Shift Tray Unit (D428)

2.11 SHIFT TRAY UNIT (D428)

2.11.1 COMPONENT CHECK

Check the quantity and condition of the components against the following list.
No.
1 Shift Tray Unit

2.11.2 INSTALLATION PROCEDURE

Unplug the copier power cord before starting the following procedure.
If both the shift tray unit and the 1-bin tray unit are installed in the mainframe at the
same time, install the shift tray unit first. Installing the shift tray unit after the 1-bin
tray unit may be difficult.
1. Remove all tapes.
D037/D038/D040/D041
Description
2-40
Q'ty
1
SM
