: SNMPv1. This keyword must be the same with the SNMP version on the NMS; otherwise, the NMS
cannot receive any trap.
v2c: SNMPv2c. This keyword must be the same with the SNMP version on the NMS; otherwise, the
NMS cannot receive any trap.
v3: SNMPv3. This keyword must be the same with the SNMP version on the NMS; otherwise, the NMS
cannot receive any trap.
authentication: Specifies the security model to be authentication without privacy. Authentication is
a process to check whether the packet is integral and whether it has been tampered. You need to
configure the authentication password when creating an SNMPv3 user.
privacy: Specifies the security model to be authentication with privacy. Privacy is to encrypt the
data part of a packet to prevent it from being intercepted. You need to configure the authentication
password and privacy password when creating an SNMPv3 user.
Description
Use the snmp-agent target-host command to configure the related settings for a trap target host.
Use the undo snmp-agent target-host command to remove the current settings. According to the
networking requirements, you can use this command for multiple times to configure different settings for
a target host, enabling the device to send trap messages to different NMSs. Up to 20 target hosts that
can be configured.
If udp-port port-number is not specified, port number 162 is used.
If the key words v1, v2 and v3 are not specified, v1 is used.
1-21
